PIONEER S-DF1-K Service Manual

Cover page of PIONEER S-DF1-K Service Manual

Service Manual for PIONEER S-DF1-K, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 2 pages
  • File size: 0.02 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6
background image
1
S-DF1-K
Service
Manual
ORDER NO.
PET99012
PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1 B-9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880
©PIONEER CORPORATION 1999
1999 Printed in U.S.A.
·
The grille is attached to the trim baffle. Detach it by pulling the
grille towards you.
·
The trim baffle is attached to the baffle by external screws. To
detach it, unfasten those screws.
·
The woofer is attached to the trim baffle by internal screws. To
detach it, unfasten those screws. When attaching, face its terminal
downward.
·
The tweeter is attached to the baffle by internal screws. To detach
it, unfasten those screws.
·
The terminal cup is attached to the backboard by external screws.
To detach it, unfasten those screws.
·
The crossover assembly is attached to the terminal cup with
adhesive. To detach it, first remove terminal cup, and then remove it.
HOW TO REASSEMBLE AND
DISASSEMBLE
65S
This service manual is intended for qualified service technicians; it is
not meant for the casual do-it- your selfer. Qualified technicians have
the necessary test equipment and tools, and have been trained to
properly and safely repair complex products such as those covered by
this manual.
Improperly performed repairs can adversely affect the safety and
reliability of the product and may void the warranty. If you are not
qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service
technician.
SPEAKER SYSTEM
S-DF1-K
background image
1
S-DF1-K
Service
Manual
ORDER NO.
PET99012
PIONEER CORPORATION 4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1 B-9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 501 Orchard Road, #10-00, Wheelock Place, Singapore 238880
©PIONEER CORPORATION 1999
1999 Printed in U.S.A.
·
The grille is attached to the trim baffle. Detach it by pulling the
grille towards you.
·
The trim baffle is attached to the baffle by external screws. To
detach it, unfasten those screws.
·
The woofer is attached to the trim baffle by internal screws. To
detach it, unfasten those screws. When attaching, face its terminal
downward.
·
The tweeter is attached to the baffle by internal screws. To detach
it, unfasten those screws.
·
The terminal cup is attached to the backboard by external screws.
To detach it, unfasten those screws.
·
The crossover assembly is attached to the terminal cup with
adhesive. To detach it, first remove terminal cup, and then remove it.
HOW TO REASSEMBLE AND
DISASSEMBLE
65S
This service manual is intended for qualified service technicians; it is
not meant for the casual do-it- your selfer. Qualified technicians have
the necessary test equipment and tools, and have been trained to
properly and safely repair complex products such as those covered by
this manual.
Improperly performed repairs can adversely affect the safety and
reliability of the product and may void the warranty. If you are not
qualified to perform the repair of this product properly and safely, you
should not risk trying to do so and refer the repair to a qualified service
technician.
SPEAKER SYSTEM
S-DF1-K
background image
2
PARTS LIST
NOTES: · Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
· The "
"mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Mark No. Description
Parts No.
Packing Case
267392
Foam pad
267401
Poly Bag
264244
Mark No. Description
Parts No.
For Packing
SCHEMATIC DIAGRAM
Low Frequency Transducer
267476
High Frequency Transducer
267481
Grille Assembly
268548
Trim Baffle
267461
Catch Cup
270457
Crossover Assembly
268815
Gasket for Terminal Cup
268840
Instruction Manual
267416
Screw (for Low Frequency Trans)
BPZ40P100FMC
Screw (for High Frequency Trans)
BBZ35P140FMC
Screw (for Trim Baffle)
BYC40P200FZB
Screw (for Terminal Cup)
BYC40P200FZB
Mark No. Description
Parts No.
S-DF1-K
INPUT
WHITE
3.0
µ F / 50 V
36
µ F / 50 V
4.0
µ F / 50 V
0.68 / 5w
2.7 / 5w
10 / 5w
1.10 mH
0.42 mH
0.22 mH
RED
BLK
BLU
BRN
TWEETER
WOOFER
WHITE/BLACK
