SERVICE BULLETIN COMP. SYSTEMS
Issued by Canon Europa N.V.
MODEL:
No.:
GEN-126
Date: 24.11.00
SUBJECT:
SERVICE PLAN
FOR
BUBBLE JET PRINTER S800
PRODUCT CODE: Q30-3410-xxx
Use of this Service Plan should be strictly supervised to avoid disclosures of confidential information.
background image
SERVICE BULLETIN COMP. SYSTEMS
Issued by Canon Europa N.V.
MODEL:
No.:
GEN-126
Date: 24.11.00
SUBJECT:
SERVICE PLAN
FOR
BUBBLE JET PRINTER S800
PRODUCT CODE: Q30-3410-xxx
Use of this Service Plan should be strictly supervised to avoid disclosures of confidential information.
background image
COMP. SYSTEMS
- 2 -
GEN-126
SERVICE PLAN FOR BUBBLE JET PRINTER S800
This Service Plan contains basic information required for preparation of service activities for model
Bubble Jet Printer S800 during the "launching period".
TABLE OF CONTENTS
1.
PRODUCT OUTLINE
1-1.
Overview
1-2.
Features
1-3.
Printer Specifications
1-4.
Print Media Specifications
1-4-1. Media type
1-4-2. Paper weight
1-5.
BJ Cartridges
1-6.
Printer / Scanner Drivers
1-7.
Scanner Cartridge
2.
SERVICE PARTS
2-1.
Number of Parts
2-2.
Major Assemblies
2-3.
Product Lifetime / MTBF / MTTR
2-4.
Adjustments
2-5.
Special Tools
2-6.
Periodic Replacement Parts / Consumable Parts
2-7.
Periodic Maintenance
2-8.
Customers Maintenance
3.
SERVICE MATERIALS
3-1.
Technical Documents List
4.
SERVICE TRAINING
5.
PRODUCT CODE LIST
5-1.
Main Unit
5-2.
Consumables
5-3.
Options
Note: Information in this Service Plan is subject to change.
background image
COMP. SYSTEMS
- 3 -
GEN-126
1. PRODUCT OUTLINE
The S800 is a successor model of the BJC-8200 printer, realizing photo-grade image thanks to
small 4pl. ink droplets and new light and dark inks.
New BJ cartridges, new inks, and driver improvements have allowed high speed printing, and
improved colors and durability.
1-1.
Overview
background image
COMP. SYSTEMS
- 4 -
GEN-126
1-2.
Features (Main changes from the BJC-8200)
(1)
Higher printing speed due to improved BJ cartridge.
(2)
Higher resolution of 2,400 x 1,200 dpi
(3)
Improved anti-weatherability due to new ink
(4)
Improvement of color briliance due to new inks and improved driver image processing
1-3.
Printer Specifications
Type
Desktop-type serial printer
Paper feeding method
Auto sheet feed and manual feeding
Resolution
2,400 x 1,200 dpi (max.)
Throughput speed
(Reference value)
Draft
Standard
High
Bk (BkJ97.doc)
4.11
3.45
1.10
Color (ColorJ97.doc)
3.49.
1.90
0.83
Color (600Pias_c.tif))
-
-
0.45
Printing direction
Bi-directional / Uni-directional
Print width
203 mm
Line feed speed
161 ms/line (at 256/1200" feed)
Interface
Bi-directional Centronics interface (IEEE1284 compatible)
USB (without HUB function)
ASF stacking capacity
Max. 10 mm (Approx. 100 pages of 64 g/m
2)
Detection functions
Cover open:
Available
Presence of BJ cartridge:
Available
Presence of scanner cartridge:
Available
Ink remaining amount:
Available
Paper out:
Available
Waste ink full:
Available
Paper width:
Not available
Acoustic noise level
Approx. 38 dB (8-pass printing / ASF fully stacked)
Environmental
requirements
During operation
Temperature
5
oC to 35oC
Humidity
10% to 90% (no condensation)
Non-operation
Temperature
0
oC to 35 oC
Humidity
5% to 95% (no condensation)
Power supply
Power voltage / Frequency
Power consumption
Stand-by status
AC220V to 240V / 50Hz
Approx. 27W (max.)
Approx. 5W
External dimensions
450(W) x 343 (D) x 208 (H) mm
Weight
5.9 kg (excluding the BJ cartridge)
Related standards
RFI: VCCI, FCC, IC, CE Mark, Taiwan EMC, Korean EMC, CCIB
(Chinese EMC) C-tick
Electrical safety:
Dentori, UL, C-UL, CB Report, GS, CE Mark,
FIMCO, CCIB, SISIR, AS, CCEE, PSB, Korean Dentori, SASO
Environment-related standards:
Blue Angel, Energy Star,
Environment label
Serial No. location
Printer frame (visible with front cover open)
