Thank you for buying Pioneer's product.
Please read through the Operating Instructions to learn how
to operate your model safely and properly.
Please be advised to keep the Operating Instructions in
your place for future reference.
Installation
· Consult your dealer if you encounter any difficulties
with this installation.
· Pioneer is not liable for any damage resulting from
improper installation, improper use, modification, or
natural disasters.
Contents
Cautions ................................................................... 2
Checking the Enclosed Parts................................... 3
Assembling the Stand ............................................. 4
Attaching the Pioneer Television ........................... 5
Forward/Backward Angle of Inclination
Adjustment Mechanism .......................................... 6
Installing the Product on a TV table etc. ............... 7
Preparing the Cables ............................................... 8
Preventing Equipment from Falling Over .............. 9
Fixing the rotation to the front............................ 10
Detaching the Pioneer Television from
the Stand ................................................................ 10
Specifications ......................................................... 10
Dimensions Diagram ............................................. 11
Cautions
This product is a table top stand exclusively designed
for Pioneer televisions (PDP-5020FD / PDP-111FD / PDP-
LX5090H / PDP-LX5090 / PDP-LX509A / PDP-C509A).
Use with other model is capable of resulting in instability
causing possible injury. For further information, please
contact the store where you purchased your display.
Do not install or modify the product other than specified. Do
not use this stand for a Pioneer television other than those
designated and do not modify it or use it for other purposes.
Improper installation is extremely dangerous because it may
result in it falling over or other accident.
Installation Location
· Select a location that is strong enough to support the
weight of the stand and the displays.
· Make sure to place it in a level and stable location.
· Do not install it outdoors or in a wet place such as at a
hot spring or near a beach.
· Do not install the stand where it may be subjected to
vibration or shock.
Assembling and Installation
· Assemble the stand in accordance with the assembly
instructions and securely attach all screws at the
designated locations.
There have been cases where unforeseen accidents
such as the equipment breaking or falling over
occurred after the installation of the display because
the stand was not installed as instructed.
· The display must always be installed by two or more
people to assure it is installed safely.
· Before installation, turn off the power for the display
and peripheral devices then remove the power cord
plug from the power outlet.
This product rotates 10° to the left and right and inclines
approximately 2° forward and backward.
Do not place objects within the range of rotation of this
product and the Pioneer television. Install this product so
that during routine use or when it is rotated, it does not
protrude from the TV table or other location it has been
installed. Failure to do so could cause unforeseen accidents
such as the equipment breaking or falling over (see page 7).
While adjusting its angle forward and backward, be
extremely careful to keep your hands out of the space
between the bottom of the Pioneer television and the stand
(see page 6).
Prevent accidents caused by the product falling over, by
taking reliable measures to prevent it from falling over (see
page 9).
