PIONEER KEH-P1010R Service Manual

Cover page of PIONEER KEH-P1010R Service Manual

Service Manual for PIONEER KEH-P1010R, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 38 pages
  • File size: 5.45 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
MULTI-CD CONTROL HIGH POWER CASSETTE PLAYER WITH RDS TUNER
ORDER NO
CRT2607
K-ZZS. NOV. 2000 Printed in Japan
1. SAFETY INFORMATION
2
2. EXPLODED VIEWS AND PARTS LIST
2
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
8
4. PCB CONNECTION DIAGRAM
14
5. ELECTRICAL PARTS LIST
21
6.ADJUSTMENT
25
7. GENERAL INFORMATION
26
7.1 DIAGNOSIS
26
7.1.1 DISASSEMBLY
26
7.1.2 CONNECTOR FUNCTION DESCRIPTION
27
7.2 PARTS
28
7.2.1 IC
28
7.2.2 DISPLAY
32
7.3 OPERATIONAL FLOW CHART
33
8. OPERATIONS AND SPECIFICATIONS
34
CONTENTS
KEH-P1010R
XM/EW
KEH-P1013R XM/EW
KEH-P1010R/XM/EW
background image
PIONEER CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE INC.
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
PIONEER EUROPE NV
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2000
MULTI-CD CONTROL HIGH POWER CASSETTE PLAYER WITH RDS TUNER
ORDER NO
CRT2607
K-ZZS. NOV. 2000 Printed in Japan
1. SAFETY INFORMATION
2
2. EXPLODED VIEWS AND PARTS LIST
2
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM
8
4. PCB CONNECTION DIAGRAM
14
5. ELECTRICAL PARTS LIST
21
6.ADJUSTMENT
25
7. GENERAL INFORMATION
26
7.1 DIAGNOSIS
26
7.1.1 DISASSEMBLY
26
7.1.2 CONNECTOR FUNCTION DESCRIPTION
27
7.2 PARTS
28
7.2.1 IC
28
7.2.2 DISPLAY
32
7.3 OPERATIONAL FLOW CHART
33
8. OPERATIONS AND SPECIFICATIONS
34
CONTENTS
KEH-P1010R
XM/EW
KEH-P1013R XM/EW
KEH-P1010R/XM/EW
background image
2
KEH-P1010R,P1013R
1. SAFETY INFORMATION
CAUTION
This service manual is intended for qualified service technicians; it is not meant for the casual do-it-yourselfer.
Qualified technicians have the necessary test equipment and tools, and have been trained to properly and safely
repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may void the warranty.
If you are not qualified to perform the repair of this product properly and safely; you should not risk trying to do so
and refer the repair to a qualified service technician.
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
background image
3
KEH-P1010R,P1013R
NOTE
Parts marked by "*" are generally unavailable because they are not in our Master Spare Parts List.
Mark No. Description
Part No.
Mark No. Description
Part No.
1 Carton
CZH5577
2 Owner's Manual
CZR2940
3 Installation Manual
CZR2941
*
4 Warranty Card
CRY1157
*
5 Passport
CRY1013
6 Protector
CHP1623
7 Protector
CHP1622
8 Polyethylene Bag
CZE2903
9 Cord Assy
CZD2977
10 Case Assy
CXB3520
11 Owner's Manual
CZR2942
*
12 Accessory Assy
CEA2397
13 Bush
CNV3930
14 Screw
CBA1002
15 Handle
CNC5395
16 Polyethylene Bag
E36-615
17 Contain Box
CZH5578
KEH-P1013R/XM/EW
Mark No. Description
Part No.
Mark No. Description
Part No.
1 Carton
CZH5579
2 Owner's Manual
CZR2940
3 Installation Manual
CZR2941
*
4 Warranty Card
CRY1157
*
5 Passport
CRY1013
6 Protector
CHP1623
7 Protector
CHP1622
8 Polyethylene Bag
CZE2903
9 Cord Assy
CZD2977
10 Case Assy
CXB3520
11 Owner's Manual
CZR2942
*
12 Accessory Assy
CEA2397
13 Bush
CNV3930
14 Screw
CBA1002
15 Handle
CNC5395
16 Polyethylene Bag
E36-615
17 Contain Box
CZH5580
Owner's Manual,Installation Manual
Part No.
