PIONEER PDP-4330HD Owner's Manual

Cover page of PIONEER PDP-4330HD Owner's Manual

Owner's Manual for PIONEER PDP-4330HD, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 71 pages
  • File size: 4.93 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
Operating Instructions
Mode d'emploi
Manual de instrucciones
PLASMA DISPLAY SYSTEM
SYSTEME D'ÉCRAN PLASMA
SISTEMA DE PANTALLA DE PLASMA
PDP-5030HD
PDP-4330HD
background image
Operating Instructions
Mode d'emploi
Manual de instrucciones
PLASMA DISPLAY SYSTEM
SYSTEME D'ÉCRAN PLASMA
SISTEMA DE PANTALLA DE PLASMA
PDP-5030HD
PDP-4330HD
background image
Note to CATV system installer.
This reminder is provided to call the CATV system installer's attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground­shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.
background image
WARNING: THE APPARATUS IS NOT WATERPROOFS, TO PREVENT FIRE OR SHOCK HAZARD, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE AND DO NOT PUT ANY WATER SOURCE NEAR THIS
APPARATUS, SUCH AS VASE, FLOWER POT, COSMETICS CONTAINER AND MEDICINE BOTTLE ETC.
NOTE: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
Information to User
Alteration or modifications carried out without appropriate authorization may invalidate the user's right to operate the
equipment.
[For Canadian model]
This Class B digital apparatus complies with Canadian ICES-003.
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect the unit to other
equipment. To prevent electromagnetic interference with electric appliances such as radios and televisions, use shielded
cables and connectors for connections.
FEDERAL COMMUNICATIONS COMMISSION
DECLARATION OF CONFORMITY
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Product Name: Plasma Display System
(Plasma Display)
(Media Receiver)
Model Number: PDP-5030HD
PDP-4330HD
(PDP-503PU)
(PDP-433PU)
(PDP-R03U)
(PDP-R03U)
Product Category: Class B Personal Computers & Peripherals
Responsible Party Name: PIONEER ELECTRONICS (USA), INC., Customer Support Div.
Address: P.O. BOX 1760, LONG BEACH, CA., 90801-1760 U.S.A.
Phone: (800) 421-1625
For Business Customer URL http://www.PioneerUSA.com
IMPORTANT NOTICE
: The serial number for this equipment is located on the rear panel. Please write this
serial number on your enclosed warranty card and keep it in a secure area. This is for your security.
background image
E-1
Dear customer
Thank you for your purchase of the PIONEER product. To ensure safety and many years of trouble-free operation
of your product, please read the IMPORTANT SAFETY INSTRUCTIONS carefully before using this product.
Contents
Dear customer
............................................. 1
Contents ...................................................... 1
Important User Guidance Information ............... 2
Features ...................................................... 3
Supplied accessories .................................... 4
Plasma Display .......................................... 4
Media Receiver .......................................... 4
Preparation ................................................... 5
Installing the Plasma Display ........................ 5
Setting the system
.................................... 6
How to route cables .................................... 7
Using the remote control unit ........................ 8
Cautions regarding remote control unit ...... 8
Inserting the batteries ........................... 8
Cautions regarding batteries .................. 8
Part names ................................................... 9
Plasma Display .......................................... 9
Media Receiver ....................................... 10
Remote control unit ................................. 11
Watching TV
............................................. 12
Basic connection .................................... 12
Turning on the power .............................. 14
Turning off the power .............................. 14
Initial auto installation .............................. 15
Simple button operations for changing
channels .......................................... 16
Simple button operations for changing
volume/sound .................................... 17
Using FRONT SURR(SURROUND) on the
remote control unit .............................. 18
Setting MTS/SAP stereo mode .................. 19
Basic adjustment settings ........................... 20
AV mode menu items .............................. 20
PC mode menu items .............................. 21
Moving the picture on the screen ............... 22
Auto installation ....................................... 23
Channel setup ....................................... 24
Language setting .................................... 26
Picture adjustments ................................. 27
Color temperature .............................. 28
Black
............................................. 28
