ONKYO KEY-2.7 Service Manual

Cover page of ONKYO KEY-2.7 Service Manual

Service Manual for ONKYO KEY-2.7, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 20 pages
  • File size: 0.14 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
Keypad
KEY-2.7
Instruction Manual
background image
Keypad
KEY-2.7
Instruction Manual
background image
2
Precautions
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Never expose the unit to moisture.
7. Suitable only for use Indoors.
8. Only connect specified supply volt-
ages.
9. Connect only to the specified termi-
nals.
For U.S. models
FCC information for User
CAUTION:
The user changes or modifications not
expressly approved by the party responsible
for compliance could void the user's authority
to operate the equipment.
Note: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful inter-
ference in a residential installation.
For Canadian Models
NOTE: THIS CLASS B DIGITAL APPARA-
TUS COMPLIES WITH CANADIAN ICES-
003.
Modèle pour les Canadien
REMARGUE: CET APPAPEIL
NUMÉRIQUE DE LA CLASSE B EST
CONFORME À LA NORME NMB-003 DU
CANADA.
background image
3
Table of Contents
Precautions ..................................... 2
Introduction...................................... 3
Features .......................................... 4
Part Names and Function................ 5
Installation ....................................... 8
System Wiring ................................. 9
Manual Programming .................... 11
Troubleshooting............................. 14
Specifications ................................ 14
Thank you for purchasing an Integra KEY-2.7
keypad.
Please read this manual thoroughly before
making connections and plugging in the unit.
Following the instructions in this manual will
enable you to obtain optimum performance
from your new keypad.
Please retain this manual for future reference.
Introduction
The Integra KEY-2.7 keypad simply controls
and provides status feedback of source selec-
tion, power, mute and volume of an Integra
MZA-4.7 multi-zone amplifier.
The Keypad is programmed manually when
connected to the amplifier.
background image
4
Features
· Standby, Volume Up/Down and 6 Source select keys.
· 32 Source select key-caps providing a selection of Source select key labels.
· Integra Zone setup; 32 zones with Amp or Preamplifier definition.
·Toggling Amp/Preamplifier control function.
· IR receiver (May be defeated).
· Blue Source Select indicators - tracks the amplifier selection, indicates amplifier ON status.
·Volume Level indicated by a full color LED.
· RJ45 crimp plug connection for simple & reliable installation.
·A white cover plate is supplied as standard.
background image
5
Part Names and Function
-VOL
VOL+
Source Keys
Membrane
Keypad
IR Receiver
Chassis
Set Key
System LED &
Volume indicator
Key Cap bracket
