PIONEER DEHM6006ZH Service Manual

Cover page of PIONEER DEHM6006ZH Service Manual

Service Manual for PIONEER DEHM6006ZH, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 71 pages
  • File size: 5.77 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001
K-ZZS. JAN. 2001 Printed in Japan
ORDER NO.
CRT2657
MULTI-CD CONTROL CD PLAYER WITH RDS TUNER
DEH-M6006ZH
X1P/EW
Service
Manual
HONDA
VEHICLE
DESTINATION
PRODUCED AFTER
HONDA PART No.
ID No.
PIONEER MODEL No.
CIVIC 5door
EUROPE
March 2001
39100-S6A-G500
DEH-M6006ZH/X1P/EW
ACCORD
EUROPE
February 2001
39100-S1A-E100
DEH-M6017ZH/EW
DEH-M6006ZH/X1P/EW
- This service manual should be used together with the following manual(s):
Model No.
Order No.
Mech. Module Remarks
CX-958
CRT2423
S8.1
CD Mech. Module:Circuit Description, Mech.Description, Disassembly
DEH-M6017ZH EW
CONTENTS
1. SAFETY INFORMATION............................................2
2. EXPLODED VIEWS AND PARTS LIST ......................3
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..10
4. PCB CONNECTION DIAGRAM................................30
5. ELECTRICAL PARTS LIST........................................40
6. ADJUSTMENT .........................................................49
7. GENERAL INFORMATION.......................................54
7.1 DIAGNOSIS .......................................................54
7.1.1 ERROR MESSAGES.................................54
7.1.2 DISASSEMBLY .........................................55
7.1.3 CONNECTOR FUNCTION DESCRIPTION ......60
7.2 PARTS ................................................................61
7.2.1 IC ...............................................................61
7.2.2 DISPLAY ...................................................67
7.3 OPERATIONAL FLOW CHART ..........................68
8. OPERATIONS AND SPECIFICATIONS ....................71
background image
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001
K-ZZS. JAN. 2001 Printed in Japan
ORDER NO.
CRT2657
MULTI-CD CONTROL CD PLAYER WITH RDS TUNER
DEH-M6006ZH
X1P/EW
Service
Manual
HONDA
VEHICLE
DESTINATION
PRODUCED AFTER
HONDA PART No.
ID No.
PIONEER MODEL No.
CIVIC 5door
EUROPE
March 2001
39100-S6A-G500
DEH-M6006ZH/X1P/EW
ACCORD
EUROPE
February 2001
39100-S1A-E100
DEH-M6017ZH/EW
DEH-M6006ZH/X1P/EW
- This service manual should be used together with the following manual(s):
Model No.
Order No.
Mech. Module Remarks
CX-958
CRT2423
S8.1
CD Mech. Module:Circuit Description, Mech.Description, Disassembly
DEH-M6017ZH EW
CONTENTS
1. SAFETY INFORMATION............................................2
2. EXPLODED VIEWS AND PARTS LIST ......................3
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ..10
4. PCB CONNECTION DIAGRAM................................30
5. ELECTRICAL PARTS LIST........................................40
6. ADJUSTMENT .........................................................49
7. GENERAL INFORMATION.......................................54
7.1 DIAGNOSIS .......................................................54
7.1.1 ERROR MESSAGES.................................54
7.1.2 DISASSEMBLY .........................................55
7.1.3 CONNECTOR FUNCTION DESCRIPTION ......60
7.2 PARTS ................................................................61
7.2.1 IC ...............................................................61
7.2.2 DISPLAY ...................................................67
7.3 OPERATIONAL FLOW CHART ..........................68
8. OPERATIONS AND SPECIFICATIONS ....................71
background image
2
DEH-M6006ZH,M6017ZH
- CD Player Service Precautions
1. For pickup unit(CXX1285) handling, please refer
to"Disassembly"(see page 55)
During replacement, handling precautions shall be
taken to prevent an electrostatic discharge(protection
by a short pin).
2. During disassembly, be sure to turn the power off
since an internal IC might be destroyed when a con-
nector is plugged or unplugged.
3. Please checking the grating after changing the ser-
vice pickup unit(see page 51).
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely repair
complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.