3D-Y/C ............................................. 29
Black & White .................................... 29
PureCinema ....................................... 30
Sound adjustment .................................... 31
Power control .......................................... 32
Power control for AV source .................. 32
Power control for PC source .................. 33
Using external equipment ........................... 34
Watching a DVD image ........................... 35
Connecting a DVD player ..................... 35
Displaying a DVD image ..................... 35
Watching a VCR image
........................... 36
Connecting a VCR .............................. 36
Displaying a VCR image ..................... 36
Watching broadcasts via a Digital tuner ...... 37
Connecting a Digital tuner
.................. 37
Displaying broadcasts via a Digital tuner
37
Enjoying a game console or viewing camcorder
images ............................................. 38
Connecting a game console or
camcorder
................................. 38
Displaying an image of the game console
or camcorder images ..................... 38
Viewing an image from a computer ............ 39
Connecting a computer
..................... 39
Displaying an image from a computer ... 39
Control cord connection ........................... 40
Useful adjustment settings ........................... 41
Image position (AV mode only) .................. 41
Auto Sync. adjustment (PC mode only)
...... 42
Fine Sync. adjustment (PC mode only) ......... 42
Input signal source ................................. 43
AV SELECTION ....................................... 44
Wide Mode ............................................. 45
Audio out
............................................. 46
Sleep timer ............................................. 46
Closed caption ....................................... 47
Parental control (setting V-CHIP level) ......... 48
Secret number setting for parental control
(AV mode only) ................................. 52
How to temporarily release
the V-CHIP BLOCK
........................... 54
Reactivating the temporarily released
V-CHIP BLOCK ................................. 54
Useful features .......................................... 55
Multiscreen functions .............................. 55
Learning remote control function ............... 56
Using the TV remote control unit to
control other device ........................... 58
Appendix
................................................ 64
Troubleshooting ....................................... 64
Computer compatibility chart ..................... 65
Specifications
....................................... 66
background image
E-2
Important User Guidance Information
In order to obtain maximum enjoyment from this Pioneer PureVision PDP-5030HD/PDP-4330HD Plasma Display System, please first read
this information carefully.
With the Pioneer PureVision PDP-5030HD/PDP-4330HD, you can be assured of a high quality Plasma Display System with long-life and
high reliability. To achieve images of exceptional quality, this Pioneer Plasma Display System incorporates state-of-the-art design and
construction, as well as very precise and highly advanced technology. On a total of nearly 3 million light cells, more than 99.999 percent
of the cells remain active.
Over the course of its lifetime, the luminosity of the Pioneer PDP-5030HD/PDP-4330HD Plasma Display System will diminish very slowly,
such as with all phosphor-based screens (for example, a traditional tube-type television). To enjoy beautiful and bright images on your
Pioneer Plasma Display System for many years to come, please carefully read and follow the usage guidelines below.
Usage guidelines
All phosphor-based screens (including conventional tube-type televisions) can be affected by displaying static images for a prolonged
period. Plasma Display Systems are no exception to this rule. After-image and permanent effects on the screen can be avoided by taking
some basic precautions. By following the recommendations listed below, you can ensure longer and satisfactory results from your plasma:
· Whenever possible, avoid frequently displaying the same image or virtually still moving pictures (e.g. closed-captioned images or
video game images which have static portions).
· Avoid viewing the On Screen Display for extended periods, from a Digital tuner, DVD player, VCR and all other components.
· Do not leave the same picture freeze-framed or paused continuously over a long period of time, when using the still picture mode
from a TV, VCR, DVD player or any other component.
· Images which have both very bright areas and very dark areas side by side should not be displayed for a prolonged period of time.
· When playing a game, the "GAME" mode setting within "AV SELECTION" is strongly recommended. However, please limit its use to
less than 2 hours at a time.
