2
KEX-M8017ZT,M8017ZT-91
- Dolby noise reduction manufactured under license from Dolby Laboratories Licensing Corporation.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories Licensing Corporation.
- This service manual does not describe the CD test mode.
For the operations in the CD test mode, refer to the CD player's Service Manual.
- KEX-M8017ZT/ES have adopted AVC-LAN.
KEX-M8017ZT/ES
CONTENTS
1. SAFETY INFORMATION ............................................3
2. EXPLODED VIEWS AND PARTS LIST .......................4
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM .....8
4. PCB CONNECTION DIAGRAM ................................20
5. ELECTRICAL PARTS LIST ........................................28
6. ADJUSTMENT..........................................................34
7. GENERAL INFORMATION .......................................38
7.1 DIAGNOSIS .......................................................38
7.1.1 CONNECTOR FUNCTION DESCRIPTION ..38
7.1.2 TROUBLESHOOTING................................39
7.2 IC ........................................................................40
7.3 EXPLANATION..................................................43
7.3.1 SYSTEM BLOCK DIAGRAM ...................43
7.3.2 OPERATION FLOW CHART.....................44
8. SPECIFICATIONS......................................................45
- Supplementary model is identical to the original except for the addition of following items.
Description
Part No.
KEX-M8017ZT-91/ES
Polyethylene Bag
CEG-162
Cover
CEG1045
Carton
CHA1721
Contain Box
CHL3223
ID No.P2727
- This service manual should be used together with the following manual(s):
Model
Order No.
Mech. Module
Remarks
CX-631
CRT1640
2L
Cassette Mech. Module:Mech.Description, Disassembly
