Service
Manual
CD6000K/N1B/T1B
/N1G/T1G
R
CD6000 KI
255W855020 ACT
3120 785 22570
First Issue:2001.04
Printed in The Netherlands
CD6000
KI
CD6000
KI
CD Player
REMARK : This service manual explains the electrical differences between the
CD6000K/N1B/T1B/N1G/T1G (KI version) and CD6000F/N1B/T1B/N1G/T1G
(OSE version).
All other information is described in the service manual of the model
CD6000F/N1B/T1B/N1G/T1G (Code number : 3120 785 00060). The dispatch of
the parts for after sales service has to be referred to these service manuals, with
the first priority.
For this reason, please use these service manuals with referring to the model
CD6000 OSE service manual without fail.
The CD6000 KI is equal to the CD6000 OSE except the following electrical
changes (mechanical changes are not listed):
Position No.
Service code
Description
2131, 2132
9965 000 08117
3300uF 25V
2115, 2116,
4822 124 80123
220uF 16V Silmic
2223,2224,
2225,2226
2311, 2312,
4822 124 80958
470uF 16V Silmic
2316, 2317
5110
4822 146 10377
230V Transformer
3249, 3250,
--
Short circuited
3251,3252,
3711, 3712,
3713, 3714
Main PCB
