PIONEER A-509R/MY Service Manual

Cover page of PIONEER A-509R/MY Service Manual

Service Manual for PIONEER A-509R/MY, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 30 pages
  • File size: 1.92 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
c
RRV2285
1. SAFETY INFORMATION ...................................... 2
2. EXPLODED VIEWS AND PARTS LIST ............... 3
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..... 6
4. PCB CONNECTION DIAGRAM ......................... 16
5. PCB PARTS LIST ............................................... 21
6. ADJUSTMENT .................................................... 24
CONTENTS
7. GENERAL INFORMATION ................................ 25
7.1 IC .................................................................. 25
8. PANEL FACILITIES AND SPECIFICATIONS ....... 26
T ­ ZZK APR. 2000 Printed in Japan
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
STEREO AMPLIFIER
A-509R Direct Energy MOS
STANDBY/ON
STANDBY
OFF
ON
POWER
A
SPEAKERS
B
BASS
TREBLE
PHONES
LOUDNESS
MIN
MAX
VOLUME
DIRECT/
SB MODE
BALANCE
INPUT SELECTOR
REC SELECTOR
CD
TUNER
PHONO
TAPE 1/
CD-R/MD
LINE/
SB
TAPE 2
MONITOR
CD
TUNER
OFF
SOURCE
L
R
STEREO AMPLIFIER
A-509R
Type
Model
Power Requirement
Remarks
A-509R
MY
AC220-230V
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
c
RRV2285
1. SAFETY INFORMATION ...................................... 2
2. EXPLODED VIEWS AND PARTS LIST ............... 3
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..... 6
4. PCB CONNECTION DIAGRAM ......................... 16
5. PCB PARTS LIST ............................................... 21
6. ADJUSTMENT .................................................... 24
CONTENTS
7. GENERAL INFORMATION ................................ 25
7.1 IC .................................................................. 25
8. PANEL FACILITIES AND SPECIFICATIONS ....... 26
T ­ ZZK APR. 2000 Printed in Japan
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
STEREO AMPLIFIER
A-509R Direct Energy MOS
STANDBY/ON
STANDBY
OFF
ON
POWER
A
SPEAKERS
B
BASS
TREBLE
PHONES
LOUDNESS
MIN
MAX
VOLUME
DIRECT/
SB MODE
BALANCE
INPUT SELECTOR
REC SELECTOR
CD
TUNER
PHONO
TAPE 1/
CD-R/MD
LINE/
SB
TAPE 2
MONITOR
CD
TUNER
OFF
SOURCE
L
R
STEREO AMPLIFIER
A-509R
Type
Model
Power Requirement
Remarks
A-509R
MY
AC220-230V
