Thank you for buying this Pioneer product. Please read

through these operating instructions so you will know how to

operate your model properly. After you have finished reading

the instructions, put them away in a safe place for future

reference.

Before you start

· The nominal impedance of this speaker system is 6 .

Connect the speaker system to an amplifier with a load

impedance ranging from 4 to 16 (a model with "4

16 " displayed on the speaker output terminals).

· Do not touch the speaker cones as they are easily

damaged.

In order to prevent damage to the speaker system resulting

from input overload, please observe the following

precautions:

· Do not supply power to the speaker system in excess of

the maximum permissible input.

· When connecting or disconnecting anything in your AV

system, make sure the amplifier is switched off.

· When using a graphic equalizer to emphasize loud

sounds in the high-frequency range, do not use

excessive amplifier volume.

· Do not try to force a low-powered amplifier to produce

loud volumes of sound (the amplifier's harmonic

distortion will be increased, and you may damage the

speaker).

Caution: installation

· Do not place the speaker on an unstable surface. It

could present a hazard if it falls, as well as damaging the

equipment.

· Switch off and unplug your AV equipment and consult

the instructions when connecting up components. Make

sure you use the correct connecting cables.

· Do not put a TV or other AV equipment on top of this

speaker. It could present a hazard if it falls, as well as

damaging the equipment.

Caution: in use

· Do not use the speaker to output distorted sound for

long periods of times. This can result in a fire hazard.

· Do not sit or stand on the speaker, or let children play on

the speaker.

· Do not put large or heavy objects on top of the speaker.

· Do not install your speakers overhead on the ceiling or

wall. If improperly attached, the speaker grille can fall

and cause damage or personal injury.

· Do not attach these speakers to the wall or ceiling. They

may fall off and cause injury.

WARNING: Handling the cord on this product or

cords associated with accessories sold with the

product will expose you to chemicals listed on

proposition 65 known to the State of California and

other governmental entities to cause cancer and

birth defect or other reproductive harm.

D36-P4_A_En

Wash hands after handling

Features of the "Pure Malt" speaker

cabinet

The cabinet for this speaker system is white oak recycled

from barrels used for aging malt whiskey. These whiskey

barrels were made from oak trees over one-hundred years old

and have been used for over fifty years for aging whiskey. By

adopting this dense, hard wood for our speaker cabinets,

unwanted reverberations are suppressed, and the barrel

material's natural musical characteristics allow the wood to

display its richly expressive sound.

Unique characteristics of this barrel material may include

nail marks and whiskey stains in the wood, with the result

that each product possesses unique individuality. We hope

you enjoy the pleasure of owning these speakers with their

singular appearance.

Since the oak material used in these speakers is a natural

material, they respond sensitively to temperature and

humidity changes in the environments where they are used.

Using them in conditions of excessive or insufficient

humidity may not only cause adverse influence on sound, but

also cause deformation or discoloration of the cabinet due to

shrinkage. For optimum results and a lifetime of usage,

please following the precautions noted below.

Usage precautions

· Conditions considered unpleasant by humans are

detrimental to speakers as well. Providing a comfortable

environment for the speakers will assist them in

demonstrating their best performance. Please maintain

the usage environment as follows:

Temperature: 15 °C to 25 °C

Relative Humidity: 35 % to 65 % (winter)

40 % to 70 % (summer)

· In areas of high humidity, use a dehumidifier, and in

areas of excessive dryness, use a humidifier to adjust

the room's humidity level.

· Avoid exposure to direct sunlight, and do not install in

areas nearby heating appliances.

· When using room air-conditioners or stoves to rapidly

cool or heat room spaces, take precautions to avoid

excessive dehumidification.

· Avoid locations near windows or in other locations

where speakers may be exposed to the influence of

outdoor air, since condensation may result.

Installation

Speaker systems are delicately influenced by the conditions

of the listening room where they are used. As a result, you

should take care to provid optimum conditions for your

listening environment.

This speaker system is a so-called "bookshelf" type. This

means that, for example, if the speaker system is placed

directly on the floor, bass sounds will be reverberated from

the floor surface, overemphasizing the low-range sounds and

impairing the overall sound quality. To prevent this, the use of

speaker stands is recommended to separate the speakers

from the floor. In general, good results will be produced if you

install the speakers so that the high-range speakers

(tweeters) are at about the same level as the listener's ears.

