HT-S580
PACKING PROCEDURE-1
RECEIVER SECTION
A631
A631
A610
A601
(L & R)
A631
A656
A656
A631
A631
A626
A611
A625
A631
A812
A801
A802
A811
A820
A821
A690
A804
A805
A806
A809
A822
A845
A847
<R>
Front side
Right side
marking
Front side
marking
Left side
marking
Front side
marking
<L>
background image
HT-S580
PACKING PROCEDURE-1
RECEIVER SECTION
A631
A631
A610
A601
(L & R)
A631
A656
A656
A631
A631
A626
A611
A625
A631
A812
A801
A802
A811
A820
A821
A690
A804
A805
A806
A809
A822
A845
A847
<R>
Front side
Right side
marking
Front side
marking
Left side
marking
Front side
marking
<L>
background image
HT-S580
PACKING PROCEDURE-2
SPEAKER SECTION
BO
TT
OM
UP
CENTER
BO
TT
OM
SP05
SP04
SP03
SP06
SP05
SP07
SP05
SP05
SP07
SP02
SP01
Upper side
marking
Upper side
marking
Upper side
marking
SKC-330C
SKF-330F(L)
SKF-330F(R)
SK
M-330S(L)
SKM-330S(R)
SKW-330
Front side
background image
HT-S580
PACKING PROCEDURE-3
OVERALL
BO
TT
OM
UP
CEN
TER
BO
TT
OM
SP16
L = 15 ft.
(22# 4.5 m)
(White / Black)
SP17
L = 15 ft.
(22# 4.5 m)
(Red / Black)
SP19
L = 30 ft.
(22# 9 m)
(Blue / Black)
SP18
L = 10 ft.
(22# 3 m)
(Green / Black)
SP13
SP13
SP11a /
SP11b /
SP11c /
SP11d
SP15
L = 15 ft.
(22# 4.5 m)
(Purple / Black)
SP20
L = 30 ft.
(22# 9 m)
(Gray / Black)
SP05
SP12
SP21
(20 pcs.)
SP14
Front side
Refer to "PACKING PROCEDURE-1"
Refer to "PACKING PROCEDURE-2"
Front side
background image
1/2 PAGE
HT-S580
PACKING PROCEDURE PARTS LIST
<Notes>
<MDD> : USA model
<MDC> : Canadian model
<MWT> : World wide model
<MPP> : European model
RECEIVER SECTION (HT-R330)
REF. NO.
PART NAME
DESCRIPTION
Q'TY PART NO. (SN)
MARKS
PACKING
A601
PAD
(L & R / 1set)
1
29092278
PACKING
A610
POLY BAG
POLY BAG (850 x 650)
1
29100034-1A
PACKING
A611
SHEET
---
1
29095906
PACKING
A625
POLY BAG
350 x 250
1
29100097-1A
PACKING
A626
POLY BAG
350 x 250
1
29100097-1A
<MWT>
PACKING
A626
POLY BAG
350 x 250
1
29100097-1A
<MPP>
PACKING
A631
TAPE
NITTO NO.29 (Yellow)
(1)
29110149
PACKING
A656
LABEL
(DES), 2sheets
1
29364083
<MDD>
PACKING
A656
LABEL
(DES), 2sheets
1
29364084
<MDC>
PACKING
A656
LABEL
(DES), 2sheets
1
29364085
<MWT>
PACKING
A656
LABEL
(DES), 2sheets
1
29364164
<MPP>
PACKING
A690
SHEET
(SETUP)
1
29095987
<MDD>
PACKING
A690
SHEET
(SETUP)
1
29095987
<MDC>
PACKING
A690
SHEET
(SETUP)
1
29095991
<MWT>
PACKING
A690
SHEET
(SETUP)
1
29095991
<MPP>
PACKING
A801
INS MANUAL
U2FrEs (HT-R330)
1
29343955A
<MDC>
