­ 1 ­
Thank you for buying this PIONEER product. Please read through these operating instructions
so you will know how to operate your unit properly. After you have finished reading the
instructions, put them away in a safe place for future reference.
BDR-202BK
BD/ DVD / CD WRITER
WARNING
This equipment is not waterproof. To prevent a fire or shock hazard, do not place any
container filled with liquid near this equipment (such as a vase or flower pot) or
expose it to dripping, splashing, rain or moisture.
D3-4-2-1-3_B_En
D3-4-2-1-1_ChK
D3-4-2-1-3_A_ChK
DVD Format/Logo Licensing Corporation
DVD
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
­ Reorient or relocate the receiving antenna.
­ Increase the separation between the equipment and receiver.
­ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
­ Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_En
IMPORTANT NOTICE ­ RECORD THE MODEL NUMBER AND SERIAL NUMBERS OF THIS EQUIPMENT BELOW.
THE NUMBERS ARE ON THE REAR.
MODEL NO.
SERIAL NO.
KEEP THESE NUMBERS FOR FUTURE USE.
D1-4-2-6-2_En
BDR-202BK
Machine Noise Information Regulation 3.
GPSGV: The highest sound-pressure level is
70 dB(A) or less in accordance EN ISO 7779.
Information to User
Alteration or modifications carried out without appropriate authorization may invalidate the user's right to operate
the equipment.
D8-10-2_En
Operating instructions
÷ Avoid touching or scratching the signal surface (shiny side) of the disc.
÷ Hold the disc by the edges or by the center hold and one edge.
÷ Do not affix paper or labels to the disc.
÷ Discard warped or cracked discs as they may cause damage to the
drive.
÷ Avoid specially shaped discs such as hearts or polygons.
background image
­ 1 ­
Thank you for buying this PIONEER product. Please read through these operating instructions
so you will know how to operate your unit properly. After you have finished reading the
instructions, put them away in a safe place for future reference.
BDR-202BK
BD/ DVD / CD WRITER
WARNING
This equipment is not waterproof. To prevent a fire or shock hazard, do not place any
container filled with liquid near this equipment (such as a vase or flower pot) or
expose it to dripping, splashing, rain or moisture.
D3-4-2-1-3_B_En
D3-4-2-1-1_ChK
D3-4-2-1-3_A_ChK
DVD Format/Logo Licensing Corporation
DVD
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
­ Reorient or relocate the receiving antenna.
­ Increase the separation between the equipment and receiver.
­ Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
­ Consult the dealer or an experienced radio/TV technician for help.
D8-10-1-2_En
IMPORTANT NOTICE ­ RECORD THE MODEL NUMBER AND SERIAL NUMBERS OF THIS EQUIPMENT BELOW.
THE NUMBERS ARE ON THE REAR.
MODEL NO.
SERIAL NO.
KEEP THESE NUMBERS FOR FUTURE USE.
D1-4-2-6-2_En
BDR-202BK
Machine Noise Information Regulation 3.
GPSGV: The highest sound-pressure level is
70 dB(A) or less in accordance EN ISO 7779.
Information to User
Alteration or modifications carried out without appropriate authorization may invalidate the user's right to operate
the equipment.
D8-10-2_En
Operating instructions
÷ Avoid touching or scratching the signal surface (shiny side) of the disc.
÷ Hold the disc by the edges or by the center hold and one edge.
÷ Do not affix paper or labels to the disc.
÷ Discard warped or cracked discs as they may cause damage to the
drive.
÷ Avoid specially shaped discs such as hearts or polygons.
background image
­ 2 ­
D3-4-2-1-8_B_ChK
CAUTION
CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN, AVOID EXPOSURE TO THE BEAM.
VORSICHT
BEI GEÖFFNETER ABDECKUNG IST SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG DER KLASSE 3B IM GERÄTEINNEREN
VORHANDEN. NICHT DEM LASERSTRAHLAUSSETZEN!
(PBDE)
(PBB)
(Cr6+)
(Cd)
(Hg)
(Pb)
2006 2 28
SJ/T11364-2006
SJ/T11363-2006
SJ/T11363-2006
