Operating Instructions | Mode d'emploi | Bedienungsanleitung

Discover the benefits of registering your product online at

http://www.pioneer.co.uk (or http://www.pioneer.eu).

Découvrez les nombreux avantages offerts en enregistrant votre

produit en ligne maintenant sur http://www.pioneer.fr

(ou http://www.pioneer.eu).

Bitte nutzen Sie die Möglichkeit zur Registrierung Ihres Produktes

unter http://www.pioneer.de (oder http://www.pioneer.eu)

DCS-363

XV-DV363

DVD/CD Receiver

Récepteur-lecteur DVD/CD

DVD/CD Receiver

S-DV363

Speaker System

Système Acoustique

Lautsprechersystem

DCS-370

XV-DV370

DVD/CD Receiver

Récepteur-lecteur DVD/CD

DVD/CD Receiver

S-DV370T

S-DV370SW

Speaker System

Système Acoustique

Lautsprechersystem

cover & anki.fm

Operating Instructions | Mode d'emploi | Bedienungsanleitung

Discover the benefits of registering your product online at

http://www.pioneer.co.uk (or http://www.pioneer.eu).

Découvrez les nombreux avantages offerts en enregistrant votre

produit en ligne maintenant sur http://www.pioneer.fr

(ou http://www.pioneer.eu).

Bitte nutzen Sie die Möglichkeit zur Registrierung Ihres Produktes

unter http://www.pioneer.de (oder http://www.pioneer.eu)

DCS-363

XV-DV363

DVD/CD Receiver

Récepteur-lecteur DVD/CD

DVD/CD Receiver

S-DV363

Speaker System

Système Acoustique

Lautsprechersystem

DCS-370

XV-DV370

DVD/CD Receiver

Récepteur-lecteur DVD/CD

DVD/CD Receiver

S-DV370T

S-DV370SW

Speaker System

Système Acoustique

Lautsprechersystem

cover & anki.fm

Location: rear of the unit

The exclamation point within an equilateral

triangle is intended to alert the user to the

presence of important operating and

maintenance (servicing) instructions in the

literature accompanying the appliance.

The lightning flash with arrowhead symbol,

within an equilateral triangle, is intended to

alert the user to the presence of uninsulated

"dangerous voltage" within the product's

enclosure that may be of sufficient

magnitude to constitute a risk of electric

shock to persons.

CAUTION:

TO PREVENT THE RISK OF ELECTRIC

SHOCK, DO NOT REMOVE COVER (OR

BACK). NO USER-SERVICEABLE PARTS

INSIDE. REFER SERVICING TO QUALIFIED

SERVICE PERSONNEL.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

IMPORTANT

D3-4-2-1-1_En-A

WARNING

This equipment is not waterproof. To prevent a fire

or shock hazard, do not place any container filed

with liquid near this equipment (such as a vase or

flower pot) or expose it to dripping, splashing, rain

or moisture.

D3-4-2-1-3_A_En

WARNING

To prevent a fire hazard, do not place any naked

flame sources (such as a lighted candle) on the

equipment.

D3-4-2-1-7a_A_En

VENTILATION CAUTION

When installing this unit, make sure to leave space

around the unit for ventilation to improve heat

radiation (at least 10 cm at top, 10 cm at rear, and

10 cm at each side).

WARNING

Slots and openings in the cabinet are provided for

ventilation to ensure reliable operation of the

product, and to protect it from overheating. To

prevent fire hazard, the openings should never be

blocked or covered with items (such as newspapers,

table-cloths, curtains) or by operating the

equipment on thick carpet or a bed.

D3-4-2-1-7b_A_En

[For U.K. model]

Replacement and mounting of an AC plug on the power supply cord of this unit should be performed only by qualified

service personnel.

