Operating Instructions

HDTV PROJECTION MONITOR

PRO-720HD

PRO-620HD

PRO-520HD

Operating Instructions

HDTV PROJECTION MONITOR

PRO-720HD

PRO-620HD

PRO-520HD

Progressive Scan/HDTV READY

All SDTV and HDTV signals are converted to 1080i signals and

displayed at high resolution.

Dual System Component Input for NTSC/

Progressive

Connection to a DVD player with a component output terminal

makes possible high picture-quality display, superior to that

of S-VIDEO terminal connection. Also handles high resolution

component input (1080i, 480p), which will function as an

interface for high-quality images in future.

DUAL TUNER (SPLIT screen and SEARCH

screen function)

Two TV tuners are provided, making it possible to split the

screen vertically in two and display moving images

simultaneously on them. In addition, the channel search

function makes it possible to check, etc., on the program in the

back. This adds remarkable convenience when you are

concerned with two programs.

Fully Illuminated Remote Control Unit

A fully illuminated universal remote control is used that makes

it possible to operate other devices. Remote operations can

thus be performed easily even in dark rooms and similar

environments.

Highly Detailed Image Display Technology

The 0.52mm ultrafine-pitch screen, Hi Band Video Amplifier

circuit, Progressive contour correction circuit and various other

technologies for creating high picture quality make the display

of highly detailed images possible.

Lens System for HDTV

Adoption of a lens system for high-resolution HDTV that

faithfully reproduces HDTV 1080i signals allows highly color-

saturated images to be displayed at high resolution.

Whole Screen IR Receiver

The remote control sensor is installed behind the screen,

allowing you to operate this monitor with the remote control

unit in those installations where only the screen is revealed.

3D Y/C Separation Circuit

This three-dimensional Y/C separation circuit reproduces

clearer picture quality.

Scan Velocity Modulation Circuit

Precise images from progressive scanning can be displayed

in even greater detail, owing to the Scan Velocity Modulation

(SVM) circuit. In accordance with image type and preference,

the level of effect can be changed in terms of three stages.

Tinted Protective Screen

The accompanying protective screen is tinted, not only to

protect the screen but to present more natural high-contrast

images by renewing the color.

Pioneer's PureCinema Format Converter

An advanced and exclusive I/P (Interlace/Progressive) format

converter developed by Pioneer, called "PureCinema", delivers

a high-resolution progressive picture. It reproduces film

material in a very smooth and film-like image. This is perfect

technology for movie lovers.

Reference Theater Mode

This mode reproduces film material just like a real film image.

By cutting video enhancement circuits, the picture becomes

more natural and looks filmlike.

Room Light Sensor (RLS)

When you select RLS on (LEVEL 1, LEVEL 2), in accordance

with the ambient light of your room, TV automatically adjusts

the picture brightness to reduce eye strain.

Multi-Point Convergence System

Thanks to new convergence system digital technology, not

only can the center of the screen be adjusted, so can an amazing

72 other points (full mode) across the viewing area. This makes

it possible to display clear images with no color distortion

around the entire screen.

The adjustment is easily done using the remote control.

Program Block (V. CHIP)

You can block selected programs based on the established

rating system for television and movies.

<U.S.A. RATING SYSTEM>

The TV Parental Guidelines are used to rate television

programming: <TV-Y>, <TV-Y7>, <TV-G>, <TV-PG>, <TV-14>

and <TV-MA>.

The Motion Picture Association of America (MPAA) guidelines

are used to rate movies: <G>, <PG>, <PG-13>, <R>, <NC-17>,

<X> and <NR>.

The Canadian English Language Rating system is used to rote

television programming: <C>, <C8+>, <G>, <PG>, <14+> and

<18+>.

The Canadian French Language Rating system is used to rate

television programming: <G>, <8+>, <13+>, <16+> and <18+>.

In order to block programming you feel is inappropriate, rating

limits can be set on both systems using the remote control

and a password.

Read and understand these 'Operating

Instructions' before operating your Monitor.

the

'IMPORTANT

SAFETY

INSTRUCTIONS AND WARNINGS' section and

all the warnings on the product.

FEATURES

INTRODUCTION

Thank you for purchasing this PIONEER HDTV Projection

Monitor.

Please read the precautionary instructions enclosed with these

operating instructions please do so before proceeding.

After learning how to operate the Projection Monitor, be sure

to keep this manual handy for future reference.

[For U.S. model]

IMPORTANT NOTICE

H006AEn

The serial number for this equipment is located in the Rear

panel. Please write this serial number on your enclosed

warranty card and keep it in a secure area. This is for your

security.

In this manual, we refer to the 'HDTV PROJECTION MONITOR',

as the 'Projection Monitor' or the 'Monitor'.

Note on the SPLIT screen and SEARCH screen functions

The SPLIT screen and SEARCH screen functions provided in

this monitor are intended for private viewing only.

Use of the above video processing functions for profitmaking

purpose or for public viewing (clubs, hotels, etc.) without prior

authorization from the transmitter and/or owner of the video

program (s) may be an infringement of existing copyright laws.

NOTICE ON ADVERSE EFFECTS ON THE TV TUBE

When playing TV games, operating computers or displaying still pictures with your Monitor, be

sure to keep in mind the following points;

1. Select the 'GAME' mode. (Refer to page 51 of the Operating Instructions)

2. Do not use your Monitor for more than two hours.

3. Watch normal TV broadcast's for three times longer than the time of playing TV games, operating

computers or displaying still pictures.

Still patterns can scar the Monitor causing performance damage to the CRT.

