PIONEER AVH-P7800DVD/RE Service Manual

Cover page of PIONEER AVH-P7800DVD/RE Service Manual

Service Manual for PIONEER AVH-P7800DVD/RE, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 282 pages
  • File size: 34.35 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
AVH-P7800DVD/RE
CRT3682
MULTI-CD CONTROL DSP HIGH POWER DVD-A/DVD-V/VCD/CD/
MP3/WMA/AAC/DivX JPEG PLAYER WITH FM/AM TUNER
AVH-P7800DVD
/RE
AVH-P7850DVD/RC,RD,RI
This service manual should be used together with the following manual(s):
"DTS" and "DTS Digital Surround" are registered trademarks of Digital Theater Systems,Inc.
Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
Model No.
Order No.
Mech.Module
Remarks
CX-3183
CRT3655
MS4
DVD Mech. Module:Circuit Descriptions, Mech. Descriptions, Disassembly
For details, refer to "Important Check Points for Good Servicing".
K-ZZU. MAY 2006 Printed in Japan
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
AVH-P7800DVD/RE
CRT3682
MULTI-CD CONTROL DSP HIGH POWER DVD-A/DVD-V/VCD/CD/
MP3/WMA/AAC/DivX JPEG PLAYER WITH FM/AM TUNER
AVH-P7800DVD
/RE
AVH-P7850DVD/RC,RD,RI
This service manual should be used together with the following manual(s):
"DTS" and "DTS Digital Surround" are registered trademarks of Digital Theater Systems,Inc.
Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
Model No.
Order No.
Mech.Module
Remarks
CX-3183
CRT3655
MS4
DVD Mech. Module:Circuit Descriptions, Mech. Descriptions, Disassembly
For details, refer to "Important Check Points for Good Servicing".
K-ZZU. MAY 2006 Printed in Japan
background image
AVH-P7800DVD/RE
2
12
34
12
3
4
C
D
F
A
B
E
SAFETY INFORMATION
CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
1. Safety Precautions for those who Service this Unit.
· Follow the adjustment steps in the service manual when servicing this unit. When check -
ing or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable results.
Caution:
1. During repair or tests, minimum distance of 13 cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
2. The triangular label is attached to the mechanism
unit frame.
On the top of the player.
CAUTION :
VORSICHT :
ADVARSEL :
VARNING :
VARO!
:
VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN.
AVOID EXPOSURE TO BEAM.
SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG, WENN
ABDECKUNG GEÖFFNET NICHT DEM STRAHL AUSSETZEN!
SYNLIG OG USYNLIG LASERSTRÅLING VED ÅBNING
UNDGÅ UDSÆTTELSE FOR STRÀLING.
SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA
DEL ÄR ÖPPNAD BETRAKTA EJ STRÅLEN.
AVATTAESSA ALTISTUT NÄKYVÄ JA NÄKYMÄTTÖMÄLLE
LASERSATEIL YLLE. ÄLÄ KATSO SÄTEESEN.
VRW1860
background image
AVH-P7800DVD/RE
3
56
7
8
56
7
8
C
D
F
A
B
E
- Service Precautions
· You should conform to the regulations governing the product (safety, radio and noise, and other regulations),
and should keep the safety during servicing by following the safety instructions described in this manual.
· Be careful in handling ICs. Some ICs such as MOS type are so fragile that they can be damaged by electrostatic
induction.
- DVD section precaution
1. Before disassembling the unit, be sure to turn off
the power. Unplugging and plugging the connectors
during power-on mode may damage the ICs inside
the unit.
2. To protect the pickup unit from electrostatic discharge
during servicing, take an appropriate treatment
(shorting-solder) by referring to "the DISASSEMBLY" .
3. After replacing the pickup unit, be sure to skew
adjustment.
4. During disassembly, be sure to turn the power off since
an internal IC might be destroyed when a connector
is plugged or unplugged.
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replaced only with the same or equivalent type recommended by the manufacture.
Discord used batteries according to the manufacture's instructions.
WARNING!
The AEL (accessible emission level )of the laser power output is less than CLASS 1
but the laser component is capable of emitting radiation exceeding the limit for
CLASS 1.
A specially instructed person should do servicing operation of the apparatus.
Laser diode characteristics
Wave length:
DVD:640 nm to 660 nm
CD:770 nm to 810 nm
DVD : 2.48 mW(Emitting period :9 sec.)
CD : 705 W(Emitting period : unlimited)
Additional Laser Caution
Transistors Q1101 and Q1102 in PCB drive the laser diodes for DVD and CD
respectively. When Q1101 or Q1102 is shorted between their terminals,
the laser diodes for DVD or CD will radiate beam. If the top cover is removed
with no disc loaded while such short-circuit is continued, the naked eyes may
be exposed to the laser beam.
background image
AVH-P7800DVD/RE
4
12
34
12
3
4
C
D
F
A
B
E
H/U independent operation
Operation becomes possible even if there is no H/A, when it does in this way.
Since TUN is not connected, TUN sauce does not operate.
Please operate sauce by DVD, AUX, etc.
Short here
background image
AVH-P7800DVD/RE
5
56
7
8
56
7
8
C
D
F
A
B
E
Note) Button unit (CXC6641) is a non-reusable part. When repairing a PCB, repair without removing the button unit.
In case the button unit must be removed, do not reuse the removed button unit and use a new one.
For this product, the button unit, CXC6641, is designated as a non-reusable part because the hook part will come
off once the part is removed from the device.
When repairing the grill, repair without removing CXC6641.
A special technique will be required to install the PCB into the grill with CXC6641 mounted.
As shown in the picture below, assemble CXC9683 with the PCB beforehand. And insert the PCB into the grill by
holding CAC9683 and CXC6641 so that they will not drop off.
CXC6641
Insert into the grill while holding the parts.
Assemble CAC9683 beforehand as shown in the picture.
is a trademark of DVD Format/Logo Licensing Corporation.
