Operation Manual
Multi-CD control High power Cassette player with FM/
AM tuner
KEH-P7035
English
Portugu
ês
(B)
Español
background image
Operation Manual
Multi-CD control High power Cassette player with FM/
AM tuner
KEH-P7035
English
Portugu
ês
(B)
Español
background image
Thank you for buying this Pioneer product.
Please read through these operating instructions so you will know how to operate
your model properly. After you have finished reading the instructions, put them away
in a safe place for future reference.
Before You Start
About this manual 4
Precautions 4
Use and care of the remote control 4
Installing the battery 4
Using the remote control 4
Protecting your unit from theft 5
Removing the front panel 5
Attaching the front panel 5
About the demo mode 5
Reverse mode 6
Feature demo 6
Whats What
Head unit 7
Remote control 8
Power ON/OFF
Turning the unit on 9
Selecting a source 9
Turning the unit off 9
Tuner
Listening to the radio 10
Introduction of advanced tuner
operation 11
Storing and recalling broadcast
frequencies 11
Tuning in strong signals 11
Storing the strongest broadcast
frequencies 12
Cassette Player
Playing a tape 13
Introduction of advanced cassette player
operation 14
Repeating play 14
Skipping blank tape sections 15
Radio intercept 15
Using Dolby noise reduction 15
Multi-CD Player
Playing a CD 16
50-disc multi-CD player 16
Introduction of advanced multi-CD player
operation 17
Repeating play 17
Playing tracks in a random order 17
Scanning CDs and tracks 18
Pausing CD playback 18
Using ITSplaylists 18
Creating a playlist with ITS
programming 18
Playback from your ITSplaylist 19
Erasing a track from your ITS
playlist 19
Erasing a CD from your ITS
playlist 19
Using disc title functions 20
Entering disc titles 20
Displaying disc titles 21
Selecting discs from the disc title
list 21
Using CD TEXT functions 21
Displaying titles on CD TEXT
discs 21
Scrolling titles in the display 21
Using compression and bass emphasis 21
Audio Adjustments
Introduction of audio adjustments 23
Setting the sound focus equalizer
(SFEQ) 23
Using balance adjustment 24
Using the equalizer 24
Recalling equalizer curves 24
Adjusting equalizer curves 25
Fine adjusting equalizer curve 25
Contents
En
2
background image
Adjusting bass 26
Adjusting treble 26
Adjusting loudness 26
Using subwoofer output 26
Adjusting subwoofer settings 27
Using non fading output 27
Adjusting non fading output level 27
Using the high pass filter 27
Adjusting source levels 28
Using automatic sound levelizer 28
Initial Settings
Adjusting initial settings 29
Setting the clock 29
Setting the FM tuning step 29
Setting the AM tuning step 30
Switching the warning tone 30
Switching the auxiliary setting 30
Switching the dimmer setting 30
Adjusting the brightness 30
Setting the rear output and subwoofer
controller 31
Switching the telephone muting/
attenuation 31
Other Functions
Turning the clock display on or off 32
Using the AUX source 32
Selecting AUX as the source 32
Setting the AUX title 32
Using different entertainment displays 33
Additional Information
Cassette tapes 34
Cleaning the playback head 34
Music search and repeat functions during
tape playback 34
Specifications 35
En
3
English
Contents
background image
About this manual
This unit features a number of sophisticated
functions ensuring superior reception and op-
eration. All the functions have been designed
for the easiest possible use, but many are not
self-explanatory. This operation manual will
help you benefit fully from this productspo-
tential and to maximize your listening enjoy-
ment.
We recommend that you familiarize yourself
with the functions and their operation by read-
ing through the manual before you begin
using this unit. It is especially important that
you read and observe precautions on this
page and in other sections.
Precautions
! Keep this manual handy as a reference for
operating procedures and precautions.
! Always keep the volume low enough so you
can hear sounds outside of the car.
! Protect this product from moisture.
! If the battery is disconnected or dis-
charged, the preset memory will be erased
and must be reprogrammed.
! If this unit does not operate properly, con-
tact your dealer or nearest authorized Pio-
neer Service Station.
Use and care of the remote
control
Installing the battery
Slide the tray out on the back of the remote
control and insert the battery with the plus (+)
and minus () poles pointing in the proper di-
rection.
WARNING
Keep the battery out of the reach of children.
Should the battery be swallowed, immediately
consult a doctor.
CAUTION
! Use only one CR2025 (3 V) lithium battery.
! Remove the battery if the remote control is not
used for a month or longer.
! Do not recharge, disassemble, heat or dispose
of the battery in fire.
! Do not handle the battery with metallic tools.
! Do not store the battery with metallic materi-
als.
! In the event of battery leakage, wipe the re-
mote control completely clean and install a
new battery.
! When disposing of used batteries, please
comply with governmental regulations or en-
vironmental public institutions rules that
apply in your country/area.
Using the remote control
Point the remote control in the direction of the
front panel to operate.
Before You Start
En
4
Section
01
HHHHHHHHHHHHHH
background image
Important
! Do not store the remote control in high tem-
peratures or direct sunlight.
! The remote control may not function properly
in direct sunlight.
! Do not let the remote control fall onto the
floor, where it may become jammed under the
brake or accelerator pedal.
Protecting your unit from
theft
The front panel can be detached from the
head unit and stored in the protective case
provided to discourage theft.
! If the front panel is not detached from the
head unit within five seconds of turning off
the ignition, a warning tone will sound.
! You can turn off the warning tone. See
Switching the warning tone on page 30.
Important
! Never use force or grip the display and the
buttons tightly when removing or attaching.
! Avoid subjecting the front panel to excessive
shocks.
! Keep the front panel out of direct sunlight and
high temperatures.
Removing the front panel
1 Press OPEN to open the front panel.
2 Grip the left side of the front panel and
pull it gently outward.
Take care not to grip it tightly or drop it.
3 Put the front panel into the protective
case provided for safe keeping.
Attaching the front panel
% Replace the front panel by holding it
upright to this unit and clipping it securely
into the mounting hooks.
About the demo mode
This unit features two demonstration modes.
One is the reverse mode, the other is the fea-
ture demo mode.
! You cannot cancel a demo mode when the
front panel is open.
Important
The red lead (ACC) of this unit should be con-
nected to a terminal coupled with ignition switch
on/off operations. If this is not done, the vehicle
battery may be drained.
Before You Start
En
5
English
Section
01
HHHHHHHHHHHHHH
