XM tuner (Add-on
mode)
Display the ID code (Radio
ID)
Each XM tuner is identified with a unique
Radio ID. You will need the Radio ID when
activating XM service or when reporting a
problem. How to display the ID code depends
on the channel select mode.
Channel number select mode
If you select CH 00, the ID code is displayed.
Press
or
to select the channel
number zero (CH 00).
Channel category select mode
RADIO ID is provided as a channel category
for displaying the ID code.
Press
or
to select the RADIO ID
from channel category.
Notes
· If you select another channel, display of the
ID code is canceled.
· Display of the ID code repeats displaying
RADIO ID and the ID code one after the
other.
Radio ID
Refer to the following chart to verify each
Radio ID, before displaying them on the con-
trol unit.
En
XM tuner (Add-on
mode)
Selecting the channel in the
channel category
Channels are organized into various program
categories, e.g. Rock, Classic, Jazz. You can
search between different categories, and
then search among channels within each
channel category.
1
Select the channel category select
mode. (Refer to "Switching the channel
select mode" above.)
2
Press
or
to select the desired
channel category.
Once you select a channel category, the unit
searches for channels in that category.
During search, the channel category doesn't
immediately change even if you press the
button. To successively change the channel
category, continue pressing the button.
3
Press
or
to select the desired
channel in the selected channel category.
The channel number move up or down in the
selected channel category.
Channels that cannot currently be selected
are skipped, and the next channel in that
channel category is selected.
Note
If you select a channel of another category by
channel recall, etc., during steps 2 and 3, the
category selected in step 2 still remains in
memory. If you press
or
, the channel num-
ber moves up or down in the category selected
in step 2 regardless of the category of the pre-
sent channel.
FM modulator setting
You can adjust FM modulator frequency and
output level.
· If output from the FM modulator is hard to
hear due to interference from a strong
broadcast station transmission, you can
switch to another frequency.
· If the output sound is too quiet, too loud or
distorted, you can adjust FM modulator
output level.
1
Press POWER and hold to enter the
FM modulator setting mode.
2
Press
or
to select the desired fre-
quency.
Press
or
until the desired frequency
appears in the display.
87.9--88.1--88.3--88.5--88.7--88.9--
89.1--89.3--89.5--89.7--89.9--90.1 (MHz)
3
Press
or
to adjust the level.
Each press of
or
increases or decreases
the level.
LEVEL1 LEVEL7 is displayed as the level
is increased or decreased.
4
Press POWER and hold to cancel the
FM modulator setting mode.
Note
After entering the FM modulator setting mode,
if you do not perform an operation within about
8 seconds, the FM modulator setting is auto-
matically canceled.
En
XM tuner (Add-on
mode)
Storing and recalling chan-
nels
If you press any of the preset tuning buttons
16 you can easily store up to six channels
for later recall with the touch of a button.
· Memory and recall are for broadcasts. If
you recall a memorized broadcast that
has been moved to another channel, the
channel to which the broadcast was
moved is selected.
When you find a channel that you
want to store in memory press a preset
tuning button 16 and hold until the pre-
set number disappears.
The number you have pressed will appear in
the display and then disappears. The
selected channel has been stored in memory.
The next time you press the same preset tun-
ing button 16 the channel is recalled from
memory.
Notes
· Up to 18 channels, 6 for each of the three XM
bands can be stored in memory.
· When channel number select mode is
selected, you can also use
and
to recall
channels assigned to preset tuning buttons
16.
· If a channel you have recalled cannot be
selected, a message is displayed for 2 sec-
onds and the unit returns to the operating
status before the channel was recalled.
Switching the display
XM channels each have a channel number
and channel name. XM programing also
carries song or program title, artist name and
category, when available.
Press DISPLAY.
Press DISPLAY repeatedly to switch between
the following settings:
Channel name--Artist name/feature--
Song/program title--Channel category
Note
When you switch the display, the text is auto-
matically scrolled.
Scrolling the text in the dis-
play
You can scroll the text to the left so that the
rest of the text can be seen.
Press DISPLAY and hold until the text
begins to scroll to the left.
The rest of the text will appear in the
display.
Switching the channel
select mode
You can switch if you select a channel with a
channel number or from a channel category
when you select a channel.
Initially, channel number select mode is
selected.
Press MODE to select the desired
channel select mode.
Press MODE repeatedly to switch between
the following settings:
CH NUMBER (Channel number select
mode)--CATEGORY (Channel category
select mode)
En
XM tuner (Add-on
mode)
Listening to XM
These are the basic steps necessary to oper-
ate the XM.
Important
When using this unit for the first time, refer
to "FM modulator setting" to set the FM fre-
quency and volume appropriately.
Channel select mode indicator
Shows what channel select mode has
been selected.
Channel number indicator
Shows to which channel number the tuner
is tuned.
1
Switch to an FM source on your car
stereo and tune to the frequency set in
"FM modulator setting".
2
Press POWER to turn the unit on.
3
Press BAND to select a band.
Press BAND until the desired band is dis-
played, XM1, XM2 or XM3.
4
Press
or
to select a desired chan-
nel.
The channel number move up or down step
by step.
Channels that cannot currently be selected
are skipped, and the next channel is
selected.
If you press and hold
or
, you can
increase or decrease channel number continu-
ously.
You can also select a channel from a desired
channel category. (Refer to "Switching the
channel select mode".)
5
Press POWER to turn the unit off.
Notes
· If it is hard to hear the output sound, it may
be due to interference from a strong FM
broadcast. Refer to "FM modulator setting",
and change the setting.
· Even if you turn this unit off, the FM car
stereo remains turned on.
· When not listening to an XM broadcast, turn
this unit off. Leaving it turned on reduces the
sensitivity of your car radio.
· It may take a few seconds before you can
hear anything while this unit acquires and
processes the satellite signal when you turn
power on, change the source to XM tuner, or
select a channel.
· Display changes as follows when you switch
channels or operate in other ways. The text of
selected display* is automatically scrolled.
Channel name--Selected display*
* For details, refer to "Switching the
display".
En
ID
Display
1
2
3
4
5
6
7
8
9
0
A
B
C
D
E
F (Not used.)
----
G
H
ID
Display
I (Not used.)
----
J
K
L
M
N
O (Not used.)
----
P
Q
R
S (Not used.)
----
T
U
V
W
X
Y
Z
