KCA-RC107MR

REMOTE CONTROL UNIT

INSTRUCTION MANUAL

UNITÉ DE TÉLÉCOMMANDE

MODE D'EMPLOI

FERNBEDIENUNG

BEDIENUNGSANLEITUNG

AFSTANDSBEDIENING

GEBRUIKSAANWIJZING

TELECOMANDO

ISTRUZIONI PER L'USO

UNIDAD DE MANDO A DISTANCIA

MANUAL DE INSTRUCCIONES

UNIDADE DE CONTROLO REMOTO

MANUAL DE INSTRUÇÕES

US Residence Only

KCA-RC107MR

REMOTE CONTROL UNIT

INSTRUCTION MANUAL

UNITÉ DE TÉLÉCOMMANDE

MODE D'EMPLOI

FERNBEDIENUNG

BEDIENUNGSANLEITUNG

AFSTANDSBEDIENING

GEBRUIKSAANWIJZING

TELECOMANDO

ISTRUZIONI PER L'USO

UNIDAD DE MANDO A DISTANCIA

MANUAL DE INSTRUCCIONES

UNIDADE DE CONTROLO REMOTO

MANUAL DE INSTRUÇÕES

US Residence Only

English

Function and Operation

· ID should be registered for this unit when connecting this

unit to the receiver. For details on how to register ID, refer

to <Remote control ID setup> in the receiver instruction

manual.

· You can control only the front or rear side with this unit

when the dual zone function of the receiver is active. By

default, the front side can be controlled. To switch to the

rear side, refer to <Dual Zone control setup> in the receiver

instruction manual.

· You may not able to control the receiver from this unit just

after turning the power on. Wait for 1 to 2 seconds and then

operate it.

¡ The power turns ON and OFF each time this

button is pressed.

TM Enters the Display setting mode.

For details, refer to <Display Setup> (described

later).

Pressing the button for at least 1 second scrolls

the screen.

£ Pressing the button switches a source as follows:

SIRIUS Satellite Radio ("SIRIUS") (Optional

accessory; only available in US market), Tuner

("TUNER"), iPod ("IPOD"), USB ("USB"), Bluetooth

Audio ("BT-A EXT") (Optional accessory; not

availabel in US market), and Auxiliary input

("AUX")

Unavailable sources cannot be switched.

¢ Enters the Audio control mode.

Pressing the button for at least 1 second

switches to the Audio setup mode.

Operation type

Operation

Selection of item

Press the [

5] or [] button.

Adjust the item

Press the [

] or [

] button.

This button is used to select a highlighted item

in the Search mode or another mode.

Tuner/Satellite radio: Selects the band.

iPod/USB: Selects folder.

§ Enters the Search mode.

"SRCH/FAV" is displayed.

When this unit is connected to KMR-700U,

pressing the §[

] button again switches to

the Favorite mode and pressing the ª[+] or []

button to the Music Search mode.

For further details on the Search mode, refer

to the instruction manual of the connected

receiver. The Search mode function can be used

with the same operation as the receiver.

¶ Tuner/Satellite radio: Selects station/channel.

iPod/USB: Selects music.

· Reduces the volume.

When the button is pressed again, the volume

returns to the previous level.

Pressing the button for at least one second

pauses a song being played. Pressing again for

at least one second resumes the song.

ª Adjusts the volume.

English

Display Setup

You can adjust following Display items;

Display

Item

Setting

"DISP SEL"

Refer to <Text Display Selection>.

"DIM"

Sets whether the display illumination is

dimmed in conjunction with the light

switch of the vessel or it is dimmed

constantly.

"AUTO",

"MANU",

"OFF"

"CNTRST"

Adjusting the display contrast.

"0" "10"

"ID:"

Display the Remote control ID.

· For details on Remote control ID, refer to <Remote

control ID setup> in the receiver instruction manual.

1 Enter Display setup mode

Press the [DISP] button.

