CANON IR1600 Service Manual

Cover page of CANON IR1600 Service Manual

Service Manual for CANON IR1600, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 614 pages
  • File size: 11.86 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
iR1600/iR2000
REVISION 0
SEPT. 2001
COPYRIGHT© 2001 CANON INC. 2001 CANON iR1600/iR2000 REV.0 SEPT. 2001 PRINTED IN JAPAN (IMPRIME AU JAPON)
FY8-13HJ-000
background image
iR1600/iR2000
REVISION 0
SEPT. 2001
COPYRIGHT© 2001 CANON INC. 2001 CANON iR1600/iR2000 REV.0 SEPT. 2001 PRINTED IN JAPAN (IMPRIME AU JAPON)
FY8-13HJ-000
background image
Application
This manual has been issued by Canon Inc. for qualified persons to learn technical
theory, installation, maintenance, and repair of products. This manual covers all localities
where the products are sold. For this reason, there may be information in this manual that
does not apply to your locality.
Corrections
This manual may contain technical inaccuracies or typographical errors due to
improvements or changes in products. When changes occur in applicable products or in
the contents of this manual, Canon will release technical information as the need arises.
In the event of major changes in the contents of this manual over a long or short period,
Canon will issue a new edition of this manual.
The following paragraph does not apply to any countries where such provisions are
inconsistent with local law.
Trademarks
The product names and company names used in this manual are the registered trade-
marks of the individual companies.
Copyright
This manual is copyrighted with all rights reserved. Under the copyright laws, this
manual may not be copied, reproduced or translated into another language, in whole or in
part, without the written consent of Canon Inc.
COPYRIGHT© 2001 CANON INC.
CANON iR1600/iR2000 REV.0 SEPT. 2001 PRINTED IN JAPAN (IMPRIME AU JAPON)
Caution
Use of this manual should be strictly supervised to avoid disclosure of confidential information.
COPYRIGHT © 2001 CANON INC.
Printed in Japan
Imprimé au Japon
background image
COPYRIGHT © 2001 CANON INC. 2001 2001 2001 2001 CANON iR1600/iR2000 REV.0 SEPT. 2001
i
INTRODUCTION
1 Symbols Used
This documentation uses the following symbols to indicate special information:
Symbol
Description
Refers to the Copier Basics Series for a better understanding of the contents.
Provides a description of the nature of an error indication.
Provides a description of a service mode.
Indicates an item of reference assisting the understanding of the topic in ques-
tion.
REF.
Indicates an item intended to provide notes assisting the understanding of the
topic in question.
Memo
Indicates an item requiring disconnection of the power plug from the electric
outlet.
Indicates an item prohibiting disassembly to avoid electric shocks or prob-
lems.
Indicates an item requiring care to avoid combustion (fire).
Indicates an item requiring care to avoid electric shocks.
Indicates an item of a non-specific nature, possibly classified as Note, Cau-
tion, or Warning.
background image
COPYRIGHT © 2001 CANON INC. 2001 2001 2001 2001 CANON iR1600/iR2000 REV.0 SEPT. 2001
ii
INTRODUCTION
2 Outline of the Manual
This Service Manual provides basic facts and figures needed to service the iR1600/
iR2000. Of the machine's accessories, this manual covers the cassette unit and inner 2-
way tray; for other accessories including the ADF, see its own Service Manual.
In this manual, the 1-Cassette Unit-F1, 2-Cassette Unit-G1 and 3-Cassette Unit-H1 are
collectively called "cassette unit," and the Inner 2-Way Tray-B1 is referred to as the inner
2-way tray.
This Service Manual consists of the following chapters:
Chapter 1 Introduction:
features, specifications, operation, system con-
struction, routine maintenance by the user, safety,
reproduction processes
Chapter 2 Basic Operation:
basic operation, outline of electrical circuitry, ba-
sic sequence
Chapter 3 Image Reading/
Processing System:
principles of operation of the exposure system,
principles of operation of the image processing
system, timing of operation; disassembly/assembly
and adjustment
Chapter 4 Laser Exposure System: principles of operation of the image formation sys-
tem, timing of operation; disassembly/assembly
Chapter 5 Image formation system: standards, adjustments, troubleshooting tables
Chapter 6 Pickup/Feeding System: principles of operation of the pickup/feeding sys-
tem, timing of operation; disassembly/assembly
and adjustment
Chapter 7 Fixing System:
principles of operation of the fixing system, timing
of operation; disassembly/assembly and adjust-
ment
Chapter 8 Externals and Auxiliary
Control System:
principles of operation of the externals/auxiliary
control system, timing of operation; disassembly/
assembly and adjustment
Chapter 9 Cassette Unit:
principles of operation of the pickup system; disas-
sembly/assembly and adjustments
Chapter 10 Inner 2-Way Tray:
principles of operation; disassembly/assembly and
adjustment
Chapter 11 Installation:
site requirements and installation procedure
Chapter 12 Maintenance and
Inspection:
table of periodically replaced parts, table of
durables, scheduled servicing chart
Chapter 13 Troubleshooting:
maintenance and inspection, standards/adjustment,
troubleshooting image faults/malfunctions; service
mode, self diagnosis
Chapter 14 Version up:
version up
Appendix:
general timing chart, general circuit diagram
background image
COPYRIGHT © 2001 CANON INC. 2001 2001 2001 2001 CANON iR1600/iR2000 REV.0 SEPT. 2001
iii
INTRODUCTION
The descriptions are subject to change for product improvement, and major changes
will be communicated in the form of Service Information bulletins.
All service persons are expected to go through the contents of this Service Manual and
Service Information bulletins and have a good understanding of the machine, readying
themselves to promptly respond to the needs of the field (i.e., identifying and correcting
faults).