PACKING
A801
INS MANUAL
U2FrEs (HT-R330)
1
29343955A
<MPP>
PACKING
A802
INS MANUAL
Ct (HT-R330)
1
29343956
<MWT>
PACKING
A804
INS MANUAL
En (HT-R330)
1
29343977A
PACKING
A805
INS MANUAL
U2DeIt (HT-R330)
1
29344052
<MPP>
PACKING
A806
INS MANUAL
U2NlSv (HT-R330)
1
29344053
<MPP>
PACKING
A809
INST SHEET
U2 (En, Ct)
1
29355530
<MWT>
PACKING
A811
REMO CON
RC-606S
1
24140606
PACKING
A812
BATTERY
R6/AA (UM-3)
2
3010054
PACKING
A820
ANT COIL
NMA-3057
1
232140
PACKING
A821
FM ANT AS
D
1
292142
<MDD>
PACKING
A821
FM ANT AS
D
1
292142
<MDC>
PACKING
A821
FM ANT AS
Type W
1
292191
<MWT>
PACKING
A821
FM ANT AS
Type W
1
292191
<MPP>
PACKING
A822
CV PLUG
CV-K-1
1
25056005
<MWT>
PACKING
A845
WRNTY CARD
(ONKYO)
1
29365090C
<MDD>
PACKING
A845
WRNTY CARD
(ONKYO)
1
29365090C
<MDC>
PACKING
A847
HANDBILL
(DS-A1)
1
29380140
<MDD>
PACKING
A847
HANDBILL
(DS-A1)
1
29380140
<MDC>
SPEAKER SECTION (HTP-330)
REF. NO.
PART NAME
DESCRIPTION
Q'TY PART NO. (SN)
MARKS
PACKING
SP01
TOP POLYFOAM
---
1
ITF8303500002
PACKING
SP02
CENTER POLYFOAM
---
1
ITF8303500001
PACKING
SP03
BOTTOM POLYFOAM
---
1
ITF5305070002
PACKING
SP04
PO BAG
L860 x W650 x T0.015(For SUBWOOFER)
1
IVA803101-0022
background image
2/2 PAGE
PACKING
SP05
TAPE
NITTO NO.29 W18 (Yellow)
(1)
29110149
PACKING
SP06
PE BAG (MIRAMAT)
430L x 260W x 0.5T (For SKC)
1
IVA508016-0010
PACKING
SP07
PE BAG (MIRAMAT)
300L x 220W x 0.5T (For SKF/SKM)
4
IVA508016-0020
PACKING
SP11a
CARTON BOX
HT-S580(S) / MDD
1
ICC8S580SBM11
<MDD>
PACKING
SP11b
CARTON BOX
HT-S580(S) / MDC
1
ICC8S580SBM21
<MDC>
PACKING
SP11c
CARTON BOX
HT-S580(S) / MWT
1
ICC8S580SBM40
<MWT>
PACKING
SP11d
CARTON BOX
HT-S580(S) / MPP
1
ICC8S580SBM70
<MPP>
PACKING
SP12
MIRAMAT SHEET
L509 x W439 x T0.5 / WHITE
1
IVH802004-0023
PACKING
SP13
PP TAPE or
W50
(1)
29110071 or
PACKING
SP13
PP TAPE or
W48 OPP TAPE
(1)
29110148 or
PACKING
SP13
PP TAPE
NITTO 3703 SUPER W50L100
(1)
29110176
PACKING
SP14
POLY BAG
L250 x W180 x T0.025 (For CABLE)
1
IVA5020010130
PACKING
SP15
CABLE
22# 4.5m PURPLE / BLACK / POLYBAG
1
WMA8020010101
PACKING
SP16
CABLE
22# 4.5m WHITE / BLACK
1
VWS3301224500
PACKING
SP17
CABLE
22# 4.5m RED / BLACK
1
VWS3310224500
PACKING
SP18
CABLE
22# 3m GREEN / BLACK
1
VWS3309223000
PACKING
SP19
CABLE
22# 9m BLUE / BLACK
1
VWS3305229000
PACKING
SP20
CABLE
22# 9m GRAY / BLACK
1
VWS3307229000
PACKING
SP21
RUBBER FOOT
Dia.8 x 0.5T / 20 pcs. 1set
1
DUF5120010007
