KENWOOD TK3160 Service Manual

Cover page of KENWOOD TK3160 Service Manual

Service Manual for KENWOOD TK3160, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 59 pages
  • File size: 2.06 MB
  • Available language versions: Japanese, English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
UHF FM TRANSCEIVER / UHF
TK-3160
© 2004-4 PRINTED IN JAPAN
B51-8682-00 (S) 589
SERVICE MANUAL /
C · C2 versions
GENERAL ............................................................. 2
SYSTEM SET-UP ................................................. 3
REALIGNMENT .................................................... 4
DISASSEMBLY FOR REPAIR .............................. 6
CIRCUIT DESCRIPTION ..................................... 10
INSTALLATION .................................................. 18
TERMINAL FUNCTION ...................................... 19
SEMICONDUCTOR DATA ................................. 21
COMPONENTS DESCRIPTION ......................... 23
PARTS LIST ........................................................ 25
EXPLODED VIEW ............................................... 32
PACKING ............................................................ 33
ADJUSTMENT ................................................... 34
PC BOARD
TX-RX UNIT (X57-673X-XX) ........................ 44
SCHEMATIC DIAGRAM ..................................... 48
BLOCK DIAGRAM .............................................. 52
LEVEL DIAGRAM ............................................... 54
SPECIFICATIONS ............................................... 55
CONTENTS
Knob (CH-SELECTOR)
()
(K29-9280-13)
Knob (VOLUME)
()
(K29-9278-13)
Knob (PTT)
(PTT)
(K29-9332-03)
Antenna
(T90-0798-15) : C
(T90-0800-15) : C2
Cabinet assy
(A02-3826-43)
background image
UHF FM TRANSCEIVER / UHF
TK-3160
© 2004-4 PRINTED IN JAPAN
B51-8682-00 (S) 589
SERVICE MANUAL /
C · C2 versions
GENERAL ............................................................. 2
SYSTEM SET-UP ................................................. 3
REALIGNMENT .................................................... 4
DISASSEMBLY FOR REPAIR .............................. 6
CIRCUIT DESCRIPTION ..................................... 10
INSTALLATION .................................................. 18
TERMINAL FUNCTION ...................................... 19
SEMICONDUCTOR DATA ................................. 21
COMPONENTS DESCRIPTION ......................... 23
PARTS LIST ........................................................ 25
EXPLODED VIEW ............................................... 32
PACKING ............................................................ 33
ADJUSTMENT ................................................... 34
PC BOARD
TX-RX UNIT (X57-673X-XX) ........................ 44
SCHEMATIC DIAGRAM ..................................... 48
BLOCK DIAGRAM .............................................. 52
LEVEL DIAGRAM ............................................... 54
SPECIFICATIONS ............................................... 55
CONTENTS
Knob (CH-SELECTOR)
()
(K29-9280-13)
Knob (VOLUME)
()
(K29-9278-13)
Knob (PTT)
(PTT)
(K29-9332-03)
Antenna
(T90-0798-15) : C
(T90-0800-15) : C2
Cabinet assy
(A02-3826-43)
background image
TK-3160
2
INTRODUCTION
SCOPE OF THIS MANUAL
This manual is intended for use by experienced technicians
familiar with similar types of commercial grade
communications equipment. It contains all required service
information for the equipment and is current as of the
publication date. Changes which may occur after publication
are covered by either Service Bulletins or Manual Revisions.
These are issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment information,
the full part identification number should be included. This
applies to all parts : components, kits, or chassis. If the part
number is not known, include the chassis or kit number of
which it is a part, and a sufficient description of the required
component for proper identification.
PERSONAL SAFETY
The following precautions are recommended for personal
safety:
DO NOT transmit until all RF connectors are verified secure
and any open connectors are properly terminated.
SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
This equipment should be serviced by a qualified technician only.
............................................................................................... 2
...................................................................................... 3
...................................................................................... 4
...................................................................................... 6
.................................................................................... 10
............................................................................................. 18
.................................................................................... 19
................................................................................ 21
.................................................................................... 23
........................................................................................ 25
................................................................................ 32
............................................................................................. 33
............................................................................................. 34
PC
TXRX (X57-673X-XX) .......................................... 44
........................................................................................ 48
........................................................................................ 52
........................................................................................ 54
.........................................................................................
