KENWOOD KCA-HF521 Owner's Manual

Cover page of KENWOOD KCA-HF521 Owner's Manual

Owner's Manual for KENWOOD KCA-HF521, downloadable as a PDF file.

We also have service manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 60 pages
  • File size: 1.81 MB
  • Available language versions: French, English, Dutch, German
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
KCA-HF521
GSM HANDS FREE UNIT
3 page 2 - 15
INSTRUCTION MANUAL
UNITE MAINS LIBRES POUR GSM
3 page 16 - 29
MODE D'EMPLOI
GSM-FREISPRECHGERÄT
3 Seite 30 - 43
BEDIENUNGSANLEITUNG
HANDSFREE UNIT VOOR GSM
3 blz 44 - 57
GEBRUIKSAANWIJZING
© PRINTED IN JAPAN B64-2252-00/01 (E)(DT)
background image
KCA-HF521
GSM HANDS FREE UNIT
3 page 2 - 15
INSTRUCTION MANUAL
UNITE MAINS LIBRES POUR GSM
3 page 16 - 29
MODE D'EMPLOI
GSM-FREISPRECHGERÄT
3 Seite 30 - 43
BEDIENUNGSANLEITUNG
HANDSFREE UNIT VOOR GSM
3 blz 44 - 57
GEBRUIKSAANWIJZING
© PRINTED IN JAPAN B64-2252-00/01 (E)(DT)
background image
Restriction on GSM Telephone connections
· It is necessary to set the "GSM MODEL SELECT SWITCH", found on the back of the control
unit, to the correct GSM model setting. See "GSM MODEL SELECT SWITCH" setting in the
<Installation> pages for details of setting.
· In Ericsson Models, you cannot use "@" for any entry into Phone Book or SMS. If the mark
is used, it is replaced with a space. However, the "@" mark is displayed at browsing.
· It is not possible to dial a number that includes either of the characters '#' or '*'.
· The correct operation of the unit with Siemens models requires that the supplied charging
adapter is plugged into the vehicles cigar lighter socket.
· If the generation of call lists is disabled on the GSM phone, then the redial functionality
offered by the KCA-HF521 will be adversely affected.
· You can use the GSM telephone connection to start the automatic downloading.
The downloading will be completed in several minutes. It may take more than 10 minutes to
finish the downloading, depending on GSM telephone models to be connected.
CAUTION
2
Before Use
Safety Precaution
To prevent injury and/or fire, take the following precautions:
· Ensure that the unit is securely installed. Otherwise it may fly out of place during collisions and
other jolts.
· To prevent short circuits, never put or leave any metallic objects (e.g., coins or metal tools)
inside the unit.
· If the unit starts to emit smoke or strange smells, turn off the power immediately and consult
your Kenwood dealer
To prevent damage to the machine, take the following precautions:
· Do not open the covers of the unit.
· Do not install the unit in a spot exposed to direct sunlight or excessive heat or humidity. Also
avoid places with too much dust or the possibility of water splashing.
· Do not use any screws except for the ones provided. The use of improper screws might result
in damage to the main unit.
If you experience problems during installation, consult your Kenwood dealer.
GSM model available for this unit
The GSM models that can be used with KCA- HF521 are as follows:
(As of December/2001)
NOTE
2CAUTION
2WARNING
Nokia
Ericsson
Siemens
6110/ 6210
R320/ T28/ A2618
S35/ M35
Brand Name
Model Name
GSM Connection Cable (Option)
CAW-NK 511
CAW-ES 511
CAW-SM 511
background image
3
Kenwood Receivers available for this unit
The receiver units that can be used with KCA-HF521 are as follows:
(As of December /2001)
CD Receiver/ Cassette Receiver
KDC-PSW9521/ KDC-M9021/ KDC-8021/ Z838W/ Z738/ Z638/ KDC-MV6521/ KDC-M6021/
KDC-M6021G/ KDC-6021/ X838
Monitor Receiver
KVT-M700
About the KCA-RC420 (Remote controller with [
] button)
The KCA-RC420 is optional depending on the types of receiver units.
About the disc changer/ CD player/ CA-C1AX to be connected:
· No O-N switch disc changer and CA-C1AX cannot be connected directly. (Except after 2002 models)
