PIONEER KRP-WM02/S/WL5 Service Manual

Cover page of PIONEER KRP-WM02/S/WL5 Service Manual

Service Manual for PIONEER KRP-WM02/S/WL5, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 3 pages
  • File size: 0.43 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
KRP-WM02
ARP3515
T-ZZR AUG. 2008 Printerd in Japan
WALL MOUNT UNIT
KRP-WM02
/S/WL5
(AZR1296)
1.2 SPECIFICATIONS
1.1 ACCESSORIES
· Wall side fittings × 1
· Screw Set
· Inst. Manual Set
· Operating Instructions × 1
(AZR1282)
· Label (Marking) × 1
· Hexagon Wrench × 1
(6 mm for M8 use)
(AZE1143)
· Display Side Fitting × 2
(AZN2833)
· Washer × 8
(AZB1576)
· Bolt (M8 × 20 mm) × 4
(AZB1485)
External dimensions:
KRP-WM02 ............. 645 mm (W) × 516 mm (H) × 22 mm (D) (25-13/32 in. (W) × 20-5/16 in. (H) × 7/8 in. (D))
Weight:
KRP-WM02 ............. 3.7 kg (8.2 lbs) (fittings only)
1. SPECIFICATIONS
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2008
KRP-WM02
ARP3515
T-ZZR AUG. 2008 Printerd in Japan
WALL MOUNT UNIT
KRP-WM02
/S/WL5
(AZR1296)
1.2 SPECIFICATIONS
1.1 ACCESSORIES
· Wall side fittings × 1
· Screw Set
· Inst. Manual Set
· Operating Instructions × 1
(AZR1282)
· Label (Marking) × 1
· Hexagon Wrench × 1
(6 mm for M8 use)
(AZE1143)
· Display Side Fitting × 2
(AZN2833)
· Washer × 8
(AZB1576)
· Bolt (M8 × 20 mm) × 4
(AZB1485)
External dimensions:
KRP-WM02 ............. 645 mm (W) × 516 mm (H) × 22 mm (D) (25-13/32 in. (W) × 20-5/16 in. (H) × 7/8 in. (D))
Weight:
KRP-WM02 ............. 3.7 kg (8.2 lbs) (fittings only)
1. SPECIFICATIONS
background image
2
KRP-WM02
12
3
4
C
D
F
A
B
E
1
23
4
2. EXPLODED VIEWS AND PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
NOTES:
2.1 PACKING
(1/9)
(4/9)
(7/9)
(9/9)
(8/9)
(6/9)
(2/9)
(5/9)
(3/9)
1
Packing Set
AZH1337
NSP 2
1..Inst. Manual Set
- - - - - - - -
2..Label (Marking) x 1
AZR1296
2..Operating Instructions
AZR1282
(Japanese/English/French/Spanish/
German/Italian/ Dutch/Chinese/Russian)
NSP 3
1..Screw Set
- - - - - - - -
2..Bolt (M8 x 20 mm) x 4
AZB1485
2..Washer x 8
AZB1576
2..Hexagon Wrench x 1
AZE1143
4
Display Side Fitting x 2
AZN2833
PACKING Parts List
Mark No.
Description
Part No.
Mark No.
Description
Part No.
background image
3
KRP-WM02
5
67
8
5
6
7
8
C
D
F
A
B
E
3. SETTING
Hang the hooks at the top of the display side fittings.
UP
Rear
Display
Side Fitting
Front
Cables
Fall prevention
Screw
Sheet
Display
Side Fitting
Bolt
(M8 x 20 mm)
Bolt
(M8 x 20 mm)
