PIONEER DEH-1000/XN/UC Service Manual

Cover page of PIONEER DEH-1000/XN/UC Service Manual

Service Manual for PIONEER DEH-1000/XN/UC, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 73 pages
  • File size: 3.53 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
PIONEER ELECTRONIC CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V.
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER ELECTRONIC CORPORATION 1998
K-ZZD. DEC. 1998 Printed in Japan
ORDER NO.
CRT2313
HIGH POWER CD PLAYER WITH FM/AM TUNER
DEH-1000
X
1N/UC
Service
Manual
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................2
3. SCHEMATIC DIAGRAM ...........................................12
4. PCB CONNECTION DIAGRAM ................................28
5. ELECTRICAL PARTS LIST ........................................38
6. ADJUSTMENT..........................................................44
7. GENERAL INFORMATION .......................................48
7.1 PARTS .................................................................48
7.1.1 IC................................................................48
7.1.2 DISPLAY ....................................................55
7.2 DIAGNOSIS ........................................................56
7.2.1 DISASSEMBLY .........................................56
7.2.2 TEST MODE ..............................................57
7.3 BLOCK DIAGRAM ..............................................61
8. OPERATIONS AND SPECIFICATIONS.....................62
- See the separate manual CX-916(CRT2300) for the CD mechanism description, disassembly and circuit
description.
- The CD mechanism employed in this model is one of S8 series.
DEH-10
X
1N/UC
DEH-1050
X
1N/ES
DEH-1000/X1N/UC
background image
PIONEER ELECTRONIC CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER ELECTRONIC [EUROPE] N.V.
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER ELECTRONIC CORPORATION 1998
K-ZZD. DEC. 1998 Printed in Japan
ORDER NO.
CRT2313
HIGH POWER CD PLAYER WITH FM/AM TUNER
DEH-1000
X
1N/UC
Service
Manual
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................2
3. SCHEMATIC DIAGRAM ...........................................12
4. PCB CONNECTION DIAGRAM ................................28
5. ELECTRICAL PARTS LIST ........................................38
6. ADJUSTMENT..........................................................44
7. GENERAL INFORMATION .......................................48
7.1 PARTS .................................................................48
7.1.1 IC................................................................48
7.1.2 DISPLAY ....................................................55
7.2 DIAGNOSIS ........................................................56
7.2.1 DISASSEMBLY .........................................56
7.2.2 TEST MODE ..............................................57
7.3 BLOCK DIAGRAM ..............................................61
8. OPERATIONS AND SPECIFICATIONS.....................62
- See the separate manual CX-916(CRT2300) for the CD mechanism description, disassembly and circuit
description.
- The CD mechanism employed in this model is one of S8 series.
DEH-10
X
1N/UC
DEH-1050
X
1N/ES
DEH-1000/X1N/UC
background image
2
DEH-1000,10,1050
- CD Player Service Precautions
1. For pickup unit(CXX1285) handling, please refer
to"Disassembly"(CX-916 Service Manual CRT2300).
During replacement, handling precautions shall be
taken to prevent an electrostatic discharge(protection
by a short pin).
2. During disassembly, be sure to turn the power off
since an internal IC might be destroyed when a con-
nector is plugged or unplugged.
3. Please checking the grating after changing the ser-
vice pickup unit(see page 46).
CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of
California to cause cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 - Proposition 65
1. SAFETY INFORMATION
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
20
15
12
16
17
4
7
11
3
10
9
8
6
5
2
14
1
background image
3
DEH-1000,10,1050
- Owner's Manual
Model
Part No.
Language
DEH-1000/X1N/UC, DEH-10/X1N/UC
CRD2858
English, French, Spanish
DEH-1050/X1N/ES
CRD2860
English, Spanish, Portuguese
CRD2861
Arabic, Chinese
- Installation Manual
Model
Part No.
Language
DEH-1000/X1N/UC, DEH-10/X1N/UC
CRD2859
English, French, Spanish
DEH-1050/X1N/ES
CRD2862
English, Spanish, Portuguese, Arabic, Chinese
1 Cord Assy
CDE5874
*
2 Accessory Assy
CEA2395
3 Spring
CBH1650
4 Screw Assy
CEA2396
5 Screw
CBA1002
*
6 Polyethylene Bag
CEG-127
7 Screw
CRZ50P090FMC
8 Screw
TRZ50P080FMC
*
9 Polyethylene Bag
CEG-158
10 Handle
CNC5395
11 Bush
CNV3930
12 Polyethylene Bag
See Contrast table(2)
13 ·····
14 Carton
See Contrast table(2)
15 Contain Box
See Contrast table(2)
16 Protector
CHP2101
17 Protector
CHP2102
18 ·····
19 ·····
20-1 Owner's Manual
See Contrast table(2)
20-2 Owner's Manual
See Contrast table(2)
20-3 Installation Manual
See Contrast table(2)
20-4 Polyethylene Bag
CEG1116
* 20-5 Card
See Contrast table(2)
Mark No. Description
Part No.
