DEH-1610/XU/EE

1234

123

SAFETY INFORMATION

This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.

Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely

repair complex products such as those covered by this manual.

Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.

If you are not qualified to perform the repair of this product properly and safely, you should not risk trying to do so

and refer the repair to a qualified service technician.

1. Safety Precautions for those who Service this Unit.

· When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable

results.

Caution:

1. During repair or tests, minimum distance of 13cm from the focus lens must be kept.

2. During repair or tests, do not view laser beam for 10 seconds or longer.

2. A "CLASS 1 LASER PRODUCT" label is affixed to the

bottom of the player.

3. The triangular label is attached to the mechanism

unit frame.

4. Specifications of Laser Diode

Specifications of laser radiation fields to which human access is possible during service.

Wavelength = 800 nanometers

CLASS 1

LASER PRODUCT

- CD Section Precaution

1. Before disassembling the unit, be sure to turn off

the power. Unplugging and plugging the connectors

during power-on mode may damage the ICs inside

the unit.

2. To protect the pickup unit from electrostatic discharge

during servicing, take an appropriate treatment

(shorting-solder) by referring to "the DISASSEMBLY"

on page 43.

3. After replacing the pickup unit, be sure to check the

grating. (See p.40.)

4. In this product, because the memory capacity of the

microcomputer is insufficient, the test mode is not

installed. However grating of the pickup unit can be

confirmed.

DEH-1610/XU/EE

678

[ Important symbols for good services ]

In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.

When you find the procedures bearing any of the symbols, be sure to fulfill them:

2. Adjustments

To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.

In accordance with the procedures or instructions described in this manual, adjustments should be performed.

3. Cleaning

For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,

proper cleaning should be performed to restore their performances.

5. Lubricants, glues, and replacement parts

Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying

glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the

prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed

ones should be used.

4. Shipping mode and shipping screws

To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or

the shipping screws should be installed before shipping out in accordance with this manual, if necessary.

1. Product safety

You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and

should keep the safety during servicing by following the safety instructions described in this manual.

DEH-1610/XU/EE

1234

123

CONTENTS

SAFETY INFORMATION ..................................................................................................................................... 2

1. SPECIFICATIONS ............................................................................................................................................ 5

2. EXPLODED VIEWS AND PARTS LIST ............................................................................................................ 6

2.1 PACKING ................................................................................................................................................... 6

2.2 EXTERIOR................................................................................................................................................. 8

2.3 CD MECHANISM MODULE..................................................................................................................... 10

3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..........................................................................................12

3.1 BLOCK DIAGRAM ................................................................................................................................... 12

3.2 OVERALL CONNECTION DIAGRAM(GUIDE PAGE).............................................................................. 14

3.3 KEYBOARD UNIT.................................................................................................................................... 20

3.4 CD MECHANISM MODULE..................................................................................................................... 22

4. PCB CONNECTION DIAGRAM ..................................................................................................................... 26

4.1 TUNER AMP UNIT................................................................................................................................... 26

4.2 KEYBOARD UNIT.................................................................................................................................... 30

4.3 CD MECHANISM MODULE..................................................................................................................... 32

5. ELECTRICAL PARTS LIST ............................................................................................................................ 34

6. ADJUSTMENT ............................................................................................................................................... 38

6.1 FREQUENCY CHECK FOR CLOCK ....................................................................................................... 38

6.2 CD ADJUSTMENT................................................................................................................................... 39

6.3 CHECKING THE GRATING AFTER CHANGING THE PICKUP UNIT .................................................... 40

6.4 ERROR MODE ........................................................................................................................................ 42

7. GENERAL INFORMATION ............................................................................................................................. 43

7.1 DIAGNOSIS ............................................................................................................................................. 43

7.1.1 DISASSEMBLY ..................................................................................................................................... 43

7.1.2 CONNECTOR FUNCTION DESCRIPTION .......................................................................................... 47

7.2 PARTS...................................................................................................................................................... 48

7.2.1 IC .......................................................................................................................................................... 48

7.2.2 DISPLAY ............................................................................................................................................... 55

7.3 OPERATIONAL FLOW CHART ............................................................................................................... 56

7.4 CLEANING............................................................................................................................................... 57

8. OPERATIONS ................................................................................................................................................ 58
