PDP-R03G
1. CONTRAST OF MISCELLANEOUS PARTS
jp
f
y
For the applying amount of lubricants or glue, follow the instructions in this manual.
(In the case of no amount instructions, apply as you think it appropriate.)
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Screws adjacent to
mark on product are used for disassembly.
Reference Nos. indicate the pages and Nos. in the service manual for the base model.
NOTES:
·When ordering resistors, first convert resistance values into code form as shown in the following examples.
Ex.1 When there are 2 effective digits (any digit apart from 0), such as 560 ohm and 47k ohm (tolerance is shown by J=5%,
and K=10%).
560
56
× 101
561 ........................................................ RD1/4PU 5 6 1 J
47k
47
× 103
473 ........................................................ RD1/4PU 4 7 3 J
0.5
R50 ..................................................................................... RN2H R 5 0 K
1
1R0 ..................................................................................... RS1P 1 R 0 K
Ex.2 When there are 3 effective digits (such as in high precision metal film resistors).
5.62k
562
× 101
5621 ...................................................... RN1/4PC 5 6 2 1 F
CONTRAST TABLE
PDP-R03G/TLDPBR/1 and TLDPBR are constructed the same except for the following :
Part No.
Ref. No. Mark
Symbol and Description
PDP-R03G
PDP-R03G
Remarks
/TLDPBR
/TLDPBR/1
PCB ASSEMBLIES
P9-46
PC I/F UNIT
CPCI-0056CE16
CPCI-A005WJ36
PACKING SECTION
Case Label
Not used
TLABZA184WJZZ
NR Caution
Not used
TCAUHA056WJZZ
NSP
Marking Seal (SMALL)
Not used
TLABZ0793CESE
NSP
Marking Seal (LARGE)
Not used
TLABZA001WJSE
EXTERIOR SECTION
P9-22
No. Label
TLABN0416CEZZ
TLABNA250WJZZ
Notes : For PCB ASSEMBLIES, Refer to "PCB PARTS LIST", "2. SCHEMATIC DIAGRAM" and "3. PCB CONNECTION DIAGRAM".
