PIONEER CS-3070 Service Manual

Cover page of PIONEER CS-3070 Service Manual

Service Manual for PIONEER CS-3070, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 2 pages
  • File size: 0.02 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1998
RRV2070
T-ZZW NOV. 1998 Printed in Japan
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the cabinet by catches. Detach by pull-
ing it toward you.
The woofer is attached to the baffle by external screws.
To detach it, unfasten those screws.
The midrange is attached to the baffle by external screws.
To detach it, unfasten those screws.
The tweeter is attached to the baffle by external screws.
To detach it, unfasten those screws.
SPEAKER SYSTEM
CS-3070
XE
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1998
RRV2070
T-ZZW NOV. 1998 Printed in Japan
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the cabinet by catches. Detach by pull-
ing it toward you.
The woofer is attached to the baffle by external screws.
To detach it, unfasten those screws.
The midrange is attached to the baffle by external screws.
To detach it, unfasten those screws.
The tweeter is attached to the baffle by external screws.
To detach it, unfasten those screws.
SPEAKER SYSTEM
CS-3070
XE
background image
2
Mark No.
Description
Part No.
Network ASSY (FRWN-144)
SCHEMATIC DIAGRAM
For Packing
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
NOTES:
PARTS LIST
Mark No.
Description
Part No.
CS-3070
Grill ASSY
FRMG-153
Network ASSY
FRWN-144
Badge
FRAM-030
NSP
Model Label
FRAN-238
Input Terminal Board
FRKX-013
Catch
FRNK-015
Speaker (Woofer)
A18EC70-59F
Speaker (Mid-range)
P77CP60-56F
Speaker (Tweeter)
P66AP45-81F
Screw (for Woofer)
FRBA-011
Screw (for Mid-range and Tweeter) FRBA-010
Speaker Wire
FRDD-036
Operating Instructions
FRRD-119
NSP
Warranty Card
FRRY-025
Protector
FRHA-017
Protection Mat S5
FRHC-011
Packing Case
FRHG-223
Woofer
Mid-range
I NPUT
Red
Green
White
Black
White
Tweeter
2.2
µF
Black