CAUTION : USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
CAUTION : THE USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE HAZARD. D6-8-2-1_En
This product complies with the EMC Directive
2004/108/EC.
D3-4-2-1-9b_A_En
CAUTION
This product is a class 1 laser product, but this product contains a laser diode higher than Class 1.
To ensure continued safety, do not remove any covers or attempt to gain access to the inside of the product.
Refer all servicing to qualified personnel.
The following caution label appears on your unit.
Location: on top of the cover
D3-4-2-1-8_B_En
CAUTION
CLASS 3B VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN, AVOID EXPOSURE TO THE BEAM.
VORSICHT
BEI GEÖFFNETER ABDECKUNG IST SICHTBARE UND UNSICHTBARE LASERSTRAHLUNG DER KLASSE 3B IM GERÄTEINNEREN
VORHANDEN. NICHT DEM LASERSTRAHLAUSSETZEN!
DANGER ­ VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID DIRECT
EXPOSURE TO BEAM.
/
(
/
)
/
background image
­ 3 ­
SAFETY INSTRUCTIONS
To ensure your personal safety and to maximize the full operating potential of your Drive, read and
follow these safety precautions:
ENVIRONMENT - Please do not use the unit in places with high levels of dust, high temperature,
or high humidity. Please use the unit in a place where it is not subjected to vibrations or shocks.
POWER - Before installing the unit on the system, be sure to turn off power on the system and
remove the power cord from the AC outlet.
READ INSTRUCTIONS - Read all safety and operating instructions before the Drive is operated.
RETAIN INSTRUCTIONS - Retain the safety and operating instructions for future reference.
FOLLOW INSTRUCTIONS - Follow all operating and use instructions.
HEED WARNINGS - All warnings must be adhered to.
CLEANING - DO NOT use liquid, aerosol cleaners, or alcohol. Use only a damp cloth to clean the
exterior housing.
WATER AND MOISTURE - DO NOT use this product near water.
POWER SOURCES - Operate this product from the type of power source indicated on the marking
label. If you are not sure of the type of power available, consult Authorized Pioneer Dealer.
OVERLOADING - DO NOT overload wall outlets and extension cords. Doing so may result in fire
or electric shock.
OBJECT AND LIQUID ENTRY - Never push objects of any kind into this product. Touching dangerous
voltage points may cause a short resulting in fire or electric shock. Do not spill liquid of any kind on
this product.
CONDENSATION - Moisture will form in the operating section of the product causing performance
to be impaired if it is brought from cool surroundings into a warmer environment. If you are moving
the unit to a location with a warmer temperature, let the product stand for 1-2 hours in the new
location before turning it back on.
SERVICING - Do not attempt to repair this product yourself. Opening or removing covers may
expose you to dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
(Refer to the enclosed Service and Support Card.)
÷ Remove dust or lint from the disc with a soft cloth by wiping
from the inside to the outside edge rather than in a circular
motion.
÷ Do not use record-cleaning or anti-static agents as the solutions
may cause damage to a disc.
Always be sure to store your discs in proper disc storage cases when not in use, and
always be sure to check for dirt or dust on discs (especially on the recording side) before
use.
background image
­ 4 ­
FEATURES
· Maximum Write Speed (
L : ZCLV )
BD-R
4X
BD-RE
2X
DVD-R
1X, 2X, 4X, 6X, 8XL, 12XL
DVD-R DL
2X, 4X
DVD-RW
1X, 2X, 4X, 6X
DVD+R
2.4X, 4X, 6X, 8XL, 12XL
DVD+R DL
2.4X, 4X
DVD+RW
2.4X, 3.3X, 4X, 6X
DVD-RAM
2X, 3X, 5X
CD-R
4X, 10X, 16X, 24XL
CD-RW
4X, 10X, 16X, 24XL
· Maximum Read Speed
BD-ROM (single)
5X CAV
BD-ROM (dual)
2X CLV
BD-R
5X CAV
BD-RE
5X CAV
DVD-ROM (single)
12X CAV
DVD-ROM (dual)
8X CAV
DVD-R, DVD+R
12X CAV
DVD-R DL, DVD+R DL
8X CAV
DVD-RW, DVD+RW
8X CAV
DVD-RAM
