PIONEER PDU-50WX2 Service Manual

Cover page of PIONEER PDU-50WX2 Service Manual

Service Manual for PIONEER PDU-50WX2, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 95 pages
  • File size: 2.72 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7Thumbnail of page 8
Thumbnail of page 9
background image
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
c
ORDER NO.
PDU-50WX2
ARP3114
T ­ ZZK JAN. 2002 Printed in Japan
PLASMA DISPLAY
1. SAFETY INFORMATION ....................................... 3
2. EXPLODED VIEWS AND PARTS LIST ................. 6
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ... 24
(For SCHEMATIC DIAGRAM, refer to ARP3115)
4. PCB CONNECTION DIAGRAM ... Refer to ARP3115
5. PCB PARTS LIST ................................................ 36
6. ADJUSTMENT ..................................................... 45
CONTENTS
7. GENERAL INFORMATION ................................ 68
7.1 DIAGNOSIS .................................................. 68
7.1.1 PCB LOCATION ................................... 68
7.1.2 SHUT DOWN/POWER DOWN
DIAGNOSIS BY LED DISPLAY ........... 69
7.1.3 DISASSEMBLY ..................................... 75
7.2 IC INFORMATION ........................................ 77
Model No.
Order No.
Remarks
PDU-50WX2
ARP3115
SCHEMATIC DIAGRAM and PCB DIAGRAM
¶ This service manual should be used together with the following manual(s).
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Type
Model
Power Requirement
Remarks
PDU-50WX2
TUCYV
AC100 - 240V
For details, refer to "Important symbols for good services" on the next page.
background image
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2002
c
ORDER NO.
PDU-50WX2
ARP3114
T ­ ZZK JAN. 2002 Printed in Japan
PLASMA DISPLAY
1. SAFETY INFORMATION ....................................... 3
2. EXPLODED VIEWS AND PARTS LIST ................. 6
3. BLOCK DIAGRAM AND SCHEMATIC DIAGRAM ... 24
(For SCHEMATIC DIAGRAM, refer to ARP3115)
4. PCB CONNECTION DIAGRAM ... Refer to ARP3115
5. PCB PARTS LIST ................................................ 36
6. ADJUSTMENT ..................................................... 45
CONTENTS
7. GENERAL INFORMATION ................................ 68
7.1 DIAGNOSIS .................................................. 68
7.1.1 PCB LOCATION ................................... 68
7.1.2 SHUT DOWN/POWER DOWN
DIAGNOSIS BY LED DISPLAY ........... 69
7.1.3 DISASSEMBLY ..................................... 75
7.2 IC INFORMATION ........................................ 77
Model No.
Order No.
Remarks
PDU-50WX2
ARP3115
SCHEMATIC DIAGRAM and PCB DIAGRAM
¶ This service manual should be used together with the following manual(s).
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Type
Model
Power Requirement
Remarks
PDU-50WX2
TUCYV
AC100 - 240V
For details, refer to "Important symbols for good services" on the next page.
background image
2
PDU-50WX2
[ Important symbols for good services ]
In this manual, the symbols shown-below indicate that adjustments, settings or cleaning should be made securely.
When you find the procedures bearing any of the symbols, be sure to fulfill them:
2. Adjustments
To keep the original performances of the product, optimum adjustments or specification confirmation is indispensable.
In accordance with the procedures or instructions described in this manual, adjustments should be performed.
3. Cleaning
For optical pickups, tape-deck heads, lenses and mirrors used in projection monitors, and other parts requiring cleaning,
proper cleaning should be performed to restore their performances.
5. Lubricants, glues, and replacement parts
Appropriately applying grease or glue can maintain the product performances. But improper lubrication or applying
glue may lead to failures or troubles in the product. By following the instructions in this manual, be sure to apply the
prescribed grease or glue to proper portions by the appropriate amount.For replacement parts or tools, the prescribed
ones should be used.
4. Shipping mode and shipping screws
To protect the product from damages or failures that may be caused during transit, the shipping mode should be set or
the shipping screws should be installed before shipping out in accordance with this manual, if necessary.
1. Product safety
You should conform to the regulations governing the product (safety, radio and noise, and other regulations), and
should keep the safety during servicing by following the safety instructions described in this manual.
background image
3
PDU-50WX2
1. SAFETY INFORMATION
This service manual is intended for qualified service technicians ; it is not meant for the casual do-it-
yourselfer. Qualified technicians have the necessary test equipment and tools, and have been trained
to properly and safely repair complex products such as those covered by this manual.
Improperly performed repairs can adversely affect the safety and reliability of the product and may
void the warranty. If you are not qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service technician.
WARNING
This product contains lead in solder and certain electrical parts contain chemicals which are known to the state of California to cause
cancer, birth defects or other reproductive harm.
Health & Safety Code Section 25249.6 ­ Proposition 65
NOTICE
(FOR CANADIAN MODEL ONLY)
Fuse symbols
(fast operating fuse) and/or
(slow operating fuse) on PCB indicate that replacement parts must
be of identical designation.
REMARQUE
(POUR MODÈLE CANADIEN SEULEMENT)
Les symboles de fusible
(fusible de type rapide) et/ou
(fusible de type lent) sur CCI indiquent que les pièces
de remplacement doivent avoir la même désignation.
1.1 SAFETY PRECAUTIONS
NOTICE :Comply with all cautions and safety related notes located
on or inside the cabinet and on the chassis.
The following precautions should be observed :
1. When service is required, even though the PDP UNIT an isolation
transformer should be inserted between the power line and the
set in safety before any service is performed.
2. When replacing a chassis in the set, all the protective devices
must be put back in place, such as barriers, nonmetallic knobs,
adjustment and compartment covershields, isolation resistor-
capacitor, etc.
3. When service is required, observe the original lead dress. Extra
precaution should be taken to assure correct lead dress in the