1. Safety Precautions for those who Service this Unit.
· When checking or adjusting the emitting power of the laser diode exercise caution in order to get safe, reliable
results.
Caution:
1. During repair or tests, minimum distance of 13cm from the focus lens must be kept.
2. During repair or tests, do not view laser beam for 10 seconds or longer.
2. A "CLASS 1 LASER PRODUCT" label is affixed to the
top of the player.
3. The triangular label is attached to the mechanism
unit frame.
CLASS 1
LASER PRODUCT
4. Specifications of Laser Diode
Specifications of laser radiation fields to which human access is possible during service.
Wavelength
=
800 nanometers
background image
3
DEH-M6006ZH,M6017ZH
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
1
1
2
3
4
6
7
5
8
NOTE:
- Parts marked by "*" are generally unavailable because they are not in our Master Spare Parts List.
- Screws adjacent to
mark on the product are used for disassembly.
- PACKING SECTION PARTS LIST
Part No.
Mark No. Description
DEH-M6006ZH/X1P/EW DEH-M6017ZH/EW
1 Protector
UHP2311
CHP2311
2 Protector
UHP2312
CHP2312
3 Protector
UHP2315
CHP2315
4 Polyethylene Bag
UEG1042
CEG-162
5 Contain Box
UHL-091
CHL4294
6 Protector
UHP2313
CHP2313
7 Protector
UHP2314
CHP2314
8-1 Polyethylene Bag
UEG1229
CEG1229
8-2 ID Card
CEE1018
CEE1018
background image
4
DEH-M6006ZH,M6017ZH
2.2 EXTERIOR(DEH-M6006ZH)
A
B
background image
5
DEH-M6006ZH,M6017ZH
1 Screw
BSZ26P060FMC
2 Screw
BSZ26P150FMC
3 Screw
BSZ30P060FMC
4 Screw
BSZ30P120FMC
5 Cable
CDE6645
6 Button(L/M/U)
CAC6568
7 Button(CD,AUX)
CAC6569
8 CD Mechanism Module(S8.1)
CXK5201
9 IC(IC901)
TDA7384
10 Transistor(Q801,805)
2SD2396
11 Button
CAC6570
12 Button
CAC6571
13 Screw
ISS30P060FMC
14 Case
CNB2560
15 Holder
CNC5704
16 Cushion
CNM7071
17 Cushion
CNM4870
18 Insulator
CNM6862
19 Heat Sink
CNR1565
20 Tuner Amp Unit
UWM7108
21 Screw
BSZ26P060FMC
22 Terminal(CN501)
CKF1059
23 Terminal(CN502)
CKF1059
24 Connector(CN901)
CKM1208
25 Plug(CN902)
CKM1283
26 Connector(CN601)
CKS1962
27 Plug(CN602)
CKS3538
28 Antenna Jack(ANT501)
CKX1060
29 Holder
CNC7533
30 Holder
CNC8746
31 Holder
CNC8747
32 Insulator
CNM5967
33 FM/AM Tuner Unit
UWE1576
34 Holder
CNC7532
35 Screw
PRZ30P060FSN
36 Chassis Unit
CXB5428
37 Button
CAC6573
38 Button(TA)
CAC6574
39 Button(PTY,NEWS)
CAC6575
40 Cushion
CNM6939
41 Lighting Conductor
CNV6159
42 Conductor
CNC9043
43 Lighting Conductor
CNV6160
44 Rubber
CNV6173
45 Lighting Conductor
CNV6294
46 Holder
CNV6295
47 Knob Assy
CXB5429
48 Grille Unit
CXB5431
49 Lighting Conductor
CNV6161
50 Screw
BPZ20P080FMC
51 Screw
ISS26P055FUC
52 Connector
CNV6163
53 Connector
CNV6293
54 Keyboard Unit
UWM7109
55 Plate
CAH1723
56 LCD(LCD951)
CAW1588
57 Socket(CN951)
CKS3551
58 Holder
CNC8745
59 Plate
CNM7308
60 Holder
CNV6162
61 Spacer
CNM7313
62 Button(SEEK/SKIP)
CAC6572
63 Button(EJECT)
CAC6567
Mark No. Description
Part No.
Mark No. Description
Part No.
- EXTERIOR SECTION PARTS LIST
