KDC-4060RG

KDC-4060RA

CD-RECEIVER

INSTRUCTION MANUAL

KDC-4060RG

KDC-4060RA

CD-RECEIVER

INSTRUCTION MANUAL

Contents

-- 2 --

English

Before use

Safety precautions ........................................................................3

Handling Compact discs................................................................5

Buttons and Display ......................................................................6

Basic operations

Power............................................................................................9

Volume ..........................................................................................9

Attenuator .....................................................................................9

Loudness ......................................................................................9

Menu System..............................................................................10

Tuner features

Selecting Tuning Mode ...............................................................11

Tuning .........................................................................................11

Local Seek Function ....................................................................11

Monaural Reception ....................................................................12

Station Preset Memory ...............................................................12

Auto Memory Entry.....................................................................12

RDS features

RDS (Radio Data System) ...........................................................13

EON (Enhanced Other Network).................................................13

Alarm...........................................................................................13

AF(Alternative Frequency) Function ............................................13

Restricting RDS Region (Region Restrict Function) ....................14

Traffic Information Function ........................................................14

Auto TP Seek Function................................................................15

Presetting Volume for Traffic Information/ News .......................15

News Bulletin Function with PTY News Timeout Setting...........16

Programme Type (PTY) Function ................................................17

CD player features

Playing CDs .................................................................................18

Fast Forwarding and Reversing Disc Play ...................................18

Switching Display for CDs...........................................................18

Track Search................................................................................18

Track Repeat Function ................................................................19

Track Scan Function ....................................................................19

Random Play Function ................................................................19

Other features

Audio Control Setting ..................................................................20

Clock Display...............................................................................20

Adjusting Time ............................................................................20

DSI (Disabled System Indicator)..................................................21

Theft Deterrent Faceplate ...........................................................21

Installation

Accessories.................................................................................22

Installation Procedure..................................................................22

Connecting Cables to Terminals .................................................23

Installation ...................................................................................24

Troubleshooting guide .......................................................26

Specifications .........................................................................27

-- 3 --

Safety precautions

To prevent injury and/or fire, take the

following precautions:

· Insert the unit all the way until it is fully

locked in place. Otherwise it may fly out of

place during collisions and other jolts.

· When extending the ignition, battery or

ground cables, make sure to use automotive-

grade cables or other cables with an area of

0.75mm2 (AWG18) or more to prevent cable

deterioration and damage to the cable

coating.

· To prevent short circuits, never put or leave

any metallic objects (e.g., coins or metal

tools) inside the unit.

· If the unit starts to emit smoke or strange

smells, turn off the power immediately and

consult your Kenwood dealer.

· Be careful not to drop the unit or subject it to

strong shock.

The unit may break or crack because it

contains glass parts.

· Do not touch the liquid crystal fluid if the LCD

is damaged or broken due to shock. The

liquid crystal fluid may be dangerous to your

health or even fatal.

If the liquid crystal fluid from the LCD

contacts your body or clothing, wash it off

with soap immediately.

2WARNING

To prevent damage to the machine,

take the following precautions:

· Make sure to ground the unit to a negative

12V DC power supply.

· Do not open the top or bottom covers of the

unit.

· Do not install the unit in a spot exposed to

direct sunlight or excessive heat or humidity.

Also avoid places with too much dust or the

possibility of water splashing.

· Do not set the removed faceplate or the

faceplate case in areas exposed to direct

sunlight, excessive heat or humidity. Also

avoid places with too much dust or the

possibility of water splashing.

· Do not subject the faceplate to excessive

shock, as it is a piece of precision equipment.

· To prevent deterioration, do not touch the

terminals of the unit or faceplate with your

fingers.

· When replacing a fuse, only use a new one

with the prescribed rating. Using a fuse with

the wrong rating may cause your unit to

malfunction.

· To prevent short circuits when replacing a

fuse, first disconnect the wiring harness.