Mark No. Description
Part No.
(1) PACKING SECTION PARTS LIST
NOTE:
- Parts marked by "*" and | can not be supplied.
- Screws adjacent to
mark on the product are used for disassembly.
Part No.
Mark No. Symbol and Description DEH-1000/X1N/UC
DEH-10/X1N/UC
DEH-1050/X1N/ES
12 Polyethylene Bag
CEG1173
CEG1173
CEG-162
14 Carton
CHG3664
CHG3663
CHG3665
15 Contain Box
CHL3664
CHL3663
CHL3665
20-1 Owner's Manual
CRD2858
CRD2858
CRD2860
20-2 Owner's Manual
Not used
Not used
CRD2861
20-3 Installation Manual
CRD2859
CRD2859
CRD2862
* 20-5 Card
ARY1048
ARY1048
Not used
(2) CONTRAST TABLE
DEH-1000/X1N/UC, DEH-10/X1N/UC and DEH-1050/X1N/ES are constructed the same except for the fol-
lowing:
background image
4
DEH-1000,10,1050
2.2 EXTERIOR
- DEH-1000/X1N/UC
background image
5
DEH-1000,10,1050
1 Screw
BMZ26P120FMC
2 Screw
BSZ26P060FMC
3 Screw
BSZ30P060FMC
4 Screw
BSZ30P120FMC
5 Cable
CDE6018
6 Cord Assy
CDE5874
7 Fuse(10A)
CEK1136
8 Resistor
RS1/2PMF102J
9 Cap
CNS1472
10 Cover
CNC8367
11 Earth Plate
CNC8368
12 Spacer
CNM4913
13 Insulator
CNM6006
14 Insulator
CNM6224
|
15 Tuner Amp Unit
CWM6092
16 Screw
ASZ26P080FMC
17 Screw
BPZ26P080FMC
18 Screw
BSZ26P160FMC
19 IC(IC551)
PAL005A
20 Connector(CN551)
CDE5996
21 Antenna Cable(CN502)
CDH1254
22 Transistor(Q981,991)
2SD2396
23 Clamper
CEF1006
24 Pin Jack(CN431)
CKB1028
25 Terminal(CN501)
CKF1059
26 Connector(CN951)
CKM1299
*
27 Connector(CN681)
CKS2227
28 ·····
29 Connector(CN651)
CKS3581
30 Holder
CNC7533
31 Holder
CNC8130
32 Holder
CNC8041
33 Holder
CNC8043
34 Insulator
CNM5967
35 Heat Sink
CNR1506
36 FM/AM Tuner Unit
CWE1501
37 Holder
CNC7532
38 Chassis Unit
CXB3167
39 Screw
BPZ20P060FMC
40 Screw
BPZ20P080FMC
41 Button(+)
CAC5834
42 Button(-)
CAC5837
43 Button(SOURCE)
CAC5983
44 Button(BAND)
CAC5984
45 Button(1-6)
CAC5840
46 Button(PGM,CL)
CAC5841
47 Button(UP,DOWN)
CAC5846
48 Button(<>)
CAC5849
49 Button(F,A)
CAC5852
50 Button(EJECT)
CAC5853
51 Button(EQ)
CAC6132
52 Cover
CNM4704
53 ·····
54 ·····
55 ·····
56 ·····
57 Holder
CNV5574
58 Housing
CNV5575
59 Keyboard Unit
CWM6098
60 LCD(LCD1801)
CAW1500
61 Connector(CN1801)
CKS3580
62 Holder
CNC8036
63 Sheet
CNM6026
64 ·····
65 Screw
ISS26P055FUC
66 Lighting Conductor
CNV5570
67 Connector
CNV5571
68 Grille Unit
CXB3504
69 Case Unit
CXB4033
70 CD Mechanism Module
CXK5200
71 Holder
CNC6798
72 Panel
CNS5132
- EXTERIOR SECTION PARTS LIST
Mark No. Description
Part No.
Mark No. Description
Part No.
