Z919

INSTRUCTION MANUAL

MULTI CONTROL CD-RECEIVER

01/12 11 10 9 8 7 6 5 4 3 2 1 00/12 11 10 9 8 7 6 5 4

Take the time to read through this instruction manual.

Familiarity with installation and operation procedures will help you obtain the

best performance from your new CD-receiver.

For your records

Record the serial number, found on the back of the unit, in the spaces designated on

the warranty card, and in the space provided below. Refer to the model and serial

numbers whenever you call upon your KENWOOD dealer for information or service on

the product.

Model Z919 Serial number

Z919

INSTRUCTION MANUAL

MULTI CONTROL CD-RECEIVER

01/12 11 10 9 8 7 6 5 4 3 2 1 00/12 11 10 9 8 7 6 5 4

Take the time to read through this instruction manual.

Familiarity with installation and operation procedures will help you obtain the

best performance from your new CD-receiver.

For your records

Record the serial number, found on the back of the unit, in the spaces designated on

the warranty card, and in the space provided below. Refer to the model and serial

numbers whenever you call upon your KENWOOD dealer for information or service on

the product.

Model Z919 Serial number

-- 2 --

English

Contents

Before use

Warning........................................................................................................3

Safety precautions .......................................................................................3

Notes on playing MP3 files ..........................................................................5

Handling Compact discs ..............................................................................8

General features

Power...........................................................................................................9

Switching Modes .........................................................................................9

Volume .......................................................................................................10

Loudness ...................................................................................................10

Panel Angle Adjustment ............................................................................10

Clock Adjustment.......................................................................................10

Stopwatch ..................................................................................................11

Timer ..........................................................................................................11

Alarm..........................................................................................................12

Automatic Dimmer Function ......................................................................12

Display Font Setting ...................................................................................12

Switching the Round Indicator for the Sound Level ..................................12

Audio Control Setting .................................................................................13

Digital Crossover Network .........................................................................15

Tuner features

Tuning ........................................................................................................16

Station Preset Memory ..............................................................................16

Auto Memory Entry ...................................................................................17

Preset Tuning .............................................................................................17

Clean Reception System Circuit (CRSC) ....................................................17

Switching Display for Tuner .......................................................................17

Station Name Preset (SNPS)......................................................................18

Station Name Preset Play (SBF).................................................................19

Direct Access Tuning .................................................................................19

CD/External disc control features

Playing CDs ................................................................................................20

Playing Other Disc Mode ...........................................................................21

Fast Forwarding and Reversing Disc Play ..................................................21

Track Search ..............................................................................................21

Disc Search ................................................................................................22

Track Repeat ..............................................................................................22

Disc Repeat................................................................................................22

Track Scan..................................................................................................22

Disc Scan ...................................................................................................22

Random Play ..............................................................................................23

Magazine Random Play..............................................................................23

Text Scroll ..................................................................................................23

Direct Track Search ....................................................................................23

Direct Disc Search .....................................................................................24

Presetting Disc Names ..............................................................................24

Switching Display for Discs .......................................................................25

Switching Playing Time Display .................................................................25

Search on Initials ........................................................................................26

MP3 features

Playing MP3 files .......................................................................................28

File Search .................................................................................................28

Folder Search .............................................................................................29

File Repeat .................................................................................................29

Folder Repeat.............................................................................................29

Random Play ..............................................................................................29

Name Scroll for MP3..................................................................................29

Presetting Disc Names (DNPS)..................................................................29

Direct File Search .......................................................................................30

Switching Display for MP3.........................................................................30

Folder Select ..............................................................................................30

External TV control features

Tuning ........................................................................................................32

Station Preset Memory ..............................................................................32

Auto Memory Entry ...................................................................................32

Preset Tuning .............................................................................................32

Direct Access Tuning .................................................................................33

Function set system

Function Set System..................................................................................34

Touch Sensor Tone ....................................................................................34