5X ZCLV
CD-ROM, CD-R
32X CAV
CD-RW
24X CAV
· Buffer Memory Size : 4 M Bytes (Write, Read)
· Serial ATA Data Transfer : Conferming to Serial ATA Revision 1.0a
· 5.25inch Half-Height built in type
· LCD Tilt Servo Mechanism
· Horizontal/Vertical orientation available
· Low vibration Mechanism by DRA system
Disc Format (Read/Write)
· BD-ROM single layer/dual layer
· Single layer BD-R(Version 1.1)
· Single layer BD-RE(Version 2.1)
· DVD single layer/dual layer /120 mm disc /80 mm disc
· DVD-R (In case of write, 650nm disc for General only.)
· DVD-R (4X, 8X,16X Write Speed)
· DVD-R DL
· DVD-RW (1X, 2X, 4X, 6X Write Speed)
· DVD+R (2.4X, 4X, 8X, 16X Write Speed)
· DVD+R DL
· DVD+RW (2.4X, 4X, 8X Write Speed)
· DVD-RAM (Ver 2.0, 2.1, 2.2(RAM2 Read Only)) (Non-Cartridge)
· CD-ROM Mode 1
· CD-ROM XA Mode2 (form 1, form2)
· Photo CD (single and multiple session)
· CD-DA
· CD-Extra (CD PLUS)
· Video CD
· CD Text
· CD-R
· CD-RW, HS CD-RW, US CD-RW, US+ CD-RW
Notes:
· Specific application program(s) that support above format(s) required.
· Supported media required for specific BD, DVD & CD writing speeds.
·
L ZCLV
BD-R
4X
BD-RE
2X
DVD-R
1X, 2X, 4X, 6X, 8XL, 12XL
DVD-R DL
2X, 4X
DVD-RW
1X, 2X, 4X, 6X
DVD+R
2.4X, 4X, 6X, 8XL, 12XL
DVD+R DL
2.4X, 4X
DVD+RW
2.4X, 3.3X, 4X, 6X
DVD-RAM
2X, 3X, 5X
CD-R
4X, 10X, 16X, 24XL
CD-RW
4X, 10X, 16X, 24XL
·
BD-ROM
5X CAV
BD-ROM
2X CLV
BD-R
5X CAV
BD-RE
5X CAV
DVD-ROM
12X CAV
DVD-ROM
8X CAV
DVD-R, DVD+R
12X CAV
DVD-R DL, DVD+R DL
8X CAV
DVD-RW, DVD+RW
8X CAV
DVD-RAM
5X ZCLV
CD-ROM, CD-R
32X CAV
CD-RW
24X CAV
·
4 M Bytes
/
·
ATA
ATA Revision 1.0a
·
5.25
·
·
/
·
DRA
/
·
BD-ROM
/
·
BD-R(Version 1.1)
·
BD-RE(Version 2.1)
·
DVD
/
/120 mm/80 mm
·
DVD-R
650 nm
·
DVD-R
4X, 8X, 16X
·
DVD-R DL
·
DVD-RW
1X, 2X, 4X, 6X
·
DVD+R
2.4X, 4X, 8X, 16X
·
DVD+R DL
·
DVD+RW
2.4X, 4X, 8X
·
DVD-RAM
Ver 2.0, 2.1, 2.2
RAM2
·
CD-ROM Mode 1
·
CD-ROM XA Mode2
1
2
·
Photo CD
·
CD-DA
·
CD-Extra (CD PLUS)
·
Video CD
·
CD Text
·
CD-R
·
CD-RW, HS CD-RW, US CD-RW, US+ CD-RW
·
·
DVD, CD
background image
­ 5 ­
Adaptec
ASH-1205SA
SiI3112
macPower
MP-PCI-SATA
SiI3112
PROMISE
SATAII 150 TX2plus
PDC20575
SATAII 150 TX4
PDC40518
SIIG
SC-SAE012-S1
SiI3132
kuroutoshikou
SATA 4P-PCI
SiI3114
Adaptec
SATA RAID 1210SA
SiI3112
High Point
RocketRAID 1520
HP372A+Marvell 8030
I-O DATA
SA-PCI/2R
SiI3112
System TALKS
SATA-HD150C
SiI3112
kuroutoshikou
SATA II 64BIT
SiI3124
ABIT
AI7
ICH5R
AB9
ICH8
JMB363
KV8-MAX3
SiI3114RAID
Aopen
n250a-FR
nForce3 250
SiI3114RAID
ASRock
939Dual-SATA2
ULI M1567
ASUSTek
P4C800 Deluxe
ICH5
P5AD2 Deluxe
ICH6R
P5WD2 Premium
ICH7R
P5B-Deluxe
ICH8R
A8V-VM
VIA VT8251
K8N-E Deluxe
nForce3 250
SiI3114RAID
A8N32-SLI Deluxe
nForce4 SLI
DFI
662-TMG/G
SIS966
GIGABYTE
GA-8I945G Pro
ICH7R
GA-K8N SNXP
nForce3 250
K8N Pro-SLI
nForce4 SLI
GA-M59SLI-S5
nForce590 SLI
GA-K8U-939
ULI M1689
Intel
D925XCV-LK
ICH6R
D955XBK
ICH7R
DP965LT
ICH8
MSI
K8N Neo2 Platinum
nForce3 Ultra
RS480M2-IL
ATI SB400
(SiI3112A)
P4N-Diamond
nForce4 SLI Intel Edition
SiI3132
WinFast
6150K8MA
nForce430 MCP

Reviews

There are no reviews of this manual yet.

Related Products

Cover page of PIONEER KEH-P580X1M Service Manual

This manual has 55 pages, file size: 3.32 MB. It's available in languages: English.

Cover page of PIONEER DEH-P2650ES Service Manual

This manual has 70 pages, file size: 4.34 MB. It's available in languages: English.

Cover page of PIONEER VSX-418-S/MYSXJ5 Owner's Manual

This manual has 82 pages, file size: 2.14 MB. It's available in languages: Swedish, French, English, Russian, Spanish, Dutch, German, Danish, Italian, Turkish, Norwegian, Finnish.

Cover page of PIONEER RX-530 Service Manual

This manual has 33 pages, file size: 15.63 MB. It's available in languages: English.

Cover page of PIONEER S-FCR02/XJI/CN Owner's Manual

This manual has 4 pages, file size: 0.81 MB. It's available in languages: Chinese Traditional.
