background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
RRV3615
DVD PLAYER
DV-300-S
DV-300-G
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
This service manual should be used together with the following manual(s):
Model
Type
Power Requirement
Region No.
Remarks
DV-300-S
TTXZT
AC 110 V to 240V
3
DV-300-S
TLXZT4
AC 110 V to 240V
3
DV-300-S
TPWXZT
AC 110 V to 240V
4
DV-300-G
TAXZT5
AC 110 V to 240V
6
Model
Order No.
Remarks
DV-300-K/KUCXZT
RRV3584
T-ZZV MAY 2007 Printed in Japan
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
RRV3615
DVD PLAYER
DV-300-S
DV-300-G
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
This service manual should be used together with the following manual(s):
Model
Type
Power Requirement
Region No.
Remarks
DV-300-S
TTXZT
AC 110 V to 240V
3
DV-300-S
TLXZT4
AC 110 V to 240V
3
DV-300-S
TPWXZT
AC 110 V to 240V
4
DV-300-G
TAXZT5
AC 110 V to 240V
6
Model
Order No.
Remarks
DV-300-K/KUCXZT
RRV3584
T-ZZV MAY 2007 Printed in Japan
background image
DV-300-S
2
12
34
1
234
C
D
F
A
B
E
1. CONTRAST OF MISCELLANEOUS PARTS
1.1 CONTRAST TABLE
DV-300-S/TTXZT, DV-300-S/TLXZT4, DV-300-G/TAXZT5 and DV-300-K/KUCXZT are constructed the same except
for the following:
Notes : The number in the No. column correspond to to the numbers on "EXPLODED VIEWS".
For PCB assemblies, Refer to "1.2 CONTRAST OF PCB ASSEMBLIES" and "2. SCHEMATIC DIAGRAM".
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to
mark on product are used for disassembly.
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
Mark No.
Symbol and Description
DV-300-K/
KUCXZT
DV-300-S/
TTXZT
DV-300-S/
TLXZT4
DV-300-S/
TPWXZT
DV-300-G/
TAXZT5
PCB ASSEMBLIES
P43-1 DVD MT PCB ASSY
A2K008A130
A2K002A130
A2K002A130
A2K002A130
A2K002A130
P43-2 OPERATION 1 PCB ASSY
A2K008A270
A2K018A270
A2K002A270
A2K002A270
A2K015A270
>
P43-4 POWER PCB ASSY
A2K008A240
A2K020A240
A2K020A240
A2K020A240
A2K020A240
PACKING SECTION
>
No.1 Power Cable
Not used
1206158802
1206158802
120G168801
12061K8801
NSP P41-6 Guarantee Card
J2G00202A
J2K01892A
Not used
Not used
J2K01502A
P41-7 Operating Instructions (English)
J2K00801A
Not used
J2K00201A
J2K00201A
Not used
P41-8 Operating Instructions (French)
J2K00810A
Not used
Not used
Not used
Not used
Operating Instructions (Thai)
Not used
J2K01801A
Not used
Not used
Not used
Operating Instructions (Chinese)
Not used
Not used
J2K00210A
Not used
J2K01501A
P41-9 Polyethylene Bag,Instruction
JB5KD300
JB5UD200
JB5KD200
JB5KD100
JB5KD200
P41-11 Package
792WHAA227
792WHAA227
792WHAA227
792WHAA232
792WHAA227
P41-12 Gift Box
793WCDD454
793WCDD448
793WCDD448
793WCDD489
793WCDD330
No.2 Carton Label
Not used
723000D564
723000D543
Not used
Not used
NSP No.3 Label Safety
Not used
723000D483
