ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1999
c
DVL-919E
RRV2095
T ­ ZZE JAN. 1999 Printed in Japan
DVD LD PLAYER
÷ Refer to the service manual RRV1888 for DVL-909/WY.
Type
Power Requirement
Model
DVL-919E
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Region No.
WY
AC220-240V
2
WY/RD
AC220-240V
4
WY/RE
AC220-240V
5
Remarks
1. CONTRAST OF MISCELLANEOUS PARTS ........ 2
2. SCHEMATIC DIAGRAM ....................................... 6
3. PCB CONNECTION DIAGRAM ............................ 8
CONTENTS
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1999
c
DVL-919E
RRV2095
T ­ ZZE JAN. 1999 Printed in Japan
DVD LD PLAYER
÷ Refer to the service manual RRV1888 for DVL-909/WY.
Type
Power Requirement
Model
DVL-919E
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Region No.
WY
AC220-240V
2
WY/RD
AC220-240V
4
WY/RE
AC220-240V
5
Remarks
1. CONTRAST OF MISCELLANEOUS PARTS ........ 2
2. SCHEMATIC DIAGRAM ....................................... 6
3. PCB CONNECTION DIAGRAM ............................ 8
CONTENTS
background image
DVL-919E
2
1. CONTRAST OF MISCELLANEOUS PARTS
7 CONTRAST TABLE
1 : Refer to " PCB PARTS LIST ", " 2. SCHEMATIC DIAGRAM " and " 3. PCB CONNECTION DIAGRAM ".
2 : Although VWV1639 and VWV1578 are differnt in part number, they have same service parts.
3 : Although VWG2017 and VWG1895 are differnt in part number, they have same service parts.
4 : Refer to " CONTRAST OF PCB ASSEMBLIES ".
DVL-919E/WY, WY/RD, WY/RE and DVL-909/WY are constructed the same except for the following:
Part No.
Ref. No. Mark
Symbol and Description
DVL-909
DVL-919E
Remarks
WY
WY
WY/RD
WY/RE
PCB ASSEMBLIES
NSP
CLDGM ASSY
VWM1806
VWM1886
VWM1886
VWM1886
P9 - 13
CLDM ASSY
VWS1332
VWS1365
VWS1365
VWS1365
1
P7 - 21
JCKB ASSY
VWV1578
VWV1639
VWV1639
VWV1639
2
P7 - 26
MSWB ASSY
VWG1895
VWG2017
VWG2017
VWG2017
3
DVDM ASSY
VWS1328
VWS1373
VWS1373
VWS1373
4
PACKING
P3 - 6
Remote Control Unit (CU-DV013)
VXX2534
Not used
Not used
Not used
P3 - 6
Remote Control Unit (CU-DV029)
Not used
VXX2608
VXX2608
VXX2608
P3 - 9
Operating Instructions
VRE1069
VRE1076
VRE1076
VRE1076
(English/French/German/Italian)
P3 - 10
Operating Instructions
VRF1043
VRF1047
Not used
Not used
(Spanish/Portuguese/Dutch/Swedish)
P3 - 11
NSP
Warranty Card
ARY7008
ARY7022
Not used
ARY7022
P3 - 15
Packing Case
VHG1724
VHG1769
VHG1769
VHG1769
P3 - 16
Label
Not used
Not used
VRW1761
VRW1756
P3 - 17
Label (Region)
VRW1701
VRW1701
VRW1705
VRW1755
FRONT PANEL SECTION
P5 - 1
Front Almi
VAH1280
VAH1304
VAH1304
VAH1304
P5 - 18
Name Plate
VAM1051
PAN1377
PAN1377
PAN1377
TOP VIEW SECTION
P7 - 9
Heat Sink
VNE2134
Not used
Not used
Not used
P7 - 10
Radiation Seat
VEB1282
Not used
Not used
Not used
BOTTOM VIEW SECTION
P9 - 29
Rear Cover
VNA1925
VNA2030
VNA2052
VNA2052
P9 - 35
Housing Assy (13P)
VKP2162
VKP2199
VKP2199
VKP2199
P9 - 39
Label (Region)
VRW1700
Not used
VRW1704
VRW1754
NOTES :
÷ Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