D3-4-2-1-2-2_B_En

IMPORTANT: THE MOULDED PLUG

This appliance is supplied with a moulded three pin mains plug for your safety and convenience. A 5 amp fuse is fitted in this plug. Should the

fuse need to be replaced, please ensure that the replacement fuse has a rating of 5 amps and that it is approved by ASTA or BSI to BS1362.

Check for the ASTA mark

or the BSI mark

on the body of the fuse.

If the plug contains a removable fuse cover, you must ensure that it is refitted when the fuse is replaced. If you lose the fuse cover the plug

must not be used until a replacement cover is obtained. A replacement fuse cover can be obtained from your local dealer.

If the fitted moulded plug is unsuitable for your socket outlet, then the fuse shall be removed and the plug cut off and disposed of

safely. There is a danger of severe electrical shock if the cut off plug is inserted into any 13 amp socket.

If a new plug is to be fitted, please observe the wiring code as shown below. If in any doubt, please consult a qualified electrician.

IMPORTANT: The wires in this mains lead are coloured in accordance with the following code:

Blue : Neutral

Brown : Live

As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in

your plug, proceed as follows ;

The wire which is coloured BLUE must be connected to the terminal which is marked with the

letter N or coloured BLACK.

The wire which is coloured BROWN must be connected to the terminal which is marked with the

letter L or coloured RED.

How to replace the fuse: Open the fuse compartment with a screwdriver and replace the fuse.

Thank you for buying this Pioneer product.

Please read through these operating instructions so that you will know how to operate your model

properly. After you have finished reading the instructions, put them in a safe place for future reference .

DCS-363.book

WARNING

The voltage of the available power supply differs

according to country or region. Be sure that the

power supply voltage of the area where this unit

will be used meets the required voltage (e.g., 230 V

or 120 V) written on the rear panel.

D3-4-2-1-4_A_En

Before plugging in for the first time, read the following

section carefully.

Operating Environment

Operating environment temperature and humidity:

+5 ºC to +35 ºC (+41 ºF to +95 ºF); less than 85 %RH

(cooling vents not blocked)

Do not install this unit in a poorly ventilated area, or in

locations exposed to high humidity or direct sunlight (or

strong artificial light)

D3-4-2-1-7c_A_En

CAUTION

This product is a class 1 laser product, but this

product contains a laser diode higher than Class 1.

To ensure continued safety, do not remove any covers

or attempt to gain access to the inside of the product.

Refer all servicing to qualified personnel.

The following caution label appears on your unit.

Location: top of the unit

CLASS 1

LASER PRODUCT

D3-4-2-1-8_B_En

This product complies with the Low Voltage Directive

(73/23/EEC, amended by 93/68/EEC), EMC Directives

(89/336/EEC, amended by 92/31/EEC and

93/68/EEC).

D3-4-2-1-9a_En

CAUTION

The STANDBY/ON switch on this unit will not

completely shut off all power from the AC outlet.

Since the power cord serves as the main disconnect

device for the unit, you will need to unplug it from

the AC outlet to shut down all power. Therefore,

make sure the unit has been installed so that the

power cord can be easily unplugged from the AC

outlet in case of an accident. To avoid fire hazard,

the power cord should also be unplugged from the

AC outlet when left unused for a long period of time

(for example, when on vacation).

D3-4-2-2-2a_A_En

If the AC plug of this unit does not match the AC

outlet you want to use, the plug must be removed

and appropriate one fitted. Replacement and

mounting of an AC plug on the power supply cord of

this unit should be performed only by qualified

service personnel. If connected to an AC outlet, the

cut-off plug can cause severe electrical shock. Make

sure it is properly disposed of after removal.

The equipment should be disconnected by removing

the mains plug from the wall socket when left

unused for a long period of time (for example, when

on vacation).