English

Note: Pioneer refuses any responsibility for damage

or accidents resulting from improper installation.

· Each speaker weighs 3.7 kg. Select a location for

installation with stable surface, providing sufficient

distance between the speaker system and nearby walls

as shown in the accompanying illustration.

The emphasis produced by the bass speakers (woofers)

can be adjusted to some degree by varying the distance

between the speaker system and the wall behind it.

Adjust the distance between speakers and side walls to

eliminate any subject difference between right and left

speakers.

· The most natural stereo experience will be produced

when right and left speakers are equidistant from the

listening position. Speaker cables should also be the

same lengths for right and left speakers.

· When placed beside a television set, right and left

speakers should be installed so far as possible in the

same plane as the television screen.

· In order to produce optimum breadth of sound when

used in conjunction with a television, install the

television in the center between the two speakers, and

set the speakers at distances from the television such

that the angle between the speakers and listener is

about 50° to 60°.

· In rooms with hard surfaced floors and walls, sound

may be reflected off the floor and walls, creating echoes

or harmonics. In such cases, it is recommended to

adjust the sound characteristics through the use of wall

hangings, curtains, or drapes, or by placing a carpet on

the floor. Placing curtains all the way to the corners of a

room may help prevent speakers from producing

muffled sound. Likewise, if the wall opposite the

speakers (behind the listening position) is a hard wall,

placing a thick curtain on the wall may produce good

results by helping prevent the generation of standing

waves.

Applying non skid pads

The use of non skid pads is recommended depending on the

installation location. Apply the pads to the four corners of the

side of the speaker which will be on the bottom. Note that

depending on the location, the pads may not provide fully

sufficient traction to prevent slipping, so care should be

taken not to install the speakers in conditions where they

may be prone to slide.

Installing and removing the grille net

The front panel grille net may be removed if desired. The

following instructions are provided for removal and

replacement of the grille net:

Holding the lower edge of the grill net with both

hands, pull gently forward, away from the speaker.

The lower side of the grille net will detach from the speaker

body.

Pull the top side of the grille net away from the

speaker.

The grille net will detach from the speaker body.

3To replace the grille net on the speaker, align the

holes on the corners of the grille net with the pegs on

the four corners of the speaker and press in slowly.

Connecting to an amplifier

This speaker system features banana-plug connections.

1Turn off the power at the amplifier.

Connect each supplied speaker cable to one set of

the amplifier's speaker output terminals and the speaker

system's input terminals.

The red terminal is the positive

, and the black terminal is

negative

. Connect the wire with the white line to the

terminal, and the wire without the white line to the

terminal.

1 Trim a small bit of insulation from the tip of the cable,

exposing the wire cores; twist the cores before inserting into

the terminal.

Non skid pads

50 cm

20 cm

50° to 60°

2 Loosen the terminal screw cover, insert the wire core into

the hole and retighten the cover.

·After connecting the terminals, lightly tug on the end of

the cable to confirm that the connections are tight.

Loose connections may result in distorted or interrupted

sound.

· Do not allow wire cores to protrude from the terminals

and touch each other. Allowing the positive

and

negative

wires to touch may result in overloading of

the speaker circuits, causing the speakers to be

damaged or stop operating.

· When the speaker systems are connected to the

amplifier, if one of the speaker systems' terminals is

connected in reverse (positive

to negative

terminals), stereo phase will be reversed, preventing

proper stereo effect from being produced.

CAUTION

These speaker terminals carry

HAZARDOUS LIVE

voltage. To prevent the risk of electric shock when

connecting or disconnecting the speaker cables,

disconnect the power cord before touching any

uninsulated parts.

D3-4-2-2-3_A_En

Cleaning the speaker cabinet

With normal use, wiping with a dry cloth should be sufficient

to keep the cabinet clean. If necessary, clean with a cloth

dipped in a neutral cleanser diluted five or six times with

water, and wrung out well. Do not use furniture wax or

cleansers.

Never use thinners, benzine, insecticide sprays or other

chemicals on or near this unit since these will corrode the

surfaces.

Magnetic shielding

This speaker system is magnetically shielded. However,

depending on the installation location, color distortion may

occur if the speaker system is installed extremely close to the

screen of a television set.

If this happens, turn off the television, then turn it on again

after 15 min to 30 min. If the problem persists, place the

speaker system away from the television set.

Wire with white line

Connect to amplifier's

positive

speaker

output terminal.