÷ The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷ Reference Nos. indicate the pages and Nos. in the service manual for the base model.
÷ When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex. 1
When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by
J = 5%, and K = 10%).
560
= 56 × 101= 561 ................................................... RD1/4PU 5 6 1 J
47k
= 47 × 10 3 = 473 .................................................. RD1/4PU 4 7 3 J
0.5
= R50 ...................................................................... RN2H Â 5 0 K
1
= 1R0 ......................................................................... RS1P 1 Â 0 K
Ex. 2
When there are 3 effective digits (such as in high precision metal film resistors).
5.62k
= 562 × 10 1 = 5621 ........................................... RN1/4PC 5 6 2 1 F
background image
DVL-919E
3
7 CONTRAST OF PCB ASSEMBLIES
VWS1373 and VWS1328 are constructed the same except for the following:
Mark
Symbol and Description
Remarks
Part No.
IC602
PDK026C
PDK036A
IC801
MB86371
MB86371C
IC6003
VYW1615
VYW1597
R2
RS1/16S103J
RS1/16S223J
R137, R501, R502, R505, R506, R604­R607
RA4C220J
DCN1104
(20
)
R712, R713, R719, R724, R748, R749, R791
RA4C220J
DCN1104
(20
)
R802, R803, R808, R901, R905, R907
RA4C220J
DCN1104
(20
)
R909, R910, R912, R913, R916­R919
RA4C220J
DCN1104
(20
)
R507, R508, R624, R628, R633, R703, R704
RA4C103J
DCN1094
(10
)
R717, R718, R745, R746, R761, R762, R792
RA4C103J
DCN1094
(10
)
R812, R813
RA4C103J
DCN1094
(10
)
R602, R603, R610, R613, R618
RA4C470J
DCN1090
(47
)
VWS1328
VWS1373
DVDM ASSY
F
I
7 PCB PARTS LIST
CLDM ASSY
SEMICONDUCTORS
IC761
BA10393F
IC251, IC680, IC905, IC906
BA4560F
IC203
CY2081SL-611
IC171, IC803
LA6510
IC400
LA7134M
IC801
LA9425
IC901
LA9430M
IC908
LC78625E
IC182, IC183
MM6558XF
IC221
NJM78L08A
IC222
NJM79L08A
IC351
PA0061AM
IC202
PD0236AM
IC101
PD0261A2
IC500
PD6159B
IC201
PE8001A
IC902
TA8410AK
IC181, IC410, IC762, IC907
TC4W53F
IC620
TC74HC4053AF
IC206
TC7S02F
F
J
IC102
TC7S32F
IC205, IC207
TC7SH02F
IC550
TC7SU04F
IC650
TC7W00F
IC204, IC208
TC7WU04F
Q121, Q182, Q351, Q353, Q354
2PB709A
Q356, Q411, Q451, Q456, Q461
2PB709A
Q482, Q484, Q485, Q580, Q645
2PB709A
Q672
2PB709A
Q269, Q270, Q391­Q393, Q401
2PD601A
Q425, Q441, Q481, Q486, Q626
2PD601A
Q631, Q632, Q636, Q646, Q647
2PD601A
Q655­Q658, Q661, Q662, Q671
2PD601A
Q803, Q811, Q903­Q906
2PD601A
Q834
2SA854S
Q141
2SA933S
Q152
2SC3082K
Q261, Q262
2SD2114K
Q211, Q213, Q217, Q357, Q358
PDTA124EK
Q394, Q466, Q467, Q483, Q651
PDTA124EK
Q981
PDTA124EK
Q122, Q142, Q143, Q181, Q215
PDTC124EK
Q218, Q233, Q652, Q901, Q908
PDTC124EK
D221
EC10QS04
D311, D505, D510
KV1851
Mark No.
Description
Part No.
Mark No.
Description
Part No.
background image
DVL-919E
4
Mark No.
Description
Part No.
Mark No.
Description
Part No.
D101, D141, D181, D250, D480
MA111
D650, D655, D902, D981
MA111
D355, D356
MA152WA
D115, D142, D143
UDZS5.1B
COILS AND FILTERS
F590
CHIP BEAD
