Cover page of PIONEER S-A35/XJI/E Service Manual

Service Manual for PIONEER S-A35/XJI/E, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 2 pages
  • File size: 0.02 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Wheelock Place, Singapore 238880
PIONEER ELECTRONIC CORPORATION 1998
RRV2016
T-ZZW SEPT. 1998 Printed in Japan
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is united with the baffle, therefore cannot be sepa-
rated.
The baffle is attached to the cabinet by 4 external screws.
The speaker is attached to the baffle by 4 internal screws.
To detach it, first remove the baffle. Then remove the speaker.
When attaching it, face its terminal rightward.
SPEAKER SYSTEM
S-A35
XJI/E
S-A35 XJI/NC
background image
ORDER NO.
PIONEER ELECTRONIC CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00 Wheelock Place, Singapore 238880
PIONEER ELECTRONIC CORPORATION 1998
RRV2016
T-ZZW SEPT. 1998 Printed in Japan
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is united with the baffle, therefore cannot be sepa-
rated.
The baffle is attached to the cabinet by 4 external screws.
The speaker is attached to the baffle by 4 internal screws.
To detach it, first remove the baffle. Then remove the speaker.
When attaching it, face its terminal rightward.
SPEAKER SYSTEM
S-A35
XJI/E
S-A35 XJI/NC
background image
2
NSP
CS ASSY (Surround)
SMW1556
Screw (for Baffle)
BYC40P130FZK
Speaker
D87CC45-53K
Connecting Cord
SDF1068
NSP
Cover
SES1018
Grille ASSY
SMG1621
NSP
Badge 38
SAM1442
NSP
Grille Cloth
SAS1440
NSP
Baffle Board
SNK2321
NSP
Cabinet
SNK2322
Screw (for Speaker)
TTZ40P080FMC
( XJI/E Type )
NSP
Stamped Model Label (Surround)
SME2803
NSP
Model Label (Surround)
SAN2595
( XJI/NC Type )
NSP
Stamped Model Label (Surround)
SME2855
NSP
Model Label (Surround)
SAN2651
Mark No.
Description
Part No.
SCHEMATIC DIAGRAM
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
NOTES:
PARTS LIST
Mark No.
Description
Part No.
S-A35
Operating Instructions
SRD1199
(English/ Russian/ Spanish/ Portuguese/ French/
Arabian/ Traditional Chinese/ Simplified Chinese)
Bottom Protector
SHA2124
Top Protector
SHA2125
Protection Mat
SHC1429
Packing Case (XJI/E Type)
SHG2116
Packing Case (XJI/NC Type)
SHG2154
Master Carton (XJI/E Type)
SHP1070
Master Carton (XJI/NC Type)
SHP1072
NSP
Polyethylene Bag S1
SHL1109
For Packing
Connecting Cord (SDF1068)
Speaker
INPUT
Gray/Black
Gray