Dimmer ......................................................................................................34

Silent Display .............................................................................................34

KEX (Sound Coordinate system) ................................................................35

SP (Speaker selector) .................................................................................35

Basic operations of remote ....................................35

Installation

Accessories................................................................................................39

Installation Procedure ................................................................................39

Connecting Wires to Terminals..................................................................40

System Connection....................................................................................41

Installation ..................................................................................................42

Removing the Unit .....................................................................................44

Troubleshooting guide ...........................................45

Specifications ........................................................48

-- 3 --

Use of controls or adjustments or

performance of procedures other than those

specified herein may result in hazardous

radiation exposure.

In compliance with Federal Regulations,

following are reproductions of labels on, or

inside the product relating to laser product

safety.

Location : Bottom Panel

FCC WARNING

This equipment may generate or use radio

frequency energy. Changes or modifications

to this equipment may cause harmful

interference unless the modifications are

expressly approved in the instruction manual.

The user could lose the authority to operate

this equipment if an unauthorized change or

modification is made.

2CAUTION

This equipment has been tested and found to

comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide

reasonable protection against harmful

interference in a residential installation. This

equipment may cause harmful interference

to radio communications, if it is not installed

and used in accordance with the instructions.

However, there is no guarantee that

interference will not occur in a particular

installation. If this equipment does cause

harmful interference to radio or television

reception, which can be determined by

turning the equipment off and on, the user is

encouraged to try to correct the interference

by one or more of the following measures:

· Reorient or relocate the receiving antenna.

· Increase the separation between the

equipment and receiver.

· Connect the equipment into an outlet on a

circuit different from that to which the

receiver is connected.

· Consult the dealer or an experienced radio/TV

technician for help.

This Class B digital apparatus complies with

Canadian ICES-003.

NOTE

Safety precautions

To prevent injury or fire, take the

following precautions:

· Insert the unit all the way in until it is fully

locked in place. Otherwise it may fall out of

place when jolted.

· When extending the ignition, battery, or

ground wires, make sure to use automotive-

grade wires or other wires with a 0.75mm2

(AWG18) or more to prevent wire

deterioration and damage to the wire coating.

· To prevent a short circuit, never put or leave

any metallic objects (such as coins or metal

tools) inside the unit.

· If the unit starts to emit smoke or strange

smells, turn off the power immediately and

consult your Kenwood dealer.

· Make sure not to get your fingers caught

between the faceplate and the unit.

· Be careful not to drop the unit or subject it to

strong shock.

The unit may break or crack because it

contains glass parts.

2WARNING

2Warning

KENWOOD CORPORATION

2967-3, ISHIKAWA-CHO,

HACHIOJI-SHI

TOKYO, JAPAN

KENWOOD CORP. CERTIFIES THIS EQUIPMENT

CONFORMS TO DHHS REGULATIONS N0.21 CFR

1040. 10, CHAPTER 1, SUBCHAPTER J.

· The illustrations of the display and the panel

appearing in this manual are examples used

to explain more clearly how the controls are

used. Therefore, what appears on the display

in the illustrations may differ from what

appears on the display on the actual

equipment, and some of the illustrations on

the display may represent something

impossible in actual operation.

· If you experience problems during

installation, consult your Kenwood dealer.

· If the unit does not seem to be working right,

try pressing the reset button first. If that does

not solve the problem, consult your Kenwood

dealer.

· The functions that can be used and the

information that can be displayed will differ

depending on the external disc players being

connected.

NOTE

-- 4 --

English

To prevent damage to the machine,

take the following precautions:

· Make sure to ground the unit to a negative

12V DC power supply.

· Do not open the top or bottom covers of the

unit.

· Do not install the unit in a spot exposed to

direct sunlight or excessive heat or humidity.

Also avoid places with too much dust or the

possibility of water splashing.

· Do not subject the faceplate to excessive

shock, as it is a piece of precision equipment.