Wire without white line

Connect to amplifier's

negative

speaker output

terminal.

Specifications

Enclosure .......................................... Bass-reflex bookshelf type

(magnetically shielded)

Configuration ...................................................................... 2-way

Woofer ...................................................... 10 cm (4 inch) cone

Tweeter ................................................... 2 cm (3/4 inch) dome

Nominal impedance ............................................................ 6

Frequency response ...................................... 50 Hz to 40 000 Hz

Sensitivity ............................................................................ 84 dB

Maximum input power ..................................................... 100 W

Crossover frequency ....................................................... 4.5 kHz

Exterior dimensions

.................................. 154 (W) mm x 246 (H) mm x 213 (D) mm

6 1/16 (W) in. x 9 11/16 (H) in. x 8 3/8 (D) in.

Weight ................................................................. 3.7 kg (8.2 lbs.)

Supplied accessories

Grille × 1

Speaker cable (2.5 m) × 1

Non skid pads × 1 set

Operating Instructions

· Specifications and design subject to possible

modification without notice, due to improvements.

If you want to dispose this product, do not mix it with

general household waste. There is a separate collection

system for used electronic products in accordance with

legislation that requires proper treatment, recovery and

recycling.

Private households in the 25 member states of the EU, in

Switzerland and Norway may return their used electronic

products free of charge to designated collection facilities or to a

retailer (if you purchase a similar new one).

For countries not mentioned above, please contact your local

authorities for the correct method of disposal.

By doing so you will ensure that your disposed product

undergoes the necessary treatment, recovery and recycling and

thus prevent potential negative effects on the environment and

human health.

For Europe

English

Published by Pioneer Corporation.

S001_En

Selecting fine audio equipment such as the unit

you've just purchased is only the start of your

musical enjoyment. Now it's time to consider how

you can maximize the fun and excitement your

equipment offers. This manufacturer and the

Electronic Industries Association's Consumer

Electronics Group want you to get the most out of

your equipment by playing it at a safe level. One that

lets the sound come through loud and clear without

annoying blaring or distortion-and, most importantly,

without affecting your sensitive hearing.

Sound can be deceiving. Over time your hearing

"comfort level" adapts to higher volumes of sound.

So what sounds "normal" can actually be loud and

harmful to your hearing. Guard against this by

setting your equipment at a safe level BEFORE your

hearing adapts.

To establish a safe level:

· Start your volume control at a low setting.

· Slowly increase the sound until you can hear it

comfortably and clearly, and without distortion.

Once you have established a comfortable sound

level:

· Set the dial and leave it there.

Taking a minute to do this now will help to prevent

hearing damage or loss in the future. After all, we

want you listening for a lifetime.

We Want You Listening For A Lifetime

Used wisely, your new sound equipment will

provide a lifetime of fun and enjoyment. Since

hearing damage from loud noise is often

undetectable until it is too late, this manufacturer

and the Electronic Industries Association's

Consumer Electronics Group recommend you avoid

prolonged exposure to excessive noise. This list of

sound levels is included for your protection.

Decibel

Level Example

Quiet library, soft whispers

Living room, refrigerator, bedroom away from traffic

Light traffic, normal conversation, quiet office

Air conditioner at 20 feet, sewing machine

Vacuum cleaner, hair dryer, noisy restaurant

Average city traffic, garbage disposals, alarm clock

at two feet.

THE FOLLOWING NOISES CAN BE DANGEROUS

UNDER CONSTANT EXPOSURE

Subway, motorcycle, truck traffic, lawn mower

100

Garbage truck, chain saw, pneumatic drill

120

Rock band concert in front of speakers,

thunderclap

140

Gunshot blast, jet plane

180

Rocket launching pad

Information courtesy of the Deafness Research Foundation.

Reviews

There are no reviews of this manual yet.

Related Products

PIONEER BCT-1410/NYXK/SP Service Manual

This manual has 71 pages, file size: 6.28 MB. It's available in languages: English.

PIONEER VSW-1/RYL Service Manual

This manual has 46 pages, file size: 3.95 MB. It's available in languages: English.

PIONEER DEH-P88RS Owner's Manual

This manual has 180 pages, file size: 1.74 MB. It's available in languages: Portuguese, Swedish, French, English, Russian, Greek, Spanish, Dutch, German, Danish, Italian, Turkish, Norwegian, Finnish.