WARNING

IMPORTANT SAFETY INSTRUCTIONS AND WARNINGS

· Read all of these instructions.

· Keep these instructions for later use.

· Follow all warnings and instructions marked on the Monitor.

This Monitor is equipped with a

polarized alternating current line

plug (a plug having one blade

wider than the other).

This plug will fit into the power

outlet only one way. This is a

safety feature.

If you are unable to insert the plug

fully into the outlet, try reversing

the plug. If the plug should still fail

to fit, contact your electrician to

replace your obsolete outlet. Do

not defeat the safety purpose of

the polarized plug.

If the power cord or plug becomes

damaged or frayed, unplug this

Monitor from the wall outlet and

refer

qualified

service

personnel for servicing.

Do not overload wall outlets and

extension cords as this can result

in fire or electrical shock.

Do not allow anything to rest on

or roll over the power cord, and

do not place the Monitor where

the power cord maybe subject to

traffic or abuse. This may result

in electrical or fire hazard.

Do not attempt to service this

Monitor yourself as opening or

removing covers may expose you

to dangerous voltage or other

hazards. Refer all servicing to

qualified personnel.

Never push the objects of any kind

into this Monitor through cabinet

slots

they

may

touch

dangerous voltage points or short

out parts that could result in a fire

or electric shock. Never spill liquid

of any kind on the Monitor.

If the Monitor has been dropped

or the cabinet has been damaged,

unplug this Monitor from the wall

outlet and refer to qualified service

personnel for servicing.

If liquid has been spilled into the

Monitor, unplug the Monitor from

the wall outlet and refer servicing

to qualified service personnel.

The following symbols are found in this

manual and on the labels on the product.

They alert the operators and service

personnel of this equipment to potentially

dangerous conditions.

WARNING

This symbol refers to a hazard or unsafe

practice which can result in severe personal

injury or death.

CAUTION

This symbol refers to a hazard or unsafe

practice which can result in personal injury

or property damage.

This symbol indicates an action that is

prohibited.

FOR YOUR PERSONAL SAFETY

INTRODUCTION

Do not subject your Monitor to

impact of any kind. Be particularly

careful not to damage the screen

surface.

10.

Unplug the Monitor from the wall

outlet before cleaning. Do not use

liquid cleaners or spray-type

cleaners. Use a damp cloth for

cleaning.

11-1. Do not place this Monitor on an

unstable, uneven or an inclined

location. The Monitor may

overturn, causing serious injury

(to a person), and serious damage

to the appliance.

11-2. Be careful when placing the

Monitor on a cart to move it.

Quick stops, excessive force, and

uneven surfaces may cause the

Monitor and cart to overturn.

12.

· Do not use the Monitor near

water, for example, near a

bathtub, washbowl, kitchen sink,

or laundry tub, in a wet basement,

or near a swimming pool, etc.

· Never expose the Monitor to rain

water.

If the Monitor system has been

exposed to rain or water, unplug

the Monitor from the wall outlet

and refer servicing to qualified

service personnel.

13.

Choose a place where light (artificial

or sunlight) does not shine directly

on the screen.

14.

Avoid dusty places since the

buildup of dust inside the Monitor's

chassis

may

result

the

malfunctioning,

when

high

humidity persists.

15.

· The Monitor has slots, or

openings in the cabinet for

ventilation purposes to ensure the

reliable operation of the Monitor,

and to protect it from overheating.

These openings must not be

blocked or covered.

· Nevercovertheslotsoropenings

with cloth or other material.

· Never block the bottom

ventilation slots of the Monitor by

placing it on a bed, sofa, rug, etc.

· Never place the Monitor near or

over a radiator or heat register.

· NeverplacetheMonitorinabuilt-

in enclosure such as a bookcase,

unless proper ventilation is

provided.

PROTECTION AND LOCATION OF YOUR HDTV PROJECTION MONITOR

16.

If an outside antenna is connected through other

equipment, be sure the antenna system is grounded so

as to provide protection against voltage surges and built-

up static charges. In the U. S. A., section 810 of the

National Electrical Code, ANSI/NFPA 70, provides

information on proper grounding of the mast and

supporting structure, grounding of the lead-in wire to

an antenna-discharge unit, size of grounding

conductors, location of antenna-discharge unit,

connection to grounding electrode, and requirements

for the grounding electrode.

EXAMPLE OF ANTENNA GROUNDING IN

NATIONAL ELECTRICAL CODE INSTRUCTIONS

ANTENNA

LEAD IN WIRE

ANTENNA

DISCHARGE UNIT

(NEC SECTION 810-20)

GROUNDING CONDUCTORS

(NEC SECTION 810-21)

GROUNDING CLAMPS

POWER SERVICE GROUNDING

ELECTRODE SYSTEM

(NEC ART 250, PART H)

GROUND

CLAMP

ELECTRIC

SERVICE

EQUIPMENT

FIG. A

NEC-NATIONAL

ELECTRICAL CODE

Reviews

There are no reviews of this manual yet.

Related Products

PIONEER RRV2588 Service Manual

This manual has 4 pages, file size: 0.1 MB. It's available in languages: English.

PIONEER DEH-2050MP/XS/ES Service Manual

This manual has 60 pages, file size: 7.33 MB. It's available in languages: English.

PIONEER VSX-D2S Service Manual

This manual has 104 pages, file size: 117.83 MB. It's available in languages: English.

PIONEER VSX-LX60/HYXJ5 Service Manual

This manual has 268 pages, file size: 27.14 MB. It's available in languages: English.

PIONEER PDR-W37 Owner's Manual

This manual has 52 pages, file size: 1.69 MB. It's available in languages: English.
