PIONEER CD-PC1/ES Service Manual

Cover page of PIONEER CD-PC1/ES Service Manual

Service Manual for PIONEER CD-PC1/ES, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 13 pages
  • File size: 0.65 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001
K-ZZS. JULY 2001 Printed in Japan
ORDER NO.
CRT2738
PC LINK KIT
CD-PC1
ES
Service
Manual
- For operation verification, use either of the detachable front panels for the car stereos listed below:
DEH-P9350/ES
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................2
3. SCHEMATIC DIAGRAM .............................................6
4. PCB CONNECTION DIAGRAM ..................................8
5. ELECTRICAL PARTS LIST ........................................10
6. ADJUSTMENT..........................................................11
7. GENERAL INFORMATION .......................................11
8. OPERATIONS AND SPECIFICATIONS.....................12
background image
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001
K-ZZS. JULY 2001 Printed in Japan
ORDER NO.
CRT2738
PC LINK KIT
CD-PC1
ES
Service
Manual
- For operation verification, use either of the detachable front panels for the car stereos listed below:
DEH-P9350/ES
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................2
3. SCHEMATIC DIAGRAM .............................................6
4. PCB CONNECTION DIAGRAM ..................................8
5. ELECTRICAL PARTS LIST ........................................10
6. ADJUSTMENT..........................................................11
7. GENERAL INFORMATION .......................................11
8. OPERATIONS AND SPECIFICATIONS.....................12
background image
2
CD-PC1
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
2
7
8
3
5
9
9
4
6
11
10
1
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so
and refer the repair to a qualified service technician.
background image
CD-PC1
3
1-1 Owner's Manual
CZR3221
1-2 Owner's Manual
CZR3222
1-3 Owner's Manual
CZR3227
*
1-4 Caution Card
CZR3232
*
1-5 Label
CZR3235
2 Polyethylene Bag
CZE3171
3 Carton
CZH6211
4 Contain Box
CZH6212
>
5 AC Cord
ADG7003
6 RS232C Cable(Straight)
CZD6031
>
7 AC Adapter
CZE3271
8 Board
CZH6203
*
9 Board
CZH6206
10 Spacer
CZH6213
11 CD-ROM
CZR3229
Mark No. Description
Part No.
Mark No. Description
Part No.
- PACKING SECTION PARTS LIST
NOTE:
- Parts marked by "*" are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to
mark on the product are used for disassembly.
- The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore,
when replacing, be sure to use parts of identical designation.
- Owner's Manual
Model
Part No.
Language
CD-PC1/ES
CZR3221
English
CZR3222
Spanish
CZR3227
Portuguese(B)
background image
4
CD-PC1
10
2
10
10
10
2
2
2
2
2
21
21
12
19
19
16
22
23
18
17
24
15
20
14
7
6
9
11
3
4
5
7
6
9
13
1
8
2.2 EXTERIOR
background image
CD-PC1
1 Screw
BPZ26P080FZK
2 Screw
BSZ26P060FZK
3 Connector(CN3)
CKS4436
4 PCB
CNP6124
5 Cover
CNV6573
6 Screw
CZB2041
7 Spring
CZB2042
8 Holder
CZN7682
9 Hook
CZN7685
10 Foot
CZN7686
11 Case
CZN7688
12 Chassis
CZN7689
13 Stopper
CZN7691
14 PCB Unit
CZW6032
15 Screw
BSZ26P080FMC
16 Connector(CN4)
CKS1568
17 Jack(CN2)
CKS2577
18 Connector(CN1)
CZD6033
19 LED Spacer
CZE3277
20 Bracket
CZN7687
21 Screw
PMZ30P080FMC
22 LED(D3)
SLR-332DU
23 LED(D5)
SLR-332MG
24 IC(IC2)
NJM78M05FA
- EXTERIOR SECTION PARTS LIST
Mark No. Description
Part No.
Mark No. Description
Part No.
5