high voltage circuitry area.
4. Always use the manufacture's replacement components.
Especially critical components as indicated on the circuit diagram
should not be replaced by other manufacture's.
Furthermore where a short circuit has occurred, replace those
components that indicate evidence of overheating.
5. Before returning a serviced set to the customer, the service
technician must thoroughly test the unit to be certain that it is
completely safe to operate without danger of electrical shock,
and be sure that no protective device built into the set by the
manufacture has become defective, or inadvertently defeated
during servicing. Therefore, the following checks should be
performed for the continued protection of the customer and
service technician.
6. Perform the following precautions against unwanted radiation
and rise in internal temperature when it was built in by a product.
· Always return the internal wiring to the original styling.
· Attach parts (Front Protect Panel etc.) surely after disassembly.
7. Perform the following precautions for the PDP panel.
· When the Front Protect Panel is removed, make sure nothing
hits the panel face, panel corner, and panel edge (so that the
glass does not break).
· Make sure that the panel vent does not break. (Check that the
cover is attached.)
· Handle the FPC connected to the panel carefully.
Twisting or pulling the FPC when connecting it to the connector
will cause it to peel off from the panel.
8. Pay attention to the following.
· When the Front Protect Panel is removed, infrared ray is
radiated and may disturb reception of the remote control unit.
· Pay extreme caution when the Front Protect Panel are removed
because this may cause a high risk of disturbance to TVs and
radios in the surrounding.
background image
4
PDU-50WX2
Leakage Current Cold Check
With the AC plug removed from an AC power source, place a
jumper across the two plug prongs. Turn the AC power switch on.
Using an insulation tester (DC 500V), connect one lead to the
jumpered AC plug and touch the other lead to each exposed metal
part (input/output terminals, screwheads, metal overlays, control
shafts, etc.), particularly any exposed metal part having a return
path to the chassis. Exposed metal parts having a return path to the
chassis should have a minimum resistor reading of 0.3M
and a
maximum resistor reading of 5M
. Any resistor value below or
above this range indicates an abnormality which requires corrective
action. Exposed metal parts not having a return path to the chassis
will indicate an open circuit.
Leakage Current Hot Check
Plug the AC line cord directly into an AC power source (do not use
an isolation transformer for this check).
Turn the AC power switch on.
Using a "Leakage Current Tester (Simpson Model 229 equivalent)",
measure for current from all exposed metal parts of the cabinet
(input/output terminals, screwheads, metal overlays, control shaft,
etc.), particularly any exposed metal part having a return path to the
chassis, to a known earth ground (water pipe, conduit, etc.). Any
current measured must not exceed 0.5mA.
ANY MEASUREMENTS NOT WITHIN THE LIMITS
OUTLINED ABOVE ARE INDICATIVE OF A POTENTIAL
SHOCK HAZARD AND MUST BE CORRECTED BEFORE
RETURNING THE SET TO THE CUSTOMER.
1.2 PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in PIONEER set have special
safety related characteristics. These are often not evident from
visual inspection nor the protection afforded by them necessarily
can be obtained by using replacement components rated for higher
voltage, wattage, etc. Replacement parts which have these special
safety characteristics are identified in this Service Manual.
Electrical components having such features are identified by marking
with a
on the schematics and on the parts list in this Service
Manual.
The use of a substitute replacement component which dose not have
the same safety characteristics as the PIONEER recommended
replacement one, shown in the parts list in this Service Manual, may
create shock, fire or other hazards.
Product Safety is continuously under review and new instructions
are issued from time to time. For the latest information, always
consult the current PIONEER Service Manual. A subscription to, or
additional copies of, PIONEER Service Manual may be obtained at
a nominal charge from PIONEER.
Also test with plug
reversed
(Using AC adapter
plug as required)
Device
under
test
Test all exposed
metal surfaces
Earth ground
Leakage
current
tester
Reading should
not be above
0.5 mA
AC Leakage Test
background image
5
PDU-50WX2
7 Charged Section
The places where the commercial AC power is used without
passing through the power supply transformer.
If the places are touched, there is a risk of electric shock. In addition,
the measuring equipment can be damaged if it is connected to the
GND of the charged section and the GND of the non-charged
section while connecting the set directly to the commercial AC
power supply. Therefore, be sure to connect the set via an insulated
transformer and supply the current.
1. Fuse (In the SW POWER SUPPLY Module)
2. STB Transformer and Converter Transformer
(In the SW POWER SUPPLY Module)
3. Other primary side of the SW POWER SUPPLY Module
1.3 CHARGED SECTION AND HIGH VOLTAGE GENERATING POINT
7 High Voltage Generating Point
The places where voltage is 100V or more except for the charged
places described above. If the places are touched, there is a risk of
electric shock.
1. SW POWER SUPPLY Module ...................................... (225V)
2. X DRIVE Assy .............................................. (­300V to 225V)
3. Y DRIVE Assy ............................................................... (355V)
4. SCAN (A) Assy .............................................................. (355V)
5. SCAN (B) Assy ............................................................... (355V)
6. X CONNECTOR (A) Assy ........................... (­300V to 225V)
7. X CONNECTOR (B) Assy ............................ (­300V to 225V)
X DRIVE
Assy
X CONNECTOR (B)
Assy
Y DRIVE
Assy
SCAN (A)
Assy
SCAN (B)
Assy
X CONNECTOR (A)
Assy
SW POWER SUPPLY
Module
Top
Front
Fig.1 Charged Section and High Voltage Generating Point (Rear View)
: Part is the High Voltage Generating Points
other than the Charged Section.
: Part is Charged Section.

Reviews

There are no reviews of this manual yet.
