PIONEER FH2716ZF04 Service Manual

Cover page of PIONEER FH2716ZF04 Service Manual

Service Manual for PIONEER FH2716ZF04, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 18 pages
  • File size: 1.16 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001
K-ZZB. MAY 2001 Printed in Japan
ORDER NO.
CRT2698
RECEIVER ASSY RADIO
FH-2716ZF-04
X1H/UC
Service
Manual
FORD
VEHICLE
DESTINATION
PRODUCED AFTER
PART No.
ID No.
PIONEER MODEL No.
Nissan Quest
U.S.A., CANADA
May 2001
1F5F-18C868-A1A
FH-2716ZF-04/X1H/UC
Mercury Villager
- This service manual should be used together with the manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model
Order No.
Mech. Module
Remarks
CX-597
CRT1829
S7
CD Mech. Module:Circuit Description, Mech.Description, Disassembly
CX-1011
CRT2406
3L
Cassette Mech. Module:Mech.Description, Disassembly, Adjustment
FH-2716ZF/X1H/UC CRT2181
background image
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2001
K-ZZB. MAY 2001 Printed in Japan
ORDER NO.
CRT2698
RECEIVER ASSY RADIO
FH-2716ZF-04
X1H/UC
Service
Manual
FORD
VEHICLE
DESTINATION
PRODUCED AFTER
PART No.
ID No.
PIONEER MODEL No.
Nissan Quest
U.S.A., CANADA
May 2001
1F5F-18C868-A1A
FH-2716ZF-04/X1H/UC
Mercury Villager
- This service manual should be used together with the manual(s) listed below.
For the parts numbers, adjustments, etc. which are not shown in this manual,
refer to the following manual(s).
Model
Order No.
Mech. Module
Remarks
CX-597
CRT1829
S7
CD Mech. Module:Circuit Description, Mech.Description, Disassembly
CX-1011
CRT2406
3L
Cassette Mech. Module:Mech.Description, Disassembly, Adjustment
FH-2716ZF/X1H/UC CRT2181
background image
2
FH-2716ZF-04
EXPLODED VIEWS AND PARTS LIST
EXTERIOR (Page 4)
- EXTERIOR SECTION PARTS LIST
Part No.
Mark
No.
Description
FH-2716ZF/X1H/UC
FH-2716ZF-04/X1H/UC
11
Cassette Mechanism Module
EXK3285
EXK4260
22
Insulator
HNM4745
HNM0089
26
Mother Unit
HWM5104
HWM0062
35
Connector(CN702)
HKS1730
CKS3568
42
Compound Unit
HWM5956
HWM0063
background image
3
FH-2716ZF-04
ELECTRICAL PARTS LIST(Page 58)
Mother Unit
Part No.
Symbol and Description
FH-2716ZF/X1H/UC
FH-2716ZF-04/X1H/UC
IC602
IC
PE5189A
PE5250A
D501
Diode
1SS133
DAN202U
D502
Diode
1SS133
Not used
R502
RS1/10S223J
RS1/16S223J
R506
RS1/10S102J
RS1/16S102J
R507
RS1/10S222J
RS1/16S222J
R523
RS1/10S473J
RS1/16S473J
R721
RS1/10S473J
Not used
C293
CKSYB334K16
CKSQYB334K16
C295
CKSYB332K50
CKSRYB332K50
C504
CKSQYB223K50
CKSRYB223K50
C520
CKSQYB102K50
CKSRYB102K50
C530
CKSYB105K16
CKSQYB105K16
C567
CKSYB102K50
CCSRCH102J50
C1203
CKSYB563K25
CKSRYB563K16
C1205
CKSYB123K50
CKSRYB123K50
Compound Unit
Part No.
Symbol and Description
FH-2716ZF/X1H/UC
FH-2716ZF-04/X1H/UC
C207,208
CKSYB123K50
CKSRYB123K50
C213,214
CKSYB334K16
CKSQYB334K16
C215,216
CKSYB473K25
CKSRYB473K50
C217,218
CKSYB683K25
CKSRYB683K16
C223,224
CKSYB393K50
CKSRYB393K25
C228,229,231,232,273,274,275,276,277,278
CKSYB104K16
CKSRYB104K25
C253,254
CKSYB562K50
CKSRYB562K50
C255,256
CKSYB472K50
CKSRYB472K50
background image
4
FH-2716ZF-04
A
1
234
B
C
D
12
34
1
23
4
56
9
10
11
12
13
14
7
818
15
16
17
19
20
21
24
25
26
27
28
29
34
35
36
31
32
33
22
23
30
G CN701
PCB CONNECTION DIAGRAM
MOTHER UNIT (Page 42)
NOTE FOR PCB DIAGRAMS
1. The parts mounted on this PCB
include all necessary parts for
several destination.
For further information for
respective destinations, be sure
to check with the schematic dia-
gram.
2. Viewpoint of PCB diagrams
Capacitor
Connector
P.C.Board
Chip Part
SIDE A
SIDE B
MOTHER UNIT
A F
A F
background image
5
FH-2716ZF-04
5
6
7
8
A
B
C
D
5
6
7
8
SIDE A
FRONT
E CN1001
ANTENNA
B
CN251
C CN957
C CN958
CN201
F
I F
D F
A F