GENERAL /
background image
TK-3160
3
SYSTEM SET-UP /
SYSTEM SET-UP /
Merchandise received
Choose the type of transceiver
Transceiver programming
Are you using the speaker microphone?
KMC-17 or KMC-21 Speaker microphone
YES /
NO /
( Option /
)
TX/RX
4.0W
TK-3160(C)
Frequency range (MHz)
RF power
Type
Delivery
440~480
TX/RX
4.0W
TK-3160(C2)
400~430
A personal computer (IBM PC or compatible), programming
interface (KPG-22), and programming software (KPG-82D)
are required for programming.
(The frequency, TX power HI/LOW, and signalling data are programmed
for the transceiver.)
(IBM)(KPG-22)
(KPG-82D)
(TX/ )
?
KMC-17KMC-21
MHz
GENERAL /
Unit
Model
TX-RX Unit
Frequency range
Remarks
& destination
C
X57-6733-01
440~480MHz
TK-3160
IF1 : 49.95MHz
C2
X57-6730-12
400~430MHz
LOC : 50.4MHz
TX-RX
C
X57-6733-01
440~480MHz
TK-3160
IF1 : 49.95MHz
C2
X57-6730-12
400~430MHz
LOC : 50.4MHz
SERVICE
This radio is designed for easy servicing. Refer to the
schematic diagrams, printed circuit board views, and alignment
procedures contained within.
background image
TK-3160
4
REALIGNMENT /
2. How to Enter Each Mode
Mode
Operation
User mode
Power ON
PC mode
Received commands from PC
1. Modes
User mode
PC mode
PC test mode
Data programming
mode
PC tuning mode
REALIGNMENT
3.PC Mode
3-1. Preface
The TK-3160 transceiver is programmed using a personal
computer, a programming interface (KPG-22) and programming
software (KPG-82D).
The programming software can be used with an IBM PC
or compatible. Figure 1 shows the setup of an IBM PC for
programming.
3-2. Connection procedure
1. Connect the TK-3160 to the personal computer with the
interface cable.
2. When the POWER is switched on, user mode can be
entered immediately. When the PC sends a command,
the radio enters PC mode.
When data is transmitting from the transceiver, the red
LED lights.
When data is received by the transceiver, the green LED
lights.
Notes:
· The data stored in the personal computer must match the
model type when it is written into the EEPROM.
· Change the TK-3160 to PC mode, then attach the interface
cable.
1 .
3.
3-1
TK-3160 KPG-22
KPG-82D
IBM 1 IBM
3-2
1. TK-3160
2. PC
PC
Mode
Function
User mode
For normal use.
PC mode
Used for communication between the
radio and PC (IBM compatible).
Data programming
Used to read and write frequency data
mode
and other features to and from the radio.
PC test mode
Used to check the radio using the PC.
This feature is included in the KPG-
82D.
(IBM )
KPG- 82D
2.
·
EEPROM ,
·
TK-3160
background image
TK-3160
5
3-3. KPG-22 description
(PC programming interface cable: Option)
The KPG-22 is required to interface the TK-3160 with the
computer. It has a circuit in its D-subconnector (25-pin) case
that converts the RS-232C logic level to the TTL level.
The KPG-22 connects the side panel connector of the TK-
3160 to the computer's RS-232C serial port.
3-4. Programming software description
KPG-82D is the programming software for TK-3160
supplied on a CD-ROM. This software runs under Windows
98, ME, Windows 2000 or XP on an IBM-PC or compatible
machine.
The data can be input to or read from TK-3160 and edited
on the screen. The programmed or edited data can be printed
out. It is also possible to tune the transceiver.
Fig. 1 /
Tuning cable /
(E30-3216-05)
RF Power meter or SSG
/ RF SSG
+
/
­
1.5D-XV
+
1.5D-XV ­
}
}
SP
MIC
KPG-22
KPG-82D
IBM-PC /
IBM
Gray
Gray/Black
1.5D-XV Lead wire
1.5D-XV Shield wire
3-3 KPG-22 (PC )
TK-3160 KPG-22
D 25 RS-232C TTL
KPG-22 TK-3160
RS-232C
3-4
KPG-82D TK-3160
IBM-PC Windows 98,ME,Windows 2000 XP
TK-3160
REALIGNMENT /
