Operating Instructions

COMPACT DISC PLAYER

CMX-5000

Operating Instructions

COMPACT DISC PLAYER

CMX-5000

2 <DRB1254>

READ INSTRUCTIONS -- All the safety and operating

instructions should be read before the product is

operated.

RETAIN INSTRUCTIONS -- The safety and operating

instructions should be retained for future reference.

HEED WARNINGS -- All warnings on the product and in

the operating instructions should be adhered to.

FOLLOW INSTRUCTIONS -- All operating and use

instructions should be followed.

CLEANING -- Unplug this product from the wall outlet

before cleaning. The product should be cleaned only

with a polishing cloth or a soft dry cloth. Never clean

with furniture wax, benzine, insecticides or other

volatile liquids since they may corrode the cabinet.

ATTACHMENTS -- Do not use attachments not

recommended by the product manufacturer as they

may cause hazards.

WATER AND MOISTURE -- Do not use this product near

water -- for example, near a bathtub, wash bowl,

kitchen sink, or laundry tub; in a wet basement; or

near a swimming pool; and the like.

ACCESSORIES -- Do not place this product on an

unstable cart, stand, tripod, bracket, or table. The

product may fall, causing serious injury to a child or

adult, and serious damage to the product. Use only

with a cart, stand, tripod, bracket, or table

recommended by the manufacturer, or sold with the

product. Any mounting of the product should follow

the manufacturer's instructions, and should use a

mounting accessory recommended by the

manufacturer.

CART -- A product and cart combination should be moved

with care. Quick stops, excessive force, and uneven

surfaces may cause the product and cart combination

to overturn.

VENTILATION -- Slots and openings in the cabinet are

provided for ventilation and to ensure reliable

operation of the product and to protect it from

overheating, and these openings must not be blocked

or covered. The openings should never be blocked

by placing the product on a bed, sofa, rug, or other

similar surface. This product should not be placed in

a built-in installation such as a bookcase or rack unless

proper ventilation is provided or the manufacturer's

instructions have been adhered to.

POWER SOURCES -- This product should be operated

only from the type of power source indicated on the

marking label. If you are not sure of the type of power

supply to your home, consult your product dealer or

local power company.

LOCATION -- The appliance should be installed in a stable

location.

NONUSE PERIODS -- The power cord of the appliance

should be unplugged from the outlet when left unused

for a long period of time.

WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

IMPOTANT SAFETY INSTRUCTIONS

GROUNDING OR POLARIZATION

If this product is equipped with a polarized alternating

current line plug (a plug having one blade wider than

the other), it will fit into the outlet only one way. This

is a safety feature. If you are unable to insert the plug

fully into the outlet, try reversing the plug. If the plug

should still fail to fit, contact your electrician to replace

your obsolete outlet. Do not defeat the safety purpose

of the polarized plug.

If this product is equipped with a three-wire grounding

type plug, a plug having a third (grounding) pin, it will

only fit into a grounding type power outlet. This is a

safety feature. If you are unable to insert the plug

into the outlet, contact your electrician to replace your

obsolete outlet. Do not defeat the safety purpose of

the grounding type plug.

POWER-CORD PROTECTION -- Power-supply cords

should be routed so that they are not likely to be

walked on or pinched by items placed upon or against

them, paying particular attention to cords at plugs,

convenience receptacles, and the point where they

exit from the product.

OUTDOOR ANTENNA GROUNDING -- If an outside

antenna or cable system is connected to the product,

be sure the antenna or cable system is grounded so

as to provide some protection against voltage surges

and built-up static charges. Article 810 of the National

Electrical Code, ANSI/NFPA 70, provides information

with regard to proper grounding of the mast and

supporting structure, grounding of the lead-in wire to

an antenna discharge unit, size of grounding

conductors, location of antenna-discharge unit,

connection to grounding electrodes, and requirements

for the grounding electrode. See Figure A.

LIGHTNING -- For added protection for this product

during a lightning storm, or when it is left unattended

and unused for long periods of time, unplug it from

the wall outlet and disconnect the antenna or cable

system. This will prevent damage to the product due

to lightning and power-line surges.

POWER LINES -- An outside antenna system should not

be located in the vicinity of overhead power lines or

other electric light or power circuits, or where it can

fall into such power lines or circuits. When installing

an outside antenna system, extreme care should be

taken to keep from touching such power lines or

circuits as contact with them might be fatal.

