MITSUBISHI HD6000 Service Manual

Cover page of MITSUBISHI HD6000 Service Manual

Service Manual for MITSUBISHI HD6000, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 54 pages
  • File size: 5.8 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
CAUTION:
Before servicing this chassis, it is important that the service person read the "SAFETY PRECAUTIONS" and
"PRODUCT SAFETY NOTICE" contained in this manual.
· Design specifications are subject to change without notice.
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.
9351 Jeronimo Road, Irvine, CA 92618-1904
Copyright © 2005 Mitsubishi Digital Electronics America, Inc.
All Rights Reserved
MITSUBISHIELECTRIC Ser
Ser
Ser
Ser
Service
vice
vice
vice
vice
Manual
Manual
Manual
Manual
Manual
2005
2005
2005
2005
2005
SET TOP BOX
V26S CHASSIS
SPECIFICATIONS
· Power Input
: AC 120V, 60Hz
· Power Usage
: 82W
· Frequency Range
: VHF
54 ~ 470MHz
UHF 470 ~ 806MHz
Analog Cable - 1 ~ 125
Digital Cable - 1 ~ 135
· Antenna Input
: 2 RF 75
unbalanced
· Tuning
: 1 NTSC/ATSC/QAM
1 CableCARDTM Slot
1 NTSC for PIP
· Cabinet Dimensions
: 17"(W) x 3.4"(H) x 16.8"(D)
· Weight
: 27 lbs
· PVR
: 120 GB Hard Disc
Approx. 12 hrs HD Recording
72 hrs SD Recording
· Analog Input
: VIDEO IN JACK (RCA Type)
Levels
1.0Vp-p 75
unbalanced
: AUDIO IN JACK (RCA Type)
-4.7dBm 43k
unbalanced
: S-VIDEO IN JACK
(Y/C separate type)
Y:1.0 Vp-p C:0.286Vp-p(BURST)
75
unbalanced
: COMP / Y, Cr, Cb (RCA Type)
Y: 1.0 Vp-p Cr, Cb: 700mVp-p
: ATV / Y(G), Pr(R), Pb(B), H, V
Y: 1.0Vp-p with sync 75
(BNC)
Pr, Pb: 700mV 75
H, V: 3.0Vp-p 75
: VGA / R,G,B,V,H (15 pin D)
· Output Level
: VIDEO OUT JACK (RCA Type)
1.0Vp-p 75
unbalanced
: COMP / Y,Cr,Cb
Y: 1.0 Vp-p Cr, Cb: 700mVp-p
: AUDIO OUT JACK (RCA Type)
-4.7dBm 4.7k
unbalanced
· Digital
: IEEE-1394 I/O Jacks
Interface
: AC-3 Digtal Audio Output
: HDMITM Input/Output
: MonitorLinkTM Control/RS-232C
: CableCARDTM Slot
: NetCommand®
.
MODEL
HD-6000
background image
CAUTION:
Before servicing this chassis, it is important that the service person read the "SAFETY PRECAUTIONS" and
"PRODUCT SAFETY NOTICE" contained in this manual.
· Design specifications are subject to change without notice.
MITSUBISHI DIGITAL ELECTRONICS AMERICA, INC.
9351 Jeronimo Road, Irvine, CA 92618-1904
Copyright © 2005 Mitsubishi Digital Electronics America, Inc.
All Rights Reserved
MITSUBISHIELECTRIC Ser
Ser
Ser
Ser
Service
vice
vice
vice
vice
Manual
Manual
Manual
Manual
Manual
2005
2005
2005
2005
2005
SET TOP BOX
V26S CHASSIS
SPECIFICATIONS
· Power Input
: AC 120V, 60Hz
· Power Usage
: 82W
· Frequency Range
: VHF
54 ~ 470MHz
UHF 470 ~ 806MHz
Analog Cable - 1 ~ 125
Digital Cable - 1 ~ 135
· Antenna Input
: 2 RF 75
unbalanced
· Tuning
: 1 NTSC/ATSC/QAM
1 CableCARDTM Slot
1 NTSC for PIP
· Cabinet Dimensions
: 17"(W) x 3.4"(H) x 16.8"(D)
· Weight
: 27 lbs
· PVR
: 120 GB Hard Disc
Approx. 12 hrs HD Recording
72 hrs SD Recording
· Analog Input
: VIDEO IN JACK (RCA Type)
Levels
1.0Vp-p 75
unbalanced
: AUDIO IN JACK (RCA Type)
-4.7dBm 43k
unbalanced
: S-VIDEO IN JACK
(Y/C separate type)
Y:1.0 Vp-p C:0.286Vp-p(BURST)
75
unbalanced
: COMP / Y, Cr, Cb (RCA Type)
Y: 1.0 Vp-p Cr, Cb: 700mVp-p
: ATV / Y(G), Pr(R), Pb(B), H, V
Y: 1.0Vp-p with sync 75
(BNC)
Pr, Pb: 700mV 75
H, V: 3.0Vp-p 75
: VGA / R,G,B,V,H (15 pin D)
· Output Level
: VIDEO OUT JACK (RCA Type)
1.0Vp-p 75
unbalanced
: COMP / Y,Cr,Cb
Y: 1.0 Vp-p Cr, Cb: 700mVp-p
: AUDIO OUT JACK (RCA Type)
-4.7dBm 4.7k
unbalanced
· Digital
: IEEE-1394 I/O Jacks
Interface
: AC-3 Digtal Audio Output
: HDMITM Input/Output
: MonitorLinkTM Control/RS-232C
: CableCARDTM Slot
: NetCommand®
.
