Subwoofer
S-DV2SW
RRV3622
SPEAKER SYSTEM
S-DV2SW
XJC/E, XJC/NC
S-DV368SW
XTW/EW5
1. REASSEMBLY AND DISASSEMBLY PRECAUTIONS
1.1 SUBWOOFER
The speaker unit is attached to the drawer bottom by 4 external
screws. To detach it, unfasten those screws. When attaching it,
face its terminal back board.
The cosmetic baffle assy is attached to the baffle board by
press-fitting. To detach it, pry it open by inserting a flat blade
screwdriver into lower slot.
T-ZZR JUNE 2007 Printed in Japan
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2007
Subwoofer
S-DV2SW
RRV3622
SPEAKER SYSTEM
S-DV2SW
XJC/E, XJC/NC
S-DV368SW
XTW/EW5
1. REASSEMBLY AND DISASSEMBLY PRECAUTIONS
1.1 SUBWOOFER
The speaker unit is attached to the drawer bottom by 4 external
screws. To detach it, unfasten those screws. When attaching it,
face its terminal back board.
The cosmetic baffle assy is attached to the baffle board by
press-fitting. To detach it, pry it open by inserting a flat blade
screwdriver into lower slot.
T-ZZR JUNE 2007 Printed in Japan
background image
S-DV2SW
2
12
3
4
12
3
4
C
D
F
A
B
E
2. EXPLODED VIEWS AND PARTS LIST
2.1 PACKING
PACKING Parts List
NOTES :
· Parts marked by " NSP " are generally unavailable because they are not in our Master Spare Parts List.
· The
> mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
Tape
Tape
Tape
5 (2/2)
6 (2/2)
5 (1/2)
6 (1/2)
Mark No.
Description
Part No.
NSP 1
CS ASSY (Subwoofer)
SMW6227
2
Speaker Cord (SW: Purple)
SDS1179
3
Non Skid Pad
SEP6031
(for Subwoofer)
4
Polyethylene Bag S1
SHL1352
(for Cord Set)
5
Protector (Top)
SHA6144
6
Protector (Bottom)
SHA6146
7
Protection Sheet S6
SHC1825
8
Polyethylene Bag S7
SHL1390
(for Subwoofer)
9
Packing Case
SHG6265
(for S-DV2SW/ XJC/E)
9
Packing Case
SHG6299
(for S-DV2SW/XJC/NC)
9
Packing Case
SHG6292
(for S-DV368SW/XTW/EW5)
background image
S-DV2SW
3
5
678
56
7
8
C
D
F
A
B
E
2.2 SPEAKER SYSTEM
SPEAKER SYSTEM Parts List
Cabinet
2
3
8
7
9
10
11
12
11
Model Label
Mark No.
Description
Part No.
1
Cosmetic BF. Assy
SXB6010
2
Connecting Cord
SDD6008
3
Input Terminal
SKX1060
4
Speaker
A14LR80-53C
5
Screw
BYC40P160FTC
6
Base (Front)
SNK6149
7
Base (Rear)
SNK6150
background image
S-DV2SW
4
12
3
4
12
3
4
C
D
F
A
B
E
3. SCHEMATIC DIAGRAM
3.1 NETWORK ASSY
INPUT
Speaker
Black
Red
Connecting Cord (SDD6008)