· When replacing a fuse, only use a new one

with the prescribed rating. Using a fuse with

the wrong rating may cause your unit to

malfunction.

· To prevent a short circuit when replacing a

fuse, first disconnect the wiring harness.

· Do not place any object between the

faceplate and the unit.

· Do not use your own screws. Use only the

screws provided. If you use the wrong

screws, you could damage the unit.

2CAUTION

Reset button

Safety precautions

Cleaning the Unit

If the front panel gets dirty, turn off the

power and wipe the panel with a dry silicon

cloth or soft cloth.

Do not wipe the panel with a hard cloth or a

cloth dampened by volatile solvents such as

paint thinner and alcohol. They can scratch

the surface of the panel and/or cause the

indicator letters to peel off.

Cleaning the CD Slot

As dust tends to accumulate in the CD slot,

clean it every once in a while. Your CDs can

get scratched if you put them in a dusty CD

slot.

Lens Fogging

Right after you turn on the car heater in cold

weather, dew or condensation may form on

the lens in the CD player of the unit. Called

lens fogging, CDs may be impossible to play.

In such a situation, remove the disc and wait

for the condensation to evaporate. If the unit

still does not operate normally after a while,

consult your Kenwood dealer.

2CAUTION

-- 5 --

Notes on playing MP3 files

This unit can play MP3 files.

Note, however, that the MP3 file recording media and

formats acceptable are limited.

When writing MP3 files, pay attention to the following

restrictions.

Acceptable media

The MP3 file recording media acceptable to this unit are CD-ROM,

CD-R, and CD-RW.

Acceptable medium formats

The medium formats acceptable to this unit are ISO 9660 Level 1 and

Level 2 excluding the extended formats. When reading an MP3 file

written in a format other than ISO 9660 Level 1 or Level 2, the unit

may fail to play the file normally or display the file or folder name

correctly.

The major specifications of ISO 9660 Level 1 and Level 2 are as

follows:

· Maximum number of directory levels: 8

· Maximum number of files and folders per directory level:

253 (files and folders in total)

· Characters available to file and folder names:

A - Z, 0 - 9, _(underscore)

· Maximum number of characters in file names:

Level 1 : 12 (including a separator "." and a 3-character extension)

Level 2 : 31 (including a separator "." and a 3-character extension)

Settings for your MP3 encoder and CD writer

When you use your MP3 encoder to compress audio data to an MP3

file, set the transfer bit rate of the encoder to fixed 128 kbps.

When you use your CD writer to record MP3 files up to the maximum

disc capacity, disable additional writing. For recording on an empty

disk up to the maximum capacity at once, check Disc at Once.

Entering file and folder names

When entering file and folder names, use alphanumeric characters

only. If entered with any other character, the file and folder names are

not displayed correctly. They may neither be displayed correctly

depending on the CD writer used.

Note that the unit cannot display ID tags even though they have been

embedded in MP3 files.

The unit recognizes and plays only those MP3 files which have the

MP3 filename extension (.MP3). MP3 files should therefore be saved

with the MP3 extension.

Writing files into a medium

When a medium containing MP3 data is loaded, the unit checks all

the files on the medium. If the medium contains a lot of folders or

non-MP3 files, therefore, it takes a long time until the unit starts

playing MP3 files.

In addition, it may take time for the unit to move to the next MP3 file

or a file search or folder search may not be performed smoothly.

You should not write non-MP3 files or unneeded folders along with

MP3 files on the medium.

When playing MP3 files on a medium which also contains non-

MP3 files or folders, observe the following precautions. Loading

such a medium may produce loud noise to break the speakers.

· Do no attempt to play a medium containing a non-MP3 file

with the MP3 extension.

The unit mistakes non-MP3 files for MP3 files as long as they

have the MP3 extension.

· Do not attempt to play a medium containing non MP3 file.

2CAUTION