During installation, do not use any screws

except for the ones provided. The use of

improper screws might result in damage to

the main unit.

2CAUTION

Safety precautions

-- 4 --

English

· If you experience problems during

installation, consult your Kenwood dealer.

· If the unit does not seem to be working right,

try pressing the reset button first. If that does

not solve the problem, consult your Kenwood

dealer.

Cleaning the Unit

If the front panel gets dirty, turn off the

power and wipe the panel with a dry silicon

cloth or soft cloth.

Do not wipe the panel with a stiff cloth or a

cloth dampened by volatile solvents such as

paint thinner and alcohol. They can scratch

the surface of the panel and/or cause the

indicator letters to peel off.

Cleaning the Faceplate Terminals

If the terminals on the unit or faceplate get

dirty, wipe them with a dry, soft cloth.

2CAUTION

NOTE

AUD

ATT

T I

LOUD

CLK

VOL

ADJ

REP

RDM

SCN

DISP

PWR

OFF

EJECT

35Wx4

NAME SET

Reset button

The marking of products using lasers

(Except for some areas)

The label is attached to the chassis/case and

says that the component uses laser beams

that have been classified as Class 1. It means

that the unit is utilizing laser beams that are

of a weaker class. There is no danger of

hazardous radiation outside the unit.

CLASS 1

LASER PRODUCT

Cleaning the CD Slot

As dust can accumulate in the CD slot, clean

it occasionally. Your CDs can get scratched if

you put them in a dusty CD slot.

Lens Fogging

Right after you turn on the car heater in cold

weather, dew or condensation may form on

the lens in the CD player of the unit. Called

lens fogging, CDs may be impossible to play.

In such a situation, remove the disc and wait

for the condensation to evaporate. If the unit

still does not operate normally after a whilst,

consult your Kenwood dealer.

-- 5 --

Handling Compact discs

Playing a CD that is dirty, scratched

or warped can cause the sound to

skip and the unit to operate

incorrectly, resulting in worsened

sound quality. Take the following

precautions to prevent your CDs from

getting scratched or damaged.

Handling CDs

· Do not touch the recorded side of the CD

(i.e., the side opposite the label) when

holding it.

· Do not stick tape on either side of the CD.

Storing CDs

· Do not store CDs in areas exposed to direct

sunlight such as a car seat or above the

fascia panel (dashboard) or other hot

places.

· Remove CDs from the unit when not

listening to them for a whilst, and put them

back in their cases. Do not stack CDs that

have been removed from their cases or prop

them against something.

Cleaning CDs

If a CD has become dirty, wipe it off gently

using a commercially available cleaning cloth

or a soft cotton cloth, starting from the

centre of the disc and moving outward. Do

not clean CDs with conventional record

cleaners, anti- static formulas, or chemicals

such as paint thinner or benzene.

Checking New CDs for Burrs

When playing a new CD for the first time,

check that there are not any burrs stuck to

the perimeter of the disc or in the central

hole. CDs with burrs stuck on them may not

load properly or may skip whilst playing.

Remove burrs using a ballpoint pen or a

similar utensil.

Do Not Load CD Accessories in Slot

Do not use commercially available CD

accessories that can be loaded into the CD

slot, such as stabilisers, protective sheets, or

CD cleaning discs, since they can cause the

unit to malfunction.

Removing the CD

Only remove the CD from the machine in a

horizontal direction. You may damage the

surface of the CD if you try pulling it down as

it ejects.

Do Not Load 8-cm (3-in.) CDs in

the CD slot

If you try to load an 8-cm CD with its adapter

into the unit, the adapter might separate

from the CD and damage the unit.

Do Not Use Special Shape CDs

· Be sure to use round shape CDs only for this

unit and do not use any special shape CDs.

Use of special shape CDs may cause the

unit to malfunction.

· Be sure to use CDs with disc mark

only for this unit.

2CAUTION