MODEL
HD-6000
background image
background image
MODEL: HD-6000
Page 3
INTRODUCTION ................................................................................................................................5
PRODUCT SAFETY NOTICE ............................................................................................................. 5
SAFETY PRECAUTIONS ................................................................................................................... 6
PWB-LOCATIONS ............................................................................................................................. 7
DISASSEMBLY .................................................................................................................................. 7
Disassembly Procedures Sequence ...................................................................................... 7
Top Cover removal .................................................................................................................. 8
HDD (Hard Drive) removal ....................................................................................................... 9
PWB'S removal ................................................................................................................... 10
ELECTRICAL ADJUSTMENTS ........................................................................................................ 11
Equipment .................................................................................................................................... 11
Option Menu / Initialization Defaults / AV Defaults ......................................................................... 12
LED Diagnostics ........................................................................................................................... 13
Remote Control Operational Mode ................................................................................................ 13
Circuit Adjustment Mode ............................................................................................................... 14
Transfering data ............................................................................................................................ 15
Adjustment Items List ................................................................................................................... 15
Adjustment Procedures ................................................................................................................ 16
Test Points .......................................................................................................................... 16
Main-Y Gain ......................................................................................................................... 16
Sub-Y Gain .......................................................................................................................... 17
Sub Picture Offset ............................................................................................................... 17
CHIP PARTS REPLACEMENT ......................................................................................................... 18
REPLACEMENT PARTS .................................................................................................................. 19
Parts Ordering .............................................................................................................................. 19
Critical and Warranty Parts Designation ........................................................................................ 19
Parts Tolerance Codes .................................................................................................................. 19
SERVICE PARTS LIST .................................................................................................................... 20
CIRCUITRY BLOCK DIAGRAMS ..................................................................................................... 29
Standby Power Supplies ............................................................................................................... 29
PWB-DM Power Supplies ............................................................................................................. 30
PWB-SIGNAL Switched Power Supplies ...................................................................................... 30
Video Select Circuitry ................................................................................................................... 31
Video Output Circuitry ................................................................................................................... 32
Sync Signal Selection ................................................................................................................... 33
Sync Signal Output Path .............................................................................................................. 34
Record Signal Path ....................................................................................................................... 34
Sound Signal Path ........................................................................................................................ 35
Control Circuitry ............................................................................................................................ 36
Command Input Circuitry ............................................................................................................... 37
Macrovision Detection ................................................................................................................... 37
PWB-DM Signal Path ................................................................................................................... 38
CONTENTS
background image
Page 4
MODEL: HD-6000
Part 2
Schematic Diagrams
CONTENTS
Page
SCHEMATIC DIAGRAMS
Overall PWB Interconnect Diagram ................................................................................................. 1
POWER / E2P / CONTROL / MV Decoder] .................................................................................... 2
TERMINAL-1 / TERMINAL-2 [Inputs / Outputs] ............................................................................... 3
SIGNAL-1 [Video Switch] ................................................................................................................ 4
SIGNAL-2 [Decoder / Switch] .......................................................................................................... 5
SIGNALS-3 [Micro} ......................................................................................................................... 6
SIGNAL-4 [TVGO] .......................................................................................................................... 7
SIGNAL-5 [MPEG Encoder] ............................................................................................................ 8
SIGNAL-6 [HDMI RX] ...................................................................................................................... 9
SIGNAL-7 [HDMI TX] ..................................................................................................................... 10
SIGNAL-8 [Video Output] ............................................................................................................. 11
SIGNAL-9 [IR232] ......................................................................................................................... 12
TUNER-1 [ATSC / NTSC Tuner] .................................................................................................... 13
TUNER-2 [Main ATSC / NTSC Demodulators] ............................................................................... 14
PWB LAYOUT DIAGRAMS .............................................................................................................. 15
background image
MODELS: HD-6000
Page 5
INTRODUCTION
This service manual provides service instructions for STB model HD-6000 which uses the V26S chassis. Service
personnel should read this manual thoroughly before servicing these chassis.
This service manual includes:
1. Safety Precautions
2. Assembly and disassembly instructions.
3. Servicing printed circuit boards (PCBs).
4. Electrical adjustments.
5. Chip parts replacement procedures.
6. Circuit path diagrams.
The parts list section of this service manual includes:
1. Cabinet and screen parts.
2. Electrical parts.
Schematic and block diagrams of the above listed models are included in this service manual for better understanding
of the circuitry. PCB drawings are also included for easy location of parts and test points.
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in television receivers have special safety related characteristics. These charac-
teristics are often not evident from visual inspection nor can the protection afforded by them necessarily be obtained by
using replacement components rated for higher voltage, wattage, etc.
Replacement parts which have special safety characteristics are identified in this service manual.
Electrical components having such features are identified by shading on the schematic diagrams and by bold type in
the parts list of this service manual. and by marking on the supplementary sheet for this chassis to be issued subse-
quently. The replacement for any safety part should be identical in value and characteristics.