OVERLOADING -- Do not overload wall outlets,

extension cords, or integral convenience receptacles

as this can result in a risk of fire or electric shock.

OBJECT AND LIQUID ENTRY -- Never push objects of

any kind into this product through openings as they

may touch dangerous voltage points or short-out parts

that could result in a fire or electric shock. Never spill

liquid of any kind on the product.

SERVICING -- Do not attempt to service this product

yourself as opening or removing covers may expose

you to dangerous voltage or other hazards. Refer all

servicing to qualified service personnel.

DAMAGE REQUIRING SERVICE -- Unplug this product

from the wall outlet and refer servicing to qualified

service personnel under the following conditions:

÷ When the power-supply cord or plug is damaged.

÷ If liquid has been spilled, or objects have fallen into

the product.

÷ If the product has been exposed to rain or water.

÷ If the product does not operate normally by following

the operating instructions. Adjust only those controls

that are covered by the operating instructions as an

improper adjustment of other controls may result in

damage and will often require extensive work by a

qualified technician to restore the product to its normal

operation.

÷ If the product has been dropped or damaged in any

way.

÷ When the product exhibits a distinct change in

performance -- this indicates a need for service.

REPLACEMENT PARTS -- When replacement parts are

required, be sure the service technician has used

replacement parts specified by the manufacturer or

have the same characteristics as the original part.

Unauthorized substitutions may result in fire, electric

shock, or other hazards.

SAFETY CHECK -- Upon completion of any service or

repairs to this product, ask the service technician to

perform safety checks to determine that the product

is in proper operating condition.

HEAT -- The product should be situated away from heat

sources such as radiators, heat registers, stoves, or

other products (including amplifiers) that produce heat.

NEC NATIONAL ELECTRICAL CODE

ANTENNA

LEAD IN WIRE

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810 20)

GROUNDING CONDUCTORS

(NEC SECTION 810 21)

GROUND CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

GROUND

CLAMP

ELECTRIC

SERVICE

EQUIPMENT

FIG. A

CAUTION

÷ Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation

exposure.

÷ The use of optical instruments with this product will increase eye hazard.

IMPORTANT

The lightning flash with arrowhead symbol, within an

equilateral triangle, is intended to alert the user to the

presence of uninsulated "dangerous voltage" within the

product's enclosure that may be of sufficient magnitude

to constitute a risk of electric shock to persons.

The exclamation point within an equilateral triangle is

intended to alert the user to the presence of important

operating and maintenance (servicing) instructions in

the literature accompanying the appliance.

CAUTION:

TO PREVENT THE RISK OF ELECTRIC SHOCK, DO

NOT REMOVE COVER (OR BACK).

NO USER-

SERVICEABLE PARTS INSIDE. REFER SERVICING TO

QUALIFIED SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

Thank you for buying this Pioneer product.

Please read through these operating instructions so you will know how to operate your model properly.

After you have finished reading the instructions, put them away in a safe place for future reference.

Read before use

Want You

LISTENING

For A Lifetime

·A

S O C I A TIO

C IND

EST

1924

Want You

LISTENING

For A Lifetime

·A

S O C I A TIO

C IND

EST

1924

[For Canadian model]

This Class B digital apparatus complies with Canadian

ICES-003.

[Pour le modèle Canadien]

Cet appareil numérique de la Classe B est conforme à la

norme NMB-003 du Canada.

Information to User

Alteration or modifications carried out without

appropriate authorization may invalidate the user's right

to operate the equipment.

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the

FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in

accordance with the instructions, may cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to

try to correct the interference by one or more of the following measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

Selecting fine audio equipment such as the unit you've just

purchased is only the start of your musical enjoyment. Now it's time

to consider how you can maximize the fun and excitement your

equipment offers. This manufacturer and the Electronic Industries

Association's Consumer Electronics Group want you to get the most

out of your equipment by playing it at a safe level. One that lets the

sound come through loud and clear without annoying blaring or

distortion-and, most importantly, without affecting your sensitive

hearing.

Sound can be deceiving. Over time your hearing "comfort level"

adapts to higher volumes of sound. So what sounds "normal" can

actually be loud and harmful to your hearing. Guard against this by

setting your equipment at a safe level BEFORE your hearing adapts.

To establish a safe level:

÷ Start your volume control at a low setting.

÷ Slowly increase the sound until you can hear it comfortably and

clearly, and without distortion.