D3-4-2-2-1a_A_En

POWER-CORD CAUTION

Handle the power cord by the plug. Do not pull out the

plug by tugging the cord and never touch the power

cord when your hands are wet as this could cause a

short circuit or electric shock. Do not place the unit, a

piece of furniture, etc., on the power cord, or pinch the

cord. Never make a knot in the cord or tie it with other

cords. The power cords should be routed such that they

are not likely to be stepped on. A damaged power cord

can cause a fire or give you an electrical shock. Check

the power cord once in a while. When you find it

damaged, ask your nearest PIONEER authorized

service center or your dealer for a replacement.

S002_En

This product is for general household purposes. Any

failure due to use for other than household purposes

(such as long-term use for business purposes in a

restaurant or use in a car or ship) and which

requires repair will be charged for even during the

warranty period.

K041_En

DCS-363.book

Contents

01 Controls and displays

Front panel

. . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Remote control

. . . . . . . . . . . . . . . . . . . . . . . . 7

Display

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

02 Getting started

Home theater sound setup

. . . . . . . . . . . . . . 10

Setting the channel levels

. . . . . . . . . . . . . 10

Using the on-screen displays

. . . . . . . . . . . . 10

Playing discs

. . . . . . . . . . . . . . . . . . . . . . . . 11

Basic playback controls

. . . . . . . . . . . . . . . 11

Resume and Last Memory

. . . . . . . . . . . . . 12

DVD-Video disc menus

. . . . . . . . . . . . . . . . 12

Video CD/Super VCD PBC menus

. . . . . . . 12

Listening to the radio

. . . . . . . . . . . . . . . . . . 12

Improving poor FM reception

. . . . . . . . . . . 13

Memorizing stations

. . . . . . . . . . . . . . . . . . 13

Listening to station presets

. . . . . . . . . . . . 13

Listening to other sources

. . . . . . . . . . . . . . 13

Setting the sleep timer

. . . . . . . . . . . . . . . . . 13

03 Listening to your system

Auto listening mode

. . . . . . . . . . . . . . . . . . . 14

Listening in surround sound

. . . . . . . . . . . . . 14

Using Extra Power mode

. . . . . . . . . . . . . . . . 14

Listening in stereo

. . . . . . . . . . . . . . . . . . . . 15

Listening with headphones

. . . . . . . . . . . . 15

Using the SFC modes

. . . . . . . . . . . . . . . . . . 15

Adjusting the bass and treble

. . . . . . . . . . . . 15

Boosting the bass level

. . . . . . . . . . . . . . . . . 15

04 Disc playback features

Scanning discs

. . . . . . . . . . . . . . . . . . . . . . . 16

Playing in slow motion

. . . . . . . . . . . . . . . . . 16

Frame advance/frame reverse

. . . . . . . . . . . . 16

Playing a JPEG slideshow

. . . . . . . . . . . . . . . 16

Browsing DVD or Video CD/Super VCD discs with

the Disc Navigator

. . . . . . . . . . . . . . . . . . . . . 17

Browsing WMA, MP3, MPEG-4 AAC, DivX video

and JPEG files with the Disc Navigator

. . . . . 18

Using Playlists

. . . . . . . . . . . . . . . . . . . . . . . . 18

Programming playlists

. . . . . . . . . . . . . . . . 18

Listening to playlists

. . . . . . . . . . . . . . . . . . 19

Clearing files from a playlist

. . . . . . . . . . . . 19

Looping a section of a disc

. . . . . . . . . . . . . . 19

Using repeat play

. . . . . . . . . . . . . . . . . . . . . 19

Using random play

. . . . . . . . . . . . . . . . . . . . 19

Creating a program list

. . . . . . . . . . . . . . . . . 20

Other functions available from the program

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Searching a disc

. . . . . . . . . . . . . . . . . . . . . . 21

Switching subtitles