DTF1069
L9231, L9232, L9584 CHIP INPEDER DTL1028
L413, L414
LAU120J
L401
LAU121J
L482
LAU180J
L352, L821­L823
LAU181J
L201, L209, L251, L311, L312
LAU220J
L351, L461, L831
LAU220J
L412, L587
LAU270J
L431, L484
LAU330J
L432
LAU390J
L433, L575
LAU430J
L411
LAU470J
L671
LAU4R7J
L462
LAU560J
L483
LAU8R2J
L832
LFA220J
L463
LFA561J
F361
684KHz FILTER
VTF1035
F362
1066KHz FILTER
VTF1036
F571
15.0MHz FILTER
VTF1068
F238­F240 CHIP SOLID INDUCTOR VTF1096
F573
14.3MHz FILTER
VTF1099
L403, L404
(22
µH)
VTL1058
L223, L230
CHIP BEADS
VTL1098
L233
CHIP BEADS
VTL1101
CAPACITORS
C229, C414, C418, C421, C429
CCSQCH100D50
C483, C543, C577
CCSQCH100D50
C353, C412, C655, C821
CCSQCH101J50
C837­C839, C843, C864, C865
CCSQCH101J50
C921, C943
CCSQCH102J50
C484
CCSQCH120J50
C413
CCSQCH121J50
C497, C569
CCSQCH150J50
C355, C494, C823, C901
CCSQCH151J50
C313, C352, C432
CCSQCH180J50
C205, C504, C509, C824, C973
CCSQCH220J50
C255, C256, C489, C555
CCSQCH221J50
C230, C354, C416, C428, C433
CCSQCH270J50
C485, C830
CCSQCH270J50
C104, C105, C257, C258, C356
CCSQCH330J50
C431, C451, C458, C579, C596
CCSQCH330J50
C456
CCSQCH360J50
C351, C405, C672
CCSQCH390J50
C671
CCSQCH391J50
C217, C222, C461
CCSQCH470J50
C371, C372, C925
CCSQCH471J50
C459
CCSQCH560J50
C941
CCSQCH561J50
C597
CCSQCH5R0C50
C358, C408, C598, C806
CCSQCH680J50
C920
CCSQCH681J50
C434­C436, C822, C829
CCSQCH7R0D50
C357, C825
CCSQCH820J50
C462
CCSQCH910J50
C123
CCSQSL102J50
C656
CEANP100M16
C629, C639
CEANP220M10
C986
CEANP3R3M50
C187, C441, C856
CEANP470M6R3
C221, C394, C975
CEAT100M50
C391, C437, C832, C834, C884
CEAT101M10
C259
CEAT102M6R3
C269, C270, C867, C929
CEAT1R0M50
C495, C927, C928, C931
CEAT220M50
C981, C982
CEAT220M50
C102, C204, C209, C223, C224
CEAT470M16
C244, C251, C316, C317, C382
CEAT470M16
C390, C802, C804, C842, C852
CEAT470M16
C854, C859, C860
CEAT470M16
C253, C254, C261­C264
CEAT470M25
C984
CEAT4R7M50
C383, C922
CEATR47M50
C936, C940
CEJA101M6R3
C902
CEJA220M50
C863, C934
CEJA2R2M50
C862
CEJA4R7M50
C439
CEV100M16
C471, C473, C475, C507, C531
CEV101M6R3
C535, C537, C539, C541, C561
CEV101M6R3
C571, C581, C591, C593
CEV101M6R3
C631
CEV470M6R3
C477
CFTLA154J50
C478
CFTLA683J50
C425, C910
CKSQYB102K50
C620, C845, C881, C917, C942
CKSQYB104K25
C506, C511, C933
CKSQYB105K10
C923
CKSQYB153K25
C911
CKSQYB154K16
C903
CKSQYB222K50
C379, C380
CKSQYB392K50
C373­C376, C388, C912, C932
CKSQYB472K50
C963
CKSQYB473K25
C763
CKSQYB682K50
C106­C112, C117, C121, C124
CKSQYF103Z50
C153, C155, C173, C181
CKSQYF103Z50
C183, C184, C188, C189, C203
CKSQYF103Z50
C206, C208, C210, C231­C235
CKSQYF103Z50
C240­C242, C245­C247
CKSQYF103Z50
C249, C250, C252, C281, C282
CKSQYF103Z50
C311, C315, C318, C359­C362
CKSQYF103Z50
background image
DVL-919E
5
Mark No.
Description
Part No.
Mark No.
Description
Part No.
C381, C386, C389, C411, C419
CKSQYF103Z50
C422, C426, C442, C452, C457
CKSQYF103Z50
C466, C505, C510, C558, C573
CKSQYF103Z50
C575, C576, C580, C583, C587
