PIONEER DV-373-K Service Manual

Cover page of PIONEER DV-373-K Service Manual

Service Manual for PIONEER DV-373-K, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 2 pages
  • File size: 0.04 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
RRV2951
DVD PLAYER
DV-373-K
Model No.
Order No.
Remarks
DV-373-S/RRXCN
RRV2950
¶ This service manual should be used together with the following manual(s):
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Power Requirement
Region No.
Serial No.
Confirm 3rd & 4th
alphabetical letters.
DV-373-K
AC110-127V/220-240V
4
&&TE######$$
Type
RPWXCN
T ­ ZZE MAY 2004 Printed in Japan
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
RRV2951
DVD PLAYER
DV-373-K
Model No.
Order No.
Remarks
DV-373-S/RRXCN
RRV2950
¶ This service manual should be used together with the following manual(s):
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Power Requirement
Region No.
Serial No.
Confirm 3rd & 4th
alphabetical letters.
DV-373-K
AC110-127V/220-240V
4
&&TE######$$
Type
RPWXCN
T ­ ZZE MAY 2004 Printed in Japan
background image
1
23
4
C
D
F
A
B
E
2
12
3
4
DV-373-K
1. CONTRAST OF MISCELLANEOUS PARTS
7 CONTRAST TABLE
DV-373-K/RPWXCN and DV-373-S/RPWXCN are constructed the same except for the following:
PACKING
P7 -16
Packing Case
VHG2460
VHG2464
EXTERIOR SECTION
P9 -10
Bonnet
VNA2677
VNA2678
P9 -13
Rear Sheet
VRW2027
VRW2031
P9 -14
DVD-V Plate
VAM1135
VAM1120
P9 -15
Tray Panel
VNK5411
VNK5413
Screw
Not used
BBZ30P060FBN
for the side of the bonnet
FRONT PANEL SECTION
P11 - 4
Pioneer Name Plate
VAM1129
VAM1130
P11 - 7
Front Panel
VNK5476
VNK5403
P11 - 8
Main Key
VNK5404
VNK5406
P11 - 9
Key Top
VNK5407
VNK5409
Ref.
No.
Remarks
DV-373-S/RPWXCN
DV-373-K/RPWXCN
Part No.
Mark
Symbol and Description
NOTES :
÷ Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
÷ The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷ Screw adjacent to
mark on the product are used for disassembly.
÷ Reference Nos. indicate the pages and Nos. in the service manual for the base model.