2 Select the Display setup item

Press the [

5] or [] button.

3 Adjust the Display setup item

Press the [

] or [

] button.

4 Exit Display setup mode

Press the [DISP] button.

Text Display Selection

Displays the following abbreviated text for settings

and functions;

In Tuner source

Information

Display

Frequency & Program Service name (RDS)

"FREQ/PS"

Music title (RDS) & Artist name (RDS)

"TITLE"

Station Name (RDS)

"ST NAME"

Radio text Plus (RDS)

"R-TEXT+"

Radio text (RDS)

"R-TEXT"

Frequency (FM/AM)

"FREQ"

Clock

"CLOCK"

Date

"DATE"

In iPod/ USB source

Information

Display

Music title & Artist name

"TITLE"

Album name & Artist name

"ALBUM"

Folder name

"FOLDER"

File name

"FILE"

Play time & Music number

"P-TIME"

Clock

"CLOCK"

Date

"DATE"

In Auxiliary input source

Information

Display

AUX name

"SRC NAME"

Clock

"CLOCK"

Date

"DATE"

In SIRIUS source (Optional)

Information

Display

Channel Name

"CH-NAME"

Music Title

"SONG"

Artist Name

"ARTIST"

Composer Name

"COMPOSER"

Category Name

"CATEGORY"

Label Name

"LABEL"

Comment

"COMMENT"

Channel Number

"CH NUM"

Clock

"CLOCK"

Date

"DATE"

1 Enter Display setup mode

Press the [DISP] button.

2 Select the Display text select item

Press the [

5] or [] button.

Select the "DISP SEL" display.

3 Enter Display text select mode

Press the [ENTER] button.

4 Select the text display part

Press the [

5] or [] button.

5 Select the Display text

Press the [

] or [

] button.

6 Exit Display text select mode

Press the [ENTER] button.

· If the selected display item does not have any

information, alternative information is displayed.

· When selecting "FOLDER" while playing with iPod, text

will be displayed depending on the currently selected

browsing mode.

· If all characters cannot be displayed while playing with

iPod, the file number in the list is displayed.

Information

Display

Music title

"TITLE***"

Folder name

"FLD***"

File name

"FILE***"

English

Before Installation

Connection

Connectable model (as of February 2009)

· KMR-700U

· Mounting and wiring this product requires skills and

experience. For safety's sake, leave the mounting and wiring

work to professionals.

· Do not install the unit in a spot exposed to direct sunlight

or excessive heat or humidity.

· Do not use your own screws. Use only the screws provided.

If you use the wrong screws, you could damage the unit.

· After installing the unit, check to make sure that electrical

equipment such as the signal lamps and gauges operate

normally.

When connecting single KCA-RC107MR

Remote control input

Marine Receiver

KCA-RC107MR

When connecting two KCA-RC107MRs

Remote control input

Marine Receiver

KCA-RC107MR

CA-Y107MR

(Optional

accessory)

When connecting three KCA-RC107MRs

Remote control input

Marine Receiver

KCA-RC107MR

CA-Y107MR

(Optional

accessory)

CA-Y107MR

(Optional

accessory)

· You can use the extension cable CA-EX7MR (7m) or

CA-EX3MR (3m) to extend the wiring cable up to 15

meters, if the installation positions of the receiver and KCA-

RC107MR are long distance apart.

English

Installation

1 Drill holes on the mounting surface in accordance

with Template (back cover).

2 Install the KCA-RC107MR as shown in the figure

below.

When using the Mounting frame

Surface Mounting (not using mounting frame)

Nut

Lock washer

Mounting surface (Max. board thickness: 18 mm)

Mounting frame

Waterproof rubber

Gasket

KCA-RC107MR

Washer

Mounting bracket

Nut

Lock washer

Mounting surface (Max. board thickness: 26 mm)

Gasket

KCA-RC107MR

Washer