Once you have established a comfortable sound level:

÷ Set the dial and leave it there.

Taking a minute to do this now will help to prevent hearing damage

or loss in the future. After all, we want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will provide a lifetime of

fun and enjoyment. Since hearing damage from loud noise is often

undetectable until it is too late, this manufacturer and the Electronic

Industries Association's Consumer Electronics Group recommend

you avoid prolonged exposure to excessive noise. This list of sound

levels is included for your protection.

Quiet library, soft whispers

Living room, refrigerator, bedroom away from traffic

Light traffic, normal conversation, quiet office

Air conditioner at 20 feet, sewing machine

Vacuum cleaner, hair dryer, noisy restaurant

Average city traffic, garbage disposals, alarm clock

at two feet.

Decibel

Level

Example

THE FOLLOWING NOISES CAN BE DANGEROUS

UNDER CONSTANT EXPOSURE

Subway, motorcycle, truck traffic, lawn mower

100

Garbage truck, chain saw, pneumatic drill

120

Rock band concert in front of speakers, thunderclap

140

Gunshot blast, jet plane

180

Rocket launching pad

Information courtesy of the Deafness Research Foundation.

CAUTION: This product satisfies FCC regulations when

shielded cables and connectors are used to connect the unit to

other equipment. To prevent electromagnetic interference with

electric appliances such as radios and televisions, use shielded

cables and connectors for connections.

IMPORTANT NOTICE

The serial number for this equipment is located on the rear

panel. Please write this serial number on your enclosed warranty

card and keep it in a secure area. This is for your security.

[For Canadian model]

CAUTION: TO PREVENT ELECTRIC SHOCK DO NOT USE

THIS (POLARIZED) PLUG WITH AN EXTENSION CORD.

RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN

BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.

ATTENTION: POUR PREVENIR LES CHOCS ELECTRIQUES

NE PAS UTILISER CETTE FICHE POLARISEE AVEC UN

PROLONGATEUR UNE PRISE DE COURANT OU UNE AUTRE

SORTIE DE COURANT, SAUF SI LES LAMES PEUVENT ETRE

INSEREES A FOND SANS EN LAISSER AUCUNE PARTIE A

DECOUVERT.

Read before use

4 <DRB1254>

CAUTIONS REGARDING HANDLING

Location

Install the player in a well-ventilated location where it will not be

exposed to high temperatures or humidity.

Do not install the player in a location which is exposed to direct

sunlight, or near stoves or radiators. Excessive heat can

adversely affect the cabinet and internal components.

Installation of the player in a damp or dusty environment may

aiso result in a malfunction and can be hazardous. Avoid

installation near cookers etc., where the player may be exposed

to oily smoke, steam or heat.

Installation guidelines

÷ Placing and using the compact disc player for long periods on

heat-generating sources such as amplifiers or near

spotlights, etc. will affect product performance. Avoid placing

the player on heat-generating sources.

÷ Install this compact disc player as far as possible away from

tuners and TV sets. A compact disc player installed in close

proximity to such equipment may cause noise or degradation

of the picture.

÷ Noise may be noticeable when an indoor antenna is used. In

such cases, make use of an outdoor antenna or turn off

power to the compact disc player.

÷ When the unit is used in a loud-sound environment, e.g., near

a speaker, sound skip may occur. Install the unit away from

the speaker or reduce the listening volume.

÷ Place this unit on a level surface and a stable platform.

÷ Be sure the player, including its audio and power supply

cords, does not touch vibrating materials. Any cause of

vibration other than the insulators may cause the disc to skip.

Take special care when using the player while it is installed in

a carrying case.

Installing the CMX-5000 in an EIA rack

The screw holes on the front panel o the CMX-5000 are

designed for use in attaching the unit to a 19-inch EIA rack.

÷ Remove the four legs on the unit before installing the unit in

the rack.

÷ Use four 3/16-inch-diameter, 3/8-inch-length screws to attach

to rack. (Screws not included with CMX-5000 CD player.)

Note

÷ Never place this CD player directly above a power amplifier,

as the heat given off by the amplifier might result in damage

to the unit. Placing the CD player directly above a power

amplifier might also result in ham radio signals being picked

up or in other types of interference.

÷ Always be sure to remove the CD player from its rack before

shipping.

÷ When moving the CD player while still installed in its rack,

exercise caution to avoid subjecting the player to shocks or

vibration.

