PD-F907
2
1. CONTRAST OF MISCELLANEOUS PARTS
CONTRAST TABLE
KUXQ and KU types are constructed the same except for the following :
PACKING
P3-6
Oerating Instructions (English)
PRB1263
PRB1268
P3-11
Packing Case
PHG2285
PHG2320
P3-12
Mirror Mat
Z23-020
Not used
P3-12
Packing Sheet
Not used
PHF1001
EXTERIOR
P6-18
Rear Base
PNA2389
PNA2430
P6-21
Back Fence
PNW2671
PNW2848
P6-26
Hood Base
PNW2633
PNW2847
P6-35
Disc Rack
PNW2632
PNW2845
P6-36
Mecha Base
PNW2639
PNW2851
P6-50
Operation Panel
PNW2773
PNW2849
P6-52
Hood
PNW2732
PNW2850
Ref.
No.
Remarks
KU type
KUXQ type
Part No.
Mark
Symbol and Description
NOTES :
÷ Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
÷ The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing,be sure to use parts of identical designation.
÷ Reference Nos. indicate the pages and Nos. in the service manual for the base model.
÷ Screw adjacent to mark on the product are used for disassembly.
÷ When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex. 1
When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by
J = 5%, and K = 10%).
560
= 56 × 101= 561 ................................................... RD1/4PU 5 6 1 J
47k
= 47 × 10 3 = 473 .................................................. RD1/4PU 4 7 3 J
0.5
= R50 ...................................................................... RN2H Â 5 0 K
1
= 1R0 ......................................................................... RS1P 1 Â 0 K
Ex. 2
When there are 3 effective digits (such as in high precision metal film resistors).
5.62k
= 562 × 10 1 = 5621 ........................................... RN1/4PC 5 6 2 1 F