· After playing a game, or displaying a PC image or any still image, it is best to view a normal moving picture in the "WIDE" or "FULL"
screen setting for over 3 times longer than the previous still/moving image.
· After using the Plasma Display System, always switch the display to "STAND BY" mode.
Installation guidelines
The Pioneer PureVision PDP-5030HD/PDP-4330HD Plasma Display System incorporates a very thin design. To ensure safety, please take
the proper measures to mount or install the Plasma Display, in order to prevent the unit from tipping over in the event of vibration or
accidental movement.
This product should be installed by using only parts and accessories designed by PIONEER. Use of accessories other than the PIONEER
stand or installation bracket may result in instability, and could cause injury. For custom installation, please consult the dealer where the
unit was purchased. To ensure correct installation, experienced and qualified experts must install the unit. PIONEER will not be held
responsible for accident or damage caused by the use of parts and accessories manufactured by other companies.
To avoid malfunction and overheating when installing, make sure that the vents on the main unit are not blocked. To ensure proper heat
emission:
· Distance the unit slightly from other equipment, walls, etc. more than 10 cm(3 15/16 inch)
· Do not fit the unit inside narrow spaces where ventilation is poor.
· Do not cover with a cloth, etc.
· Clean the vents on the sides and rear of the unit to remove dust build-up by using a vacuum cleaner set to its lowest
suction setting.
Using the unit without proper ventilation may cause the internal temperature to rise, and could result in possible malfunction. When the
surrounding or internal temperature exceeds a certain degree, the display will automatically power off in order to cool the internal electronics
and prevent a hazardous occurrence.
Malfunction can be caused by many factors: inappropriate installation site, improper assembly/installation/mounting, improper operation
of or modifications made to this product. However, PIONEER cannot be held responsible for accidents or malfunction caused by the
above.
A
Typical effects and characteristics of a phosphor-based matrix display such as permanent residual images upon the phosphors of the
panel and the existence of a minute number of inactive light cells in the screen are not covered by local warranties.
About the Plasma Panel's protection function
The brightness of this display will deteriorate slightly when an image with little movement such as a photograph or computer image is
continuously displayed. This is caused by the Plasma Panel's protection function which detects images with slight movement and
automatically adjusts brightness to protect the display, and is not a malfunction.
This function begins operating when the display detects no or little screen movement for a period of about three minutes.
L
Panel sticking and after-image lag
· Displaying the same images such as still images for a long time may cause after-image lagging. This may occur in the following two
cases.
1. After-image lagging due to remaining electrical load
When image patterns with very high peak luminance are displayed for more than 1 minute, after-image lagging may occur due to the
remaining electric load. The after-images remaining on the screen will disappear when moving images are displayed. The time for the
after-images to disappear depends on the luminance of the still images and the time they had been displayed.
2. After-image (lag image) due to burning
Avoid displaying the same image on the Plasma Display continuously over a long period of time. If the same image is displayed
continuously for several hours, or for shorter periods of time over several days, a permanent after-image may remain on the screen due
to burning of the fluorescent materials. Such images may become less noticeable if moving images are later displayed, but they will not
disappear completely.
· The Energy save function can be set to help prevent damage from screen burning (See page 32-33).

Reviews

There are no reviews of this manual yet.

Related Products

Cover page of PIONEER DVH-P6050UB/XN/CN5 Owner's Manual

This manual has 80 pages, file size: 2.25 MB. It's available in languages: Chinese Simplified.

Cover page of PIONEER KEH-P4010R/X1P/EW Service Manual

This manual has 46 pages, file size: 1.99 MB. It's available in languages: English.

Cover page of PIONEER SD-P4565-Q Owner's Manual

This manual has 266 pages, file size: 69.91 MB. It's available in languages: English.

Cover page of PIONEER DEH-P43X1N Service Manual

This manual has 68 pages, file size: 3.37 MB. It's available in languages: English.

Cover page of PIONEER VSX-LX60/HYXJ5 Service Manual

This manual has 268 pages, file size: 27.14 MB. It's available in languages: English.
