PIONEER DVD-D302 Owner's Manual

Cover page of PIONEER DVD-D302 Owner's Manual

Owner's Manual for PIONEER DVD-D302, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 8 pages
  • File size: 0.29 MB
  • Available language versions: Japanese, English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
Ja
<DRM1213>
1
IMPORTANT NOTICE:
RECORD THE MODEL NUMBER
AND SERIAL NUMBER OF THIS
EQUIPMENT BELOW. THE NUM-
BERS ARE ON THE TOP PANEL.
MODEL NO.
DVD-D302
SERIAL NO.
KEEP THESE NUMBERS FOR
FUTURE USE.
Operating instructions
DVD-D302
DVD-ROM DRIVE UNIT
DVD-ROM
Thank you for buying this Pioneer product.
Please read through these operating instructions
so you will know how to operate your model
properly.
This product is an optional drive designed for
exclusive use as the reader unit for the 100-disc
CD-ROM changers, models DRM-1004X40 and
DRM-1004XR21. This means that this unit
cannot be used alone or connected to other
equipment than specified.
As the installation of this unit requires
sophisticated expertise as well as strict
observation of safety requirements, this unit
will be installed by qualified service personnel
of our service department. For details, please
contact your dealer.
The export of this product or devices in
which this product has been installed
from Japan is regulated by Japanese
government. The export of this product
may be prohibited without govern-
mental license. To export or re-export
of this product from a country other
than Japan may also be prohibited
without an export license from the
country involved.
WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
IMPORTANT
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
background image
Ja
<DRM1213>
1
IMPORTANT NOTICE:
RECORD THE MODEL NUMBER
AND SERIAL NUMBER OF THIS
EQUIPMENT BELOW. THE NUM-
BERS ARE ON THE TOP PANEL.
MODEL NO.
DVD-D302
SERIAL NO.
KEEP THESE NUMBERS FOR
FUTURE USE.
Operating instructions
DVD-D302
DVD-ROM DRIVE UNIT
DVD-ROM
Thank you for buying this Pioneer product.
Please read through these operating instructions
so you will know how to operate your model
properly.
This product is an optional drive designed for
exclusive use as the reader unit for the 100-disc
CD-ROM changers, models DRM-1004X40 and
DRM-1004XR21. This means that this unit
cannot be used alone or connected to other
equipment than specified.
As the installation of this unit requires
sophisticated expertise as well as strict
observation of safety requirements, this unit
will be installed by qualified service personnel
of our service department. For details, please
contact your dealer.
The export of this product or devices in
which this product has been installed
from Japan is regulated by Japanese
government. The export of this product
may be prohibited without govern-
mental license. To export or re-export
of this product from a country other
than Japan may also be prohibited
without an export license from the
country involved.
WARNING: TO PREVENT FIRE OR
SHOCK HAZARD, DO NOT EXPOSE THIS
APPLIANCE TO RAIN OR MOISTURE.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
IMPORTANT
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to
alert the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
CAUTION:
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
background image
Ja
<DRM1213>
2
This product complies with the EMC Directives (89/336/EEC, 92/31/EEC) and CE
Marking Directive (93/68/EEC).
Ce produit est conforme aux directives relatives à la compatibilité électromagnétique
(89/336/CEE, 92/31/CEE) et à la directive CE relative aux marquages (93/68/CEE).
Dieses Produkt entspricht den EMV-Richtlinien (89/336/EEC, 92/31/EEC) und CE-
Markierungsrichtlinien (93/68/EEC).
Questo prodotto è conforme alle direttive EMC (89/336/CEE, 92/31/CEE) e alla
direttiva sul marchio CE (93/68/CEE).
Dit produkt voldoet aan de EMC-richtlijnen (89/336/EEC en 92/31/EEC) en de CE-
markeringsrichtlijn (93/68/EEC).
Denna produkt uppfyller föreskrifterna i EMC-direktiv (89/336/EEC, 92/31/EEC) och
CE-märkningsdirektiv (93/68/EEC).
Este producto cumple con las Directivas EMC (89/336/CEE, 92/31/CEE) y Directiva
de Marcación CE (93/68/CEE).
Este produto cumpre com as Directivas EMC (89/336/CEE, 92/31/CEE) e Directiva
da Marcação CE (93/68/CEE).
Dette produkt er i overensstemmelse med direktiverne vedrørende
elektromagnetisk kompatibilitet (89/336/EEC, 92/31/EEC) og CE-direktivet
vedrørende mærkning (93/68/EEC).
VARNING!
Om apparaten används på annat sätt än i denna bruksanvisning spacificerats, kan
användaren utsättas för osynling laserstrålning som överskrider gränsen för
laserklass 1.
ADVARSEL:
Usynlig laserstråling ved åbning når sikkerhedsafbrydere er ude af funktion. Undgå
udsaettelse for stråling.
VAROITUS!
Laitten käyttäminen muulla kuin tässä käyttöohjeessa mainitulla tavalla saattaa
altistaa käuttäjän turvallisuusluokan 1 ylittävälle näkymättömälle lasersäteilylle.
LASER DIODE ­ This product contains a laser diode. To assure continued safety,
DO NOT remove any convers or attempt to gain access to the inside of the product.
CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
CAUTION:
USE OF OPTICAL INSTRUMENTS WITH THIS PRODUCT WILL INCREASE EYE
HAZARD.
background image
Ja
<DRM1213>
3
RADIO SIGNAL INTERFERENCE - This equipment has been tested and found
to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
]
Reorient or relocate the receiving antenna.
]
Increase the separation between the equipment and receiver.
]
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
]
Consult the dealer or an experienced radio/TV technician for help.
[For Canadian model]
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing
Equipment Regulations.
[Pour le modèle Canadien]
Cet appareil numérique de la Classe B respecte toutes les exigences du Règlement sur le
matériel brouilleur du Canada.
Information to User
Alteration or modifications carried out without appropriate authorization may invalidate the
user's right to operate the equipment.
The Generation of Acoustical Noise Is Less Than 70dB.
(ISO7779/DIN45635)
IMPORTANT
CAUTION
This product contains a laser diode of higher class than
1. To ensure continued safety, do not remove any
covers or attempt to gain access to the inside of the
product.
Refer all servicing to qualified personnel.
The following caution label appears
on your unit.
Location: on top of the cover
For pluggable equipment the socket-outlet shall be installed near
the equipment and shall be easily accessible.
CLASS 1 LASER PRODUCT
LASER KLASSE 1
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
background image
Ja
<DRM1213>
4
FEATURES OF THE REPLACEMENT DVD-ROM DRIVE
SAFETY INSTRUCTIONS
÷ High transfer rate (Sustain )
max. 3,300 K Byte/sec. (DVD-ROM)
max. 3,000 K Byte/sec. (CD-ROM)
÷ Access time: Random avg. 150 ms
(DVD-ROM)
÷ SCSI2 interface
÷ SCSI bus terminator
÷ Multi-session compatibility
÷ 512-byte block compatibility
÷ CD-DA (audio CD) playback capability
÷
÷
÷
÷
÷
÷
÷
background image
Ja
<DRM1213>
5
INSTALLING THE REPLACEMENT DVD-ROM DRIVE
1. Remove the rear panel of
the Changer.
2. Remove the CD-ROM drive.
÷ Disconnect the two connectors on the
left side, and the one connector on the
right side.
÷ Remove the two screws at left and
right.
÷ Pull out the drive straight in alignment
with the changer's right and left guides.
÷
÷
÷
3. Insert the Replacment DVD-
ROM drive.
÷ Slide the drive along the left and right
guides of the Changer and insert into
the half of it.
÷
