MP-L6000--USERS MANUAL/V000/12-97
CANON/MPL-6000/UM - File: L6_TP.eps
W. Swanlund
3 November 1997
MP-L6000--USERS MANUAL/V000/12-97
background image
MP-L6000--USERS MANUAL/V000/12-97
CANON/MPL-6000/UM - File: L6_TP.eps
W. Swanlund
3 November 1997
MP-L6000--USERS MANUAL/V000/12-97
background image
ii
Copyright
This manual is copyrighted by Canon Computer Systems, Inc. (CCSI)
with all rights reserved. Under the copyright laws, this manual may not be
reproduced in any form, in whole or part, without prior written consent of
CCSI.
©1997 Canon Computer Systems, Inc.
Disclaimer
Canon Computer Systems, Inc. has reviewed this manual thoroughly in
order to make it an easy to use guide for your Canon MultiPASS L6000
system. All statements, technical information, and recommendations in
this manual and in any guides or related documents are believed reliable,
but the accuracy and completeness thereof are not guaranteed or
warranted, and they are not intended to be, nor should they be understood
to be, representations or warranties concerning the products described.
Your MultiPASS L6000 and the software media included with your system
have been sold to you subject to the limited warranties set forth in the
warranty and license agreement enclosed with the respective product. All
software is licensed AS IS, as described in the license agreement enclosed
with the software media. Further, CCSI reserves the right to make changes
in the specifications of the products described in this manual at any time
without notice and without obligation to notify any person of such
changes.
Trademarks
Canon is a registered trademark and MultiPASS, ScanGear, and UHQ are
trademarks of Canon Inc.
Other brand and product names may be trademarks or registered
trademarks of their respective companies.
As an ENERGY STAR® Partner, Canon U.S.A., Inc. has determined that the
MultiPASS L6000 meets the ENERGY STAR guidelines for energy efficiency.
MP-L6000--USERS MANUAL/V000/12-97
background image
iii
USERS IN U.S.A.
PRE-INSTALLATION REQUIREMENTS FOR CANON
FACSIMILE EQUIPMENT
A. Location
Supply a suitable table, cabinet, or desk. See Appendix A for the unit's
dimensions and weight.
B. Order Information
1.
Only a single line, touch-tone or rotary telephone set is to be used.
2.
Order an RJ11-C modular jack (USOC code), which should be installed
by the phone company. If the RJ11-C jack is not present, installation
cannot occur.
3.
Order a normal business line from your telephone company's business
representative. The line should be a regular voice grade line or equivalent.
Use one line per unit.
DDD (DIRECT DISTANCE DIAL) LINE
or
IDDD (INTERNATIONAL DIRECT DISTANCE DIAL) LINE IF
YOU COMMUNICATE OVERSEAS
N Canonrecommendsanindividuallinefollowingindustrystandards[e.g.,the2500
(touch-tone) or 500 (rotary/pulse dial) telephones]. A dedicated extension off a
PBX unit without "Call Waiting" can be used with your MultiPASS L6000. Key
telephone systems are not recommended because they send non-standard signals to
individual telephones for ringing and special codes, which may cause a fax error.
C. Power Requirements
This equipment should be connected to a standard 120 volt AC, three-wire
grounded outlet only. Do not connect this unit to an outlet or power line
shared with other appliances that cause "electrical noise." Air conditioners,
electric typewriters, copiers, and machines of this sort generate noise which
often interferes with communications equipment and the sending and
receiving of documents.
CONNECTION OF THE EQUIPMENT
This equipment complies with Part 68 of the FCC rules. On the rear panel of this
equipment is a label that contains, among other information, the FCC
Registration Number and Ringer Equivalence Number (REN) for this equipment.
If requested, this information must be given to the telephone company. This
equipment may not be used on coin service provided by the telephone company.
Connection to party lines is subject to state tariffs.
MP-L6000--USERS MANUAL/V000/12-97
background image
iv
IN CASE OF EQUIPMENT MALFUNCTION
Should any malfunction occur which cannot be corrected by the procedures
described in this User's Manual, disconnect the equipment from the telephone line
or unplug the power cord. The telephone line should not be reconnected or the
power cord plugged in until the problem is completely resolved. Users should
contact Canon Authorized Service Facilities for servicing of equipment.
Information regarding Authorized Service Facility locations can be obtained by
calling the Canon Computer Systems Customer Care Center. (See page 1-2 for
details.)
RIGHTS OF THE TELEPHONE COMPANY
Should the equipment cause harm to the telephone network, the telephone
company may temporarily disconnect service. The telephone company also retains
the right to make changes in facilities and services which may affect the operation
of this equipment. When such changes are necessary, the telephone company is
required to give adequate prior notice to the user.
WARNING
Do not make any changes or modifications to the equipment unless otherwise
specified in the manual. If such changes or modifications should be made, you
could be required to stop operation of the equipment.
N ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassB
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed, and used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one of the
following measures:
q
Reorient or relocate the receiving antenna.
q
Increase the separation between the equipment and receiver.
q
Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
q
Consult the dealer or an experienced radio/TV technician for help.
The Telephone Consumer Protection Act of 1991 makes it unlawful for any
person to use a computer or other electronic device to send any message via a
telephone fax machine unless such message clearly contains in a margin at the top
or bottom of each transmitted page or on the first page of the transmission, the
date and time it is sent and an identification of the business or other entity, or
other individual sending the message and the telephone number of the sending
machine or such business, other entity, or individual.
To automatically enter this information into your MultiPASS L6000, follow the
instructions in your Quick Start Guide.
MP-L6000--USERS MANUAL/V000/12-97
background image
v
USERS IN CANADA
PRE-INSTALLATION REQUIREMENTS FOR CANON
FACSIMILE EQUIPMENT
A. Location
Supply a suitable table, cabinet, or desk. See Appendix A for the unit's
dimensions and weight.
B. Order Information
1.
Provide only a single-line to touch-tone or rotary telephone set
terminated with a standard 4-pin modular phone plug. (Touch-tone is
recommended if available in your area.)
2.
Order an RJ11-C modular jack (USOC code), which should be installed
by the phone company. If the RJ11-C jack is not present, installation
cannot occur.
3.
Order a normal business line from your telephone company's business
representative. The line should be a regular voice grade line or equivalent.
Use one line per unit.
DDD (DIRECT DISTANCE DIAL) LINE
or
IDDD (INTERNATIONAL DIRECT DISTANCE DIAL) LINE IF
YOU COMMUNICATE OVERSEAS
N Canonrecommendsanindividuallinefollowingindustrystandards[e.g.,the2500
(touch-tone) or 500 (rotary/pulse dial) telephones]. A dedicated extension off a
PBX unit without "Camp On" signals is also permissible with your MultiPASS
L6000. Key telephone systems are not recommended because they send non-
standard signals to individual telephones for ringing and special codes, which may
cause a fax error.
C. Power Requirements
The power outlet should be a three-prong grounded receptacle (Single or
Duplex). It should be independent from copiers, heaters, air conditioners, or
any electric equipment that is thermostatically controlled. The rated value is
120 volts and 15 amperes. The RJ11-C modular jack should be relatively
close to the power outlet to facilitate installation.
NOTICE
The Industry Canada label identifies certified equipment. This certification means
that the equipment meets telecommunications network protective, operational and
safety requirements as prescribed in the appropriate Terminal Equipment
Technical Requirements document(s). The Department does not guarantee the
equipment will operate to the user's satisfaction.
MP-L6000--USERS MANUAL/V000/12-97
