Cover page of PIONEER PD-M406/WPWXJ/2 Service Manual

Service Manual for PIONEER PD-M406/WPWXJ/2, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 3 pages
  • File size: 0.03 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Wheelock Place, Singapore 238880
PIONEER ELECTRONIC CORPORATION 1998
RRV1974
MULTI COMPACT DISC PLAYER
PD-M406
T ­ ZZE JUNE 1998 Printed in Japan
÷ Refer to the service manual RRV1868 for PD-M426/WPWXJ/2.
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Type
Model
PD-M406
Power Requirement
Remarks
WPWXJ/2
AC220­240V
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Wheelock Place, Singapore 238880
PIONEER ELECTRONIC CORPORATION 1998
RRV1974
MULTI COMPACT DISC PLAYER
PD-M406
T ­ ZZE JUNE 1998 Printed in Japan
÷ Refer to the service manual RRV1868 for PD-M426/WPWXJ/2.
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Type
Model
PD-M406
Power Requirement
Remarks
WPWXJ/2
AC220­240V
background image
PD-M406
2
CONTRAST OF MISCELLANEOUS PARTS
7 CONTRAST TABLE
PD-M406/WPWXJ/2 and PD-M426/WPWXJ/2 are constructed the same except for the following:
PCB ASSEMBLIES
P7­20
MOTHER BOARD ASSY
PWM2156
PWM2153
1
NSP
SUB BOARD ASSY
PWX1337
PWX1335
P7­19
FUNCTION BOARD ASSY
PWZ2769
PWZ2768
1
PACKING
P5­ 1
Control Cable (for SR) (L=1m)
Not used
PDE1247
P5­ 3
Remote Control Unit (CU-PD068)
PWW1107
Not used
P5­ 4
Battery Cover
PZN1010
Not used
P5­ 9
CD Packing Case
PHG2243
PHG2326
P5­11
NSP
Dry Cell Battery (AAA/R03)
VEM-022
Not used
EXTERIOR
P7­ 2
32P F.F.C/30V
PDD1041
Not used
P7­ 2
30P F.F.C/30V
Not used
PDD1049
P7­ 9
Function Panel
PNW2726
PNW2730
P7­15
Display Window
PAM1635
PAM1730
P7­31
Rear Base
PNA2412
PNA2437
Ref.
No.
Remarks
PD-M426/WPWXJ/2 PD-M406/WPWXJ/2
Part No.
Mark
Symbol and Description
NOTES :
÷ Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
÷ The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
÷ Reference Nos. indicate the pages and Nos. in the service manual for the base model.
÷ When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex. 1
When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by
J = 5%, and K = 10%).
560
= 56 × 101= 561 ................................................... RD1/4PU 5 6 1 J
47k
= 47 × 10 3 = 473 .................................................. RD1/4PU 4 7 3 J
0.5
= R50 ...................................................................... RN2H Â 5 0 K
1
= 1R0 ......................................................................... RS1P 1 Â 0 K
Ex. 2
When there are 3 effective digits (such as in high precision metal film resistors).
5.62k
= 562 × 10 1 = 5621 ........................................... RN1/4PC 5 6 2 1 F
1 Refer to " CONTRAST OF PCB ASSEMBLIES " .
background image
PD-M406
3
CONTRAST OF PCB ASSEMBLIES
MOTHER BOARD ASSY
PWM2153 and PWM2156 are constructed the same except for the following:
Mark
Symbol and Description
Remarks
Part No.
D392­D394
Not used
1SS254
1
L391
Not used
LAU1R0
1
R391
Not used
RD1/4PU244J
1
R392
Not used
RD1/4PU102J
1
C393
Not used
CCCSL101J50
1
C399
Not used
CKCYF103Z50
2
JA391, JA392
SR JACK
Not used
RKN1004
1
CN351
FFC CONNECTOR
HLEM32S-1
HLEM30S-1
PWM2156
PWM2153
1 These Parts are used for PD-M426/KUXJ/2, KCXJ/2 and RDXJ/2. Refer to page 11 on the service manual RRV1868.
2 This Part is used for PD-M426/WPWXJ/2. Refer to page 11 on the service manual RRV1868.
FUNCTION BOARD ASSY
PWZ2768 and PWZ2769 are constructed the same except for the following:
Mark
Symbol and Description
Remarks
Part No.
CN701
FFC CONNECTOR
9607S-32F
9607S-30F
REMOTE SENSOR
SBX1785-51
Not used
PWZ2769
PWZ2768