Cleaning the player

To clean the PLAYER wipe with a polishing or a soft, dry cloth.

For stubborn dirt, moisten a soft cloth with a weak solution of

neutral detergent (diluted in five to six parts water), wring the

cloth well, and wipe away the dirt. Use a dry cloth to wipe the

surface dry. Do not use volatile liquids such as benzene or

thinner which will damage to the unit.

CD lens cleaner

The player's pickup lens should not become dirty in normal use.

If for some reason, the lens becomes soiled and malfunctions,

contact your nearest PIONEER authorized service center. Lens

cleaners for CD players are commercially available, but special

care should be exercised in their use as some may cause

damage to the lens.

Storing discs

÷ Discs are made of the same kinds of plastic used for

conventional analog audio records. Be careful not to allow

discs to warp. Always store discs in their cases vertically,

avoiding locations with high heat, humidity, or extremely low

temperatures. Avoid leaving discs in cars; the interior of a car

in direct sunlight can become extremely hot.

÷ Always read and abide by the precautionary notes listed on

disc labels.

Condensation

When this unit is brought into a warm room from previously cold

surroundings or when the room temperature rises sharply,

condensation may form inside the unit and impair its

performance. In such cases, allow the unit to stand for about an

hour or raise the room temperature gradually.

Read before use

Do not place on or against

vibrating materials!

Do not play a CD with a special shape

Do not play a CD having other shape than a circular disc, such as

heart shaped disc. Otherwise malfunction may occur.

FORCED DISC EJECTION

If the EJECT button fails to work and it becomes impossible

to eject a disc, the disc may be ejected by inserting the disc

ejection pin in the manual disc ejection hole located on the

front panel of the player.

Always be sure to observe the following points when

manually ejecting discs.

1 Be sure to turn off the power to the CD player and wait

for 1 minute or more before ejecting the disc.

Manually ejecting a disc immediately after the

power to the unit has been turned off may

result in one of the following problems from

occurring, and care should accordingly be

taken never to eject discs immediately after the

power has been turned off.

÷ The disc will still be spinning when it is ejected, thus

resulting in cuts to the fingers or other forms of bodily

injury.

÷ The disc clamps will spin in an unstable state, thus

resulting in scratching of discs.

2 Be sure to use only the disc ejection pin included with

your CMX-5000 (i.e., never use a paper clip or any other

object).

Inserting the disc ejection pin into the hole until it

encounters resistance will cause the disc to be ejected

some 5 to 10 millimeters from the insertion slot. The

disc may then be removed by grasping it by hand and

pulling.

Read before use

EJE

DIS

PLA

A·B

DIO

-OU

T S

ELE

MONITOR

MIN

MAX

PHONES

A·B

MIX PLA

YER

SELECT

Manual

disc ejection hole

÷ If a disc becomes very dirty, dampen a soft cloth with water,

(be sure to wring it out well) and wipe the away dirt gently.

Remove any water drops with another soft, dry cloth.

÷ Do not use record cleaning sprays or anti-static agents on

discs. Never clean discs with benzene, thinner, or other

volatile solvents or damage to the disc surface may result.

÷ With this player, use only those discs

which display the mark shown right

(Optical audio digital discs).

÷ When holding discs, do not touch their signal surfaces. Hold

by the edges, or by one edge and the center hole.

÷ Do not affix gummed labels or tape to the disc surface. Also,

do not scratch or damage the label.

÷ Discs rotate at high speeds inside the player. Do not use

damaged, cracked or warped discs.

Cleaning and handling compact discs

÷ The presence of fingerprints or smudges on the surface of

the disc will not directly affect the recorded signals, but,

depending on the degree of contamination, the brightness of

the light reflected from the signal surfaces may be reduced

causing degradation of sound quality. Always keep your discs

clean by wiping them gently with a soft cloth from the inner

edge toward the outer edge.

Reviews

There are no reviews of this manual yet.

Related Products

Cover page of PIONEER DEH-P3500-2 Service Manual

PIONEER CMX-5000/KUC Owner's Manual

Manual details

We guarantee that...

Sample pages

Reviews

Related Products

PIONEER DEH-P3500-2 Service Manual

PIONEER VSX-LX51/HYSXJ5 Service Manual

PIONEER HTZ-131DV/NAXJ5 Owner's Manual

PIONEER AVIC-80DVD Service Manual

PIONEER XR-P770F Service Manual

Popular Brands

General

Members Area