CKSQYF103Z50
C761, C762, C801, C803, C811
CKSQYF103Z50
C831, C833, C836, C841, C846
CKSQYF103Z50
C851, C853, C861, C882, C883
CKSQYF103Z50
C885, C924, C935, C937, C939
CKSQYF103Z50
C945­C947, C962, C974, C983
CKSQYF103Z50
C101, C103, C122, C151, C152
CKSQYF104Z25
C171, C172, C182, C199
CKSQYF104Z25
C267, C268, C385, C387, C392
CKSQYF104Z25
C402, C404, C430, C438, C440
CKSQYF104Z25
C445, C447, C467, C468, C472
CKSQYF104Z25
C474, C476, C491, C493, C496
CKSQYF104Z25
C498, C508, C524, C532, C536
CKSQYF104Z25
C538, C540, C542, C556, C557
CKSQYF104Z25
C562, C572, C582, C586, C589
CKSQYF104Z25
C592, C594, C622, C626­C628
CKSQYF104Z25
C630, C636, C638, C660
CKSQYF104Z25
C681­C683, C764, C805, C847
CKSQYF104Z25
C857, C858, C866, C913, C914
CKSQYF104Z25
C919, C971, C972, C976
CKSQYF104Z25
C186, C685, C855, C926, C930
CKSQYF223Z50
C938
CKSQYF223Z50
C377, C378, C908, C909
CKSQYF224Z25
C154, C156, C174, C312, C460
CKSQYF473Z50
C826, C828
CKSQYF473Z50
C265, C266
CQMBA332J50
VC301
(20pF)
VCM1008
RESISTORS
R753
RA4C221J
R203, R752
RA4C471J
R591, R592
RA4C681J
R833, R834, R837, R839
RN1/10SE1002D
R891, R892
RN1/10SE1002D
R152, R156, R618
RN1/10SE1003D
R532
RN1/10SE1100D
R425
RN1/10SE1202D
R251, R252
RN1/10SE1602D
R531
RN1/10SE1800D
R631
RN1/10SE2201D
R635
RN1/10SE2701D
R151, R259, R260, R277, R278
RN1/10SE3302D
R893, R894
RN1/10SE3302D
R153, R154
RN1/10SE4702D
R653
RN1/10SE5601D
R650
RN1/10SE6800D
VR450
(2.2k
)
PCP1025
VR603
(4.7k
)
PCP1028
VR604, VR607, VR609
(47k
)
PCP1031
Other Resistors
RS1/10S
&&&J
OTHERS
CN103, CN404 6P FFC CONNECTOR 52045-0645
CN102
10P FFC CONNECTOR 52045-1045
CN101
15P FFC CONNECTOR 52045-1545
CN802
11P CONNECTOR
B11P-SHF-1AA
CN403
KR CONNECTOR
B13B-PH-K-S
CN201
KR CONNECTOR
B4B-PH-K-S
CN202
KR CONNECTOR
B7B-PH-K-S
SCREW
BBZ30P060FCC
CN402
14P CONNECTOR
BTFN14S-3SB7
CN401
20P CONNECTOR
BTFN20S-3SB7
JA252
2P JACK
PKB1024
JA101, JA102
JACK
RKN1004
PCB BINDER
VEF1040
CN111, CN122 22P FFC CONNECTOR
VKN1253
CN801
27P FFC CONNECTOR VKN1258
SCREW PLATE
VNE1948
S102
SLIDE SWITCH
VSH1020
X101
CERAMIC RESONATOR(9MHz)
VSS1040
X311
CRYSTAL RESONATOR(16MHz)
VSS1081
X505
CRYSTAL RESONATOR(14MHz)
VSS1103
X312 CRYSTAL RESONATOR(18.432MHz) VSS1116
X510
CRYSTAL RESONATOR(15MHz)
VSS1125

Reviews

There are no reviews of this manual yet.

Related Products

Cover page of PIONEER GM-3200T/XU/EW5 Service Manual

This manual has 24 pages, file size: 2.34 MB. It's available in languages: English.

Cover page of PIONEER RX-721S Service Manual

This manual has 29 pages, file size: 30.3 MB. It's available in languages: English.

Cover page of PIONEER PDP-S47E Service Manual

This manual has 2 pages, file size: 0.51 MB. It's available in languages: English.

Cover page of PIONEER A-8 Service Manual

This manual has 10 pages, file size: 3.03 MB. It's available in languages: English.

Cover page of PIONEER F-208/SDB Service Manual

This manual has 21 pages, file size: 0.8 MB. It's available in languages: English.
