PIONEER DEH-2430R/XU/EW Owner's Manual

Cover page of PIONEER DEH-2430R/XU/EW Owner's Manual

Owner's Manual for PIONEER DEH-2430R/XU/EW, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 124 pages
  • File size: 1.18 MB
  • Available language versions: French, English, Spanish, Dutch, German, Italian
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
High power CD player with RDS tuner
Syntoniseur RDS et lecteur de CD, "Puissance élevée"
Operation Manual
DEH-3400R
DEH-2460R
DEH-2430R
Mode d'emploi
English
Español
Deutsch
F
rançais
Italiano
Nederlands
background image
High power CD player with RDS tuner
Syntoniseur RDS et lecteur de CD, "Puissance élevée"
Operation Manual
DEH-3400R
DEH-2460R
DEH-2430R
Mode d'emploi
English
Español
Deutsch
F
rançais
Italiano
Nederlands
background image
Before You Start
About this unit 2
About this manual 2
Precautions 2
In case of trouble 2
What's what 3
Optional remote control (DEH-3400R) 4
Protecting your unit from theft 4
· Removing the front panel 4
· Attaching the front panel 5
Power ON/OFF
Turning the unit on 5
Selecting a source 5
Turning the unit off 5
Tuner
Listening to the radio 6
Storing and recalling broadcast
frequencies 7
Tuning in strong signals 7
Storing the strongest broadcast
frequencies 7
RDS
Introduction of RDS operation 8
Switching the RDS display 8
Receiving PTY alarm broadcasts 8
Selecting alternative frequencies 9
· Using PI Seek 9
· Using Auto PI Seek for preset
stations 9
· Limiting stations to regional program-
ming 9
Receiving traffic announcements 10
· Responding to the TP alarm 10
PTY list 11
Built-in CD Player
Playing a CD 12
Repeating play 13
Pausing CD playback 13
Audio Adjustments
Introduction of audio adjustments 14
Using balance adjustment 14
Using the equalizer 15
· Recalling equalizer curves 15
· Adjusting equalizer curves 15
Adjusting loudness 15
Front image enhancer (FIE) 16
Adjusting source levels 16
Initial Settings
Adjusting initial settings 17
Setting the FM tuning step 17
Switching Auto PI Seek 17
Additional Information
Cellular telephone muting 18
CD player and care 18
CD-R/CD-RW discs 19
Understanding built-in CD player error mes-
sages 19
Specifications 20
Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to oper-
ate your model properly. After you have finished reading the instructions, put them
away in a safe place for future reference.
Contents
En
1
background image
About this unit
The tuner frequencies on this unit are allocated
for use in Western Europe, Asia, the Middle
East, Africa and Oceania. Use in other areas
may result in improper reception. The RDS func-
tion operates only in areas with FM stations
broadcasting RDS signals.
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and oper-
ation. All the functions have been designed for
the easiest possible use, but many are not self-
explanatory. This operation manual will help you
benefit fully from this product's potential and to
maximize your listening enjoyment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin using
this unit. It is especially important that you read
and observe precautions on this page and in
other sections.
Precautions
·A CLASS 1 LASER PRODUCT label is affixed
to the bottom of this unit.
· The Pioneer CarStereo-Pass is for use only in
Germany.
· Keep this manual handy as a reference for
operating procedures and precautions.
· Always keep the volume low enough so you
can hear sounds outside of the car.
· Protect this product from moisture.
· If the battery is disconnected or discharged,
the preset memory will be erased and must be
reprogrammed.
In case of trouble
Should this product fail to operate properly,
contact your dealer or nearest authorized
Pioneer Service Station.
CLASS 1
LASER PRODUCT
This product complies with the EMC
Directives (89/336/EEC, 92/31/EEC) and
CE Marking Directive (93/68/EEC).
Before You Start
En
2
English
Español
Deutsch
F
rançais
Italiano
Nederlands
background image
En
3
Before You Start
What's what
1 DISP/REG button
Press to switch the RDS display.
Press and hold for two seconds to switch
regional function on or off.
2 LOCAL/BSM button
Press to switch local function on or off.
Press and hold for two seconds to switch
BSM function on or off.
3 OPEN button
Press to open the front panel.
4 AUDIO button
Press to select various sound quality con-
trols.
5
5//2/3 buttons
Press to do manual seek tuning, fast for-
ward, reverse and track search controls. Also
used for controlling functions.
6 LOUDNESS button
Press to switch loudness function on or off.
7 BAND button
Press to select among two FM or MW/LW
bands and cancel the control mode of func-
tions.
8 1­6 (PRESET TUNING) buttons
Press for preset tuning.
9 SOURCE button
This unit is switched on by selecting a
source. Press to cycle through all of the
available sources.
0 EQ button
Press to select various equalizer curves.
- VOLUME
Rotate to increase or decrease the volume.
= TA button
Press to switch traffic announcements func-
tion on or off.
3
4
-
5
1
2
0
9
7
6
8
=
background image
Before You Start
En
4
English
Español
Deutsch
F
rançais
Italiano
Nederlands
Optional remote control
(DEH-3400R)
The steering remote control CD-SR80 is sold
separately. Operation is the same as when
using the button on the head unit. See the
explanation of the head unit about the operation
of each button with the exception of ATT, which
is explained below.
~ ATT button
Press to quickly lower the volume level, by
about 90%. Press once more to return to the
original volume level.
! FUNCTION button
Not used.
@ VOLUME button
Press to increase or decrease the volume.
Protecting your unit from theft
The front panel can be detached from the head
unit and stored in the protective case provided
to discourage theft.
· Keep the front panel closed while driving.
Important
· Never use force or grip the display and the
buttons tightly when removing or attaching.
· Avoid subjecting the front panel to excessive
shocks.
· Keep the front panel out of direct sunlight and
high temperatures.
Removing the front panel
1 Press OPEN to open the front panel.
2 Grip the left side of the front panel and pull
it gently outward.
Take care not to grip it tightly or drop it.
3 Put the front panel into the protective case
provided for safe keeping.
@
5
!
4
9
7
~