· Two disc changer or player cannot be connected (
During KCA-210A is connected).
Restriction on Receivers connected and conditions of
operation
Call from Phone Book
Redialling
Manual outgoing call
Automatic incoming call with GSM
Automatic incoming call with hands-free unit
Manual memory download
Phone Book data entry
Phone Book data update
Phone Book data deletion
Notification of new message (SMS)
Message (SMS) browsing
Message (SMS) deletion
Message (SMS) sending
N
Function
CD/Cassette
Receiver
N
N
Y*
Y*
N
N
N
N
Y
N
N
N
Y
Y
Y
Y
Y
Y
N
N
N
Y
Y
N
N
N
N
N
N
N
N
N
N
N
Y
N
N
N
N
N
N
Y*
Y*
N
N
N
N
Y
N
N
N
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
N
N
N
N
N
Y
N
N
N
Y
N
N
N
Y
Y
N
Y
Y
Y
N
N
Y
Y
N
N
N
KVT-M700
AB
C
A
B
C
D
*: Only the caller's phone number will be displayed.
A : During memory download from GSM
Telephone
B : Normal conditions
C : During a call
D : While driving (when parking brake
signal is undetected)
Y : Function available
N : Function not available
background image
Auto response time adjust:
If the time set in the GSM telephone is shorter than that set in the unit, the former will be
used.
4
Operation <For CD/ Cassette Receiver Unit>
Setting the Menu
Refer to the centre unit (receiver) instruction manual for Menu features.
DISP
FM
MENU
SRC
SRC
DISP
DISP
AM
MENU
MENU
AM
FM
AM
FM
"HF WT"/
"HF Wait Time"/
"Wait Time"
"HF MIC"/
"MIC ADJ"/
"HF MIC ADJ"
"HFSP"/
"HFSpeaker"/
"SP SEL"
"GSM SYNC"/
"GSM Memory
SYNC"
Auto Response time
Adjust
Microphone sensitivity
adjust
Phone voice speaker
setting
Phone Book/ Message
(SMS) data synchronize
"OFF"/"Off"
"01"-"30"
"00"-"31"
"ALL"/"All"
"FL"/
"Front-Left"/
"F-Left"
"FR"/
"Front-Right/
"F-Right"
Auto response function is off
Adjust 1 to 30 seconds
Adjust level from 0 to 31
Phone voice sent to
the front and rear speaker.
Phone voice sent to the front
left speaker.
Phone voice send to the front
right speaker.
Display
Adjustment Item
Setting
If you have updated GSM telephone after you
connected this unit to GSM telephone and
synchronized the data, select [SYNC] to
synchronize again.
KCA-RC420
About the KCA-RC420 (Remote
controller with [
] button)
The KCA-RC420 is optional
depending on the types of receiver
units.receiver units.
background image
1 Select the Initial Group
Press the [FM] or [AM] button.
Initials including no corresponding name will not
be displayed.
2 Select the Name
Press the [
4] or [¢] button.
Switching between the Name and Telephone
Number
Press the [DISP] button.
· Not available if the name has not been stored.
· Not applicable if the text scroll function has been set to Auto (in menu).
Dial a selected number
Press the [GSM] button for at least 1 second or press the [
] button on the remote.
5
1 Phone Book Search Mode
Hands Free Function
When a Call is Received
"HF CALL" / "CALL" will be displayed.
1 Accept a call
Press any button.
(Except SRC, ATT, volume, DISP and
0
buttons)
Switching between the Name and Telephone
Number
Press the [DISP] button.
2 Hang up
Press the [GSM] button for at least 1 second
or Press the [SRC] button.
12345678
HF CALL
KENWOOD
123456789012
CALL
KENWOOD
CALL
1 Select the GSM mode
Press the [GSM] button for at least 1 second or press the [
] button on the remote.
2 Select the mode item
Press the [GSM] button.
Each time the button is pressed the mode switches as follows: .
GSM Mode
"Initial"/"Initial Select"
"Redial"
"Dial"/ "Number Dial"
"SMS Mode"
1 Phone Book Search Mode
2 Redial Mode
3 Direct Dial Mode <Function of Remote (KCA-RC420) >
4 SMS Mode (SMS: Short Message Service)
Exit GSM Mode
Display
GSM Mode item
Display Ex, -1
Display Ex, -2
Inserting a CD or cassette tape while a call is in progress will cause the telephone to be
hung up.
CAUTION
I n i t i a l
KENWOOD
1 2 3 4 5 6 7 8
1 2 3 4 5 6 7 8
Initial Select
KENWOOD
Initial Select
Display Ex, -1
Display Ex, -2