Not used
Not used
Not used
EXTERIOR SECTION
>
P43-6 Cord AC Bush
120Q618902
Not used
Not used
Not used
Not used
NSP P43-7 Plate,Bottom
702WSAA192
702WSAA193
702WSAA193
702WSAA193
702WSAA193
NSP P43-9 Sheet Caution
726000A140
726000A140
726000A140
726000A140
726000A143
P43-13 Cabinet,top
702WSB0115
702WSB0114
702WSB0114
702WSB0114
702WSB0116
P43-19 Screw,tap Tite(B)
8109K3060S
8109K3060U
8109K3060U
8109K3060U
8109K3060U
NSP P43-23 Sheet,Jack 1
722631A203
722631A187
722631A187
722631A187
722631A187
NSP P43-24 Sheet,Jack 2
722631A219
722631A212
722631A214
722631A225
722631A200
NSP P43-25 Sheet,Jack 3
722631A220
722631A213
722631A215
722631A228
722631A202
NSP P43-26 Sheet,Caution
7250000597
Not used
Not used
Not used
Not used
P43-27 Front,Cabi Ass'y
7A701A911A
7A701A878A
7A701A878A
7A701A878A
7A701A914A
P43-28 Flap,DVD
712WPDA079
712WPDA079
712WPDA079
712WPDA079
712WPJC317
NSP P43-32 Energy Star Label
7230007965
Not used
Not used
7230007965
Not used
NSP No.4 Sheet,Fuse
Not used
7240001122
7240001122
7240001122
7240001122
background image
DV-300-S
3
56
7
8
56
7
8
C
D
F
A
B
E
(TTXZT and TLXZT4 types)
(TTXZT and TLXZT4 types)
No.2
No.2
No.1
No.3
(TTXZT type)
Audio/Video Cable
POWER PCB ASSY
Plate, Cover power
No.4
EXPLODED VIEWS
PACKING
EXTERIOR SECTION
background image
DV-300-S
4
12
34
1
234
C
D
F
A
B
E
1.2 CONTRAST OF PCB ASSEMBLIES
1.2.1 DVD MT PCB ASSY
A2K002A130 and A2A08130 are constructed the same except for the following
1.2.2 OPERATION 1 PCB ASSY
Although A2K018A270, A2K002A270, A2K015A270 and A2K008A270 are different in part number and they are
NOT COMPATIBLE, they consist of the same service components. As a reference, the schematic diagram is on
page 6.
1.2.3 POWER PCB ASSY
Although A2K020A240 and A2K008A240 are different in part number and they are NOT COMPATIBLE, they consist
of the same service components. As a reference, the schematic diagram is on page 8.
Mark
Symbol and Description
A2K008A130
A2K002A130
OS8001 OPTICAL DEVICE
Not used
07AA000011
background image
DV-300-S
5
56
7
8
56
7
8
C
D
F
A
B
E
2. SCHEMATIC DIAGRAM
2.1 DVD MT PCB ASSY (4/6)
OS8001
RFT5CB1
OPTICAL
1
2
3
H
E
J8001
RCA-117-01
COAXIAL
1
2
C8053
47
16V
NA_P
C8051
47
16V
NA_P
Q8005
KTC3875S_Y_RTK
COAXIAL DRIV
C8046
100P
CH
C8042
100P
CH
C8036
1B
C8037
0.1
B
C8074
330P CH
C8038
1
50V KA_P
R8040
100K
R8060
470K
R8048
470K
R8059
10K +-1%
R8049
10K +-1%
R8038
220
R8035
2.4K
R8036
3.9K
R8037
1.8K
R8044
8.2K
R8039
68
TP8001
W840
B8004
MMZ1608R102CT
ASPDIF
AMUTE
V+5V_A
D_GND
V+12AT
V+12
V+5V
PWDN#
AMUTE
ASPDIF
AL
AR
GND
VSEL1
AL
AR
AUDIO_L
AUDIO_R
V+5V_A
GND
VSEL1
V+12
FROM MPEG/MICON/DSP
FROM/TO VIDEO JACK
FROM POWER PORT
GND
INPUT
VCC
2.8
2.1
5.0
DVD MT PCB ASSY (4/6) (A2K002A130)
AUDIO JACK BLOCK
7
