ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
PDK-TS28
ARP3448
TABLE TOP STAND
PDK-TS28
XZC/WL5, WL5
Specifications
External dimensions:
Weight:
PDK-TS28 ................ 550 mm (W) × 385.5 mm (H) × 300 mm (D) (21-21/32 in. (W) × 15-3/16 in. (H) × 11-13/16 in. (D))
PDK-TS28 ................ 2.2 kg (4.9 lbs)
Base Cover × 1
(AZN2755)
Screws
(4 mm x 10 mm : Silver) × 4
Fall-prevention Straps × 2
Fall-prevention Straps
Assy (AZE1202)
Operating Instructions
x 1 : (AZR1264)
(M8 x 40 mm: black) × 2
[for 50 inch display model]
Installation Screws
(M8 x 23 mm: black) × 2
Stand Pipe (L) × 1
(AZN2756)
Stand Pipe (R) × 1
(AZN2757)
Installation Screws
Screws
Screw Set(AZE1200)
( M4 x 10 mm : Black) × 2
Parts Included
T-ZZR APR. 2007 Printed in Japan
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
PDK-TS28
ARP3448
TABLE TOP STAND
PDK-TS28
XZC/WL5, WL5
Specifications
External dimensions:
Weight:
PDK-TS28 ................ 550 mm (W) × 385.5 mm (H) × 300 mm (D) (21-21/32 in. (W) × 15-3/16 in. (H) × 11-13/16 in. (D))
PDK-TS28 ................ 2.2 kg (4.9 lbs)
Base Cover × 1
(AZN2755)
Screws
(4 mm x 10 mm : Silver) × 4
Fall-prevention Straps × 2
Fall-prevention Straps
Assy (AZE1202)
Operating Instructions
x 1 : (AZR1264)
(M8 x 40 mm: black) × 2
[for 50 inch display model]
Installation Screws
(M8 x 23 mm: black) × 2
Stand Pipe (L) × 1
(AZN2756)
Stand Pipe (R) × 1
(AZN2757)
Installation Screws
Screws
Screw Set(AZE1200)
( M4 x 10 mm : Black) × 2
Parts Included
T-ZZR APR. 2007 Printed in Japan
background image
PDK-TS28
2
12
3
4
12
3
4
C
D
F
A
B
E
1. EXPLODED VIEWS AND PARTS LIST
1.1 PACKING
PACKING parts List
NOTES :
· Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
· The
> mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Tape
Tape
Packing Case
Protecter / Top
Protecter / Middle
Protecter
/ Sheet
Protecter / Bag
Protecter / Bag
Protecter
Mark No.
Description
Part No.
1
Packing Set ( WL5)
AZH1308
1
Packing Set ( XZC/WL5)
AZH1309
2
. . . .
3
. . . .
4
. . . .
5
1..Screw Set
AZE1200
NSP
2..Screws (4 x 10) x 4
NSP
2..Installation Screws (M8 x 40) x 2
NSP
2..Installation Screws (M8 x 23) x 2
6
1..Fell-prevention Straps Assy AZE1202
2..Belt Assy
NSP
2..Screws (M4 x 10) x 2
7
Operating Instructions
AZR1264
(English/French/Spanish/German/
Italian/ Dutch/Chinese)
Mark No.
Description
Part No.
background image
PDK-TS28
3
5
678
56
7
8
C
D
F
A
B
E
1.2 EXTERIOR SECTION
EXTERIOR parts List
Sheet
Front
Rear
Screws
(4 mm x 10 mm: Silver)
Screws
(4 mm x 10 mm: Silver)
Completed
Table Top Stand
Mark No.
Description
Part No.
1
Base Cover
AZN2755
2
Stand Pipe Assy (L)
AZN2756
3
Stand Pipe Assy (R)
AZN2757
4
Rubber
AZE1198