CZR2940
CZR2941
CZR2942
English, Spanish, German
English, Spanish, German, French, Italian, Dutch
French, Italian, Dutch
Language
PACKING SECTION PARTS LIST
KEH-P1010R/XM/EW
background image
4
KEH-P1010R,P1013R
2.2 EXTERIOR
background image
5
KEH-P1010R,P1013R
3
4
6
25
26
27
33
64
Grille Unit
Cover
Keyboard Unit
Grille
Plate Assy
Panel
Door
Chassis
CZX5512
CZN6753
CZW5522
CZN6746
CZX5507
CZN6756
CA T2109
CZN6736
CZX5513
CZN6754
CZW5521
CZN6747
CZX5508
CZN6757
CA T2108
CZN6737
1 Case
CZN6739
*
2 Label
CZA5543
3 Grille Unit
See Contrast table(2)
4 Cover
See Contrast table(2)
5 Screw
BPZ20P100FZK
6 Keyboard Unit
See Contrast table(2)
7 Connector(CN900)
CKS3580
8 Holder
CZN6759
9 Rubber
CZN6744
10 Lighting Conductor
CZN6758
11 Sheet
CZN6760
12 Connector
CZN6745
13 LCD(LCD900)
CZA5541
14 Holder
CZN6743
15 Button (SOURCE)
CZA5535
16 Button (CROSS)
CZA5532
17 Button (EJECT)
CZA5531
18 Spring
CZB2976
19 Button (1-6)
CZA5533
20 Button (REW)
CZA5530
21 Button (FF)
CZA5529
22 Button (EQ)
CZA5534
23 Spring
CZB2977
24 Button
CAC5789
25 Grille
See Contrast table(2)
26 Plate Assy
See Contrast table(2)
27 Panel
See Contrast table(2)
28 Bracket
CNC6135
29 Spring
CBH1834
30 Arm
CNV4692
31 Arm
CNV4693
32 Spring
CBH2126
33 Door
See Contrast table(2)
34 Arm
CNV4728
35 Spring
CBH1835
36 Bracket
CNC6791
37 Screw
IMS20P030FZK
38 Button
CAC4836
39 Spring
CBH1996
40 Screw
BSZ26P060FMC
41 Mechanism
CZX5514
42 Bracket
CZN6738
43 Screw
BMZ26P040FMC
44 Tuner Amp Unit
CZW5519
45 Panel
CZN6741
46 Screw
BSZ26P100FMC
47 Heat Sink
CZN6740
48 IC(IC500)
TA8277H
49 Screw
BPZ26P100FZK
50 Screw
ISS26P055FUC
51 Terminal(G1)
CKF1059
52 Connector(CN600)
CKS3408
53 Connector(CN200)
CZK2943
54 Fuse(10A)
CEK1208
55 Choke Coil (L700)
CTH1221
56 Pin Jack(CN700)
CKB1041
57 Antenna Jack(CN100)
CKX1056
58 Plag (CN300)
CZK2946
59 Connector(CN800)
CKS3581
60 Plug (CN350)
CZK2945
61 Plate
CZN6730
62 FM/AM Tuner Unit
CHX1442
63 Insulator
CZN6742
64 Chassis
See Contrast table(2)
65 Cord Assy
CZD2977
66 Holder Unit
CXB6681
Mark No. Description
Part No.
Mark No. Description
Part No.
(1)EXTERIOR SECTION PARTS LIST
KEH-P1010R/XM/EW and KEH-P1013R/XM/EW have the same construction except for the following:
(2)CONTRAST TABLE
Mark No.
Symbol and Description
KEH-P1010R/XM/EW
KEH-P1013R/XM/EW
Part No.
