PDK-TS10
Operating instructions
Mode d'emploi
Manual de instrucciones
Table top stand
Support de couverture de table
Soporte de mesa
background image
PDK-TS10
Operating instructions
Mode d'emploi
Manual de instrucciones
Table top stand
Support de couverture de table
Soporte de mesa
background image
2
En
Thank you for buying Pioneer's product.
Please read through the Operating Instructions to learn how
to operate your model safely and properly.
Please be advised to keep the Operating Instructions in your
place for future reference.
Contents
Cautions ...................................................................... 2
Checking the Standard Accessories ......................... 3
Assembling the Stand ............................................... 3
Attaching the Plasma Display ................................... 4
Installing the Product on a Rack etc. ........................ 5
Preventing Equipment from Falling Over ................ 5
Specifications ............................................................. 6
Dimensions Diagram ................................................. 7
Installation
¶ Consult your dealer if you encounter any difficulties with
this installation.
¶ Pioneer is not liable for any damage resulting from
improper installation, improper use, modification, or
natural disasters.
Cautions
This product is a table top stand exclusively designed for
Plasma Displays (PDP-5050SX / PDP-4350SX) from Pioneer.
Use with other model is capable of resulting in instability
causing possible injury. For further information, please
contact the store where you purchased your display.
Do not install or modify the product other than specified. Do
not use this stand for a Plasma Display other than those
designated and do not modify it or use it for other purposes.
Improper installation is extremely dangerous because it may
result in it falling over or other accident.
Installation Location
· Select a location that is strong enough to support the
weight of the stand and the displays.
· Make sure to place it in a level and stable location.
· Do not install it outdoors, at a hot spring, or near a beach.
· Do not install the stand where it may be subjected to
vibration or shock.
Assembling and Installation
· Assemble the stand in accordance with the assembly
instructions and securely attach all screws at the
designated locations.
There have been cases where unforeseen accidents
such as the equipment breaking or falling over oc-
curred after the installation of the display because the
stand was not installed as instructed.
· The display must always be installed by two or more
people to assure it is installed safely.
· Before installation, turn off the power for the display
and peripheral devices then remove the power cord
plug from the power outlet.
Prevent accidents caused by the product falling over by taking
reliable measures to prevent it from falling over (see Pages 5 to
6).
CAUTION
This symbol refers to a hazard or unsafe practice which
can result in personal injury or property damage.
IMPORTANT NOTICE
Record the model number and serial number of this
equipment below.
Model No. PDK-TS10
Serial No.
Keep these numbers for future use.
background image
3
En
English
Checking the Standard Accessories
Check to make sure that you have all the standard accessories before assembly and installation.
Base cover x 1
Stand pipes
(left and right, interchangeable) x 2
Hexagonal wrench x 1
(Opposite side 6 mm for M8 use)
Screws 1 (4 x 10 mm) x 4
Installation bolts 2
(M8 x 20 mm: black) x 2
Installation bolts 3
(M8 x 40 mm: black) x 2
Operating instructions
(this document) x 1
PDK-TS10
Operating instructions
Mode d'emploi
Manual de instrucciones
Table top stand
Support de couverture de table
Soporte de mesa
Assembling the Stand
1 Turn the base cover over so the
underside is facing up.
2 Insert the stand pipes into the base
cover.
3 Tighten the screws to stabilize the
stand pipes.
Base cover
Screws 1
(4 x 10 mm)
Stand pipe
Screws 1
(4 x 10 mm)
Stand pipe
Assembly Procedure
background image
4
En
The weight of a 50 inch Plasma Display is about 40 kg (88 lbs),
that of a 43 inch model is about 30 kg (66 lbs), they have no
depth, and are unstable. Therefore, at least two people must
assemble and install them.
Note
Insert the bolts in the holes vertically and do not tighten
them with more force than necessary.
Place a sheet or protective cover to protect the display from
scratches or damage.
Assemble only with the Plasma Display lying flat on a table
or similar surface.
Move the stand so that the stand screw holes and the nuts
that connect the main display line up correctly.
1 With the Plasma Display lying flat, insert
and secure the two Installation bolts 2 (M8
x 20 mm: black) in the holes "a" located in
center of the Plasma Display housing.
At this point, tighten these bolts 2 only until the threads
are no longer visible when viewed from the side (you will
be unable to attach the display if the bolts are screwed in
completely).
Attaching the Plasma Display
Plasma Display
Installation
bolt 2
Plasma Display
housing
Stop screwing
down the bolt
when the threads
are no longer
visible.
Installation bolt 2
(M8 x 20 mm: black)
Sheet
Holes "a"
(holes in center
of Plasma
Display)
7 Regarding the stand pipe screw holes when the
stand is used as a desktop stand
Table: Stand pipe screw holes when the stand is used as a
desktop stand
Plasma Display model
43 inch display model
50 inch display model
Screw holes used with stand orientation
A, A'
B, B'
B
A
B
´
A
´
B
A
B
´
A
´
2 As shown in the above figure, hook the
stand pipe holes (either pipe A or B) onto
the screw heads of the installation bolts 2,
then slide the stand upwards to the main
Plasma Display until it engages the installa-
tion bolts 2 (once put together with the
display, the stand will slides no more than
19 mm (3/4 inch)).
3 Pass the installation bolts 3 (M8 x 40 mm:
black) through the stand pipes and tighten
the installation bolts firmly with the
accessory hexagonal wrench (The holes
should be used in the proper combinations,
A­A' and B­B').
4 Tighten the installation bolts 2 firmly with
the accessory hexagonal wrench.
Installation bolts 3
(M8 x 40 mm: black) (Step 3)
Slide the stand
(Step 2)
Table top stand
Caution
background image
5
En
English
Installing the Product on a Rack etc.
When installing on a rack etc.,
hold the Plasma Display. If you
hold the speakers, they may be
damaged or twisted.
Min. 20 mm
(13/16 inch)
6
mm
(1/4
inch)
9
to
15
mm
(3/8
to
5/8
inch)
Stabilizing on table or floor
Stabilize the equipment as shown in the diagram using
screws that are available on the market.
Note
To stabilize the equipment on a
table or on the floor, use screws
that have a nominal diameter of 6
mm (1/4 inch) and that are at
least 20 mm (13/16 inch) long.
After installing the stand, be sure to take special care to ensure that the equipment will not fall over.
Position of table/floor screws
When stabilizing the stand to a table or the floor, use M6
with a length above 20 mm (13/16 inch).
Unit: mm (inch)
* : 50 inch display model
** : 43 inch display model
120
(4-23/32)
575 (22-5/8)*
500 (19-21/32)**
301
(11-27/32)
24
(1)
Preventing Equipment from Falling Over
Caution
When holding the Plasma Display
erect:
When laying down the Plasma
Display:
Dimension without speakers
11
(13/32)
Side View
