PIONEER PD-F908/RDXQ Service Manual

Cover page of PIONEER PD-F908/RDXQ Service Manual

Service Manual for PIONEER PD-F908/RDXQ, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 8 pages
  • File size: 0.51 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1999
FILE-TYPE COMPACT DISC PLAYER
RRV2120
T­ZZR APR. 1999 Printed in Japan
PD-F908
¶ Refer to the service manual RRV2085 for PD-F908/KUXQ.
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
1. CONTRAST OF MISCELLANEOUS PARTS ..... 2
2. SCHEMATIC DIAGRAM .................................... 6
CONTENTS
RDXQ
AC110­127V/ 220­ 240V
With the voltage selector
The voltage can be converted by the following method.
Power Requirement
Type
Model
PD-F908
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER ELECTRONIC CORPORATION 1999
FILE-TYPE COMPACT DISC PLAYER
RRV2120
T­ZZR APR. 1999 Printed in Japan
PD-F908
¶ Refer to the service manual RRV2085 for PD-F908/KUXQ.
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
1. CONTRAST OF MISCELLANEOUS PARTS ..... 2
2. SCHEMATIC DIAGRAM .................................... 6
CONTENTS
RDXQ
AC110­127V/ 220­ 240V
With the voltage selector
The voltage can be converted by the following method.
Power Requirement
Type
Model
PD-F908
background image
PD-F908
2
NSP
MOTHER BOARD ASSY
PWM2266
PWM2267
P6-1
MAIN BOARD ASSY
PWZ3876
PWZ3877
P6-2
POWER BOARD ASSY
PWZ3879
PWZ3880
P6-4
NSP
SWITCH BOARD ASSY
PWZ3885
PWZ3886
PACKING
P3-5
NSP
Warranty Card
ARY7023
Not used
P3-11
Packing Case
PHG2334
PHG2336
NSP
Caution 220V Card
Not used
ARR7003
No.1
Index Label 100
Not used
PRW1406
No.2
Jacket File
Not used
PHN1049
No.3
Operating Instructions
Not used
PRD1035
No.4
(Spanish/Chinese)
EXTERIOR
P6-10
Cord Stopper
CM-22C
CM-22B
P6-12
AC Power Cord
PDG1064
ADG1157
P6-13
Rubber Sheet
AEB1111
Not used
P6-18
Rear Base
PNA2450
PNA2451
P6-20
Insulator
Not used
PNW2766
(X2)
P6-50
Operation Panel
PNW2867
PNW2868
P6-55
65 Label
ARW7050
Not used
LED Lens
Not used
PNW2019
No.5
1. CONTRAST OF MISCELLANEOUS PARTS
NOTES :
÷ Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
÷ The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷ Reference Nos. indicate the pages and Nos. in the service manual for the base model.
÷ When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex. 1
When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by
J = 5%, and K = 10%).
560
= 56 × 101= 561 ................................................... RD1/4PU 5 6 1 J
47k
= 47 × 10 3 = 473 .................................................. RD1/4PU 4 7 3 J
0.5
= R50 ...................................................................... RN2H Â 5 0 K
1
= 1R0 ......................................................................... RS1P 1 Â 0 K
Ex. 2
When there are 3 effective digits (such as in high precision metal film resistors).
5.62k
= 562 × 10 1 = 5621 ........................................... RN1/4PC 5 6 2 1 F
7 CONTRAST TABLE
PD-F908/ RDXQ and KUXQ are constructed the same except for the following:
Note :
÷ The numbers in the remarks column correspond to the numbers on the exploded diagram, Refer to "EXPLODED VIEWS".
PCB ASSEMBLIES
Ref.
No.
Remarks
PD-F908/
PD-F908/
KUXQ
RDXQ
Part No.
Mark
Symbol and Description
background image
PD-F908
3
EXTERIOR SECTION
EXPLODED VIEWS
PACKING SECTION
No.2
No.3
No.4
No.1
Packing Case
Front
Operating lnstructions (English)
Protecter (FR)
Protecter (FL)
Protecter (RL)
Protecter (RR)
Control Cable
Rear Base
AC Power Cord
Under Base
Screw (IBZ30P080FZK)
No.5
Operation Panel
Cord Stopper
lnsulator
background image
PD-F908
4
C17
Not used
CKCYF103Z50
S05
Not used
PSB1006
POWER TRANSFORMER
PTT1318
PTT1320
C319, C364, C398
Not used
CKCYF103Z50
C399
CKCYF103Z50
Not used
C389, C397
CCCSL101J50
Not used
C393, C1301
Not used
CCCSL101J50
L392
Not used
LAU1R0J
L393
LAU1R0J
Not used
R316, R317, R3252
Not used
RD1/4PU221J
Note : Refer to "2.SCHEMATIC DIAGRAM".
Mark
Symbol and Description
Part No.
PWZ3879
PWZ3880
Remarks
Note : Refer to "2.SCHEMATIC DIAGRAM".
D751
Not used
PCX1019
R751
Not used
RD1/4PU471J
Mark
Symbol and Description
Part No.
PWZ3885
PWZ3886
Remarks
SWITCH BOARD ASSY
PWZ3886 and PWZ3885 are constructed the same except for the following:
Note : Refer to "2.SCHEMATIC DIAGRAM".
POWER BOARD ASSY
MAIN BOARD ASSY
PWZ3877 and PWZ3876 are constructed the same except for the following:
CONTRAST OF PCB ASSEMBLIES
Mark
Symbol and Description
Part No.
PWZ3876
PWZ3877
Remarks
PWZ3880 and PWZ3879 are constructed the same except for the following:
O F
J F
K F
background image
PD-F908
5