. . . . . . . . . . . . . . . . . . . . 21

Switching language/audio channels

. . . . . . . 21

Zooming the screen

. . . . . . . . . . . . . . . . . . . 21

Switching camera angles

. . . . . . . . . . . . . . . 22

Displaying disc information

. . . . . . . . . . . . . . 22

05 USB playback

Using the USB interface

. . . . . . . . . . . . . . . . 23

Basic playback controls

. . . . . . . . . . . . . . . . 23

Scanning files

. . . . . . . . . . . . . . . . . . . . . . . . 24

Playing a JPEG slideshow

. . . . . . . . . . . . . . . 24

Browsing files with the Navigator

. . . . . . . . . 24

DCS-363.book

English

Français

Deutsch

Nederlands

Italiano

Español

06 More tuner features: RDS

An introduction to RDS

. . . . . . . . . . . . . . . . . 25

Displaying RDS information

. . . . . . . . . . . . 25

Searching for RDS programs

. . . . . . . . . . . 25

07 Audio Settings and Video Adjust

menus

Audio Settings menu

. . . . . . . . . . . . . . . . . . . 26

Audio DRC

. . . . . . . . . . . . . . . . . . . . . . . . . 26

Video Adjust menu

. . . . . . . . . . . . . . . . . . . . 26

08 Initial Settings menu

Using the Initial Settings menu

. . . . . . . . . . . 27

Video Output settings

. . . . . . . . . . . . . . . . . . 27

Language settings

. . . . . . . . . . . . . . . . . . . . . 28

Display settings

. . . . . . . . . . . . . . . . . . . . . . . 29

Options settings

. . . . . . . . . . . . . . . . . . . . . . 29

Speakers settings

. . . . . . . . . . . . . . . . . . . . . 29

Parental Lock

. . . . . . . . . . . . . . . . . . . . . . . 29

About DivX® VOD content

. . . . . . . . . . . . . 30

Speaker Distance

. . . . . . . . . . . . . . . . . . . . 31

09 Other connections

Connecting external antennas

. . . . . . . . . . . . 32

Connecting auxiliary audio components

. . . . 32

Using the SCART AV output

. . . . . . . . . . . . . 32

Line Out options

. . . . . . . . . . . . . . . . . . . . . 33

Connecting using HDMI

. . . . . . . . . . . . . . . . 33

Switching the HDMI audio setting

. . . . . . . 34

Resetting the HDMI connection

. . . . . . . . . 34

About HDMI

. . . . . . . . . . . . . . . . . . . . . . . . . 34

About control out connections

. . . . . . . . . . . 35

10 Additional information

Disc/content format playback

compatibility

. . . . . . . . . . . . . . . . . . . . . . . . . 36

Disc compatibility table

. . . . . . . . . . . . . . . . 36

About DVD+R/DVD+RW compatibility

. . . . 37

About DivX

. . . . . . . . . . . . . . . . . . . . . . . . . 37

About MPEG-4 AAC

. . . . . . . . . . . . . . . . . . . 38

About WMA

. . . . . . . . . . . . . . . . . . . . . . . . 38

Using and taking care of discs

. . . . . . . . . . . . 38

DVD Video regions

. . . . . . . . . . . . . . . . . . . 39

Installation and maintenance

. . . . . . . . . . . . 39

Hints on installation

. . . . . . . . . . . . . . . . . . 39

Cleaning the pickup lens

. . . . . . . . . . . . . . . 39

Problems with condensation

. . . . . . . . . . . . 39

Moving the system unit

. . . . . . . . . . . . . . . . 39

Screen sizes and disc formats

. . . . . . . . . . . . 39

TV system setting

. . . . . . . . . . . . . . . . . . . . . . 40

Switching off the demo

. . . . . . . . . . . . . . . . . 40

Dimming the Display

. . . . . . . . . . . . . . . . . . . 40

Troubleshooting

. . . . . . . . . . . . . . . . . . . . . . . 41

General

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

DVD/CD/Video CD player

. . . . . . . . . . . . . . . 42

Tuner

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43

USB connection

. . . . . . . . . . . . . . . . . . . . . 43

HDMI connection

. . . . . . . . . . . . . . . . . . . . 43

Error Messages

. . . . . . . . . . . . . . . . . . . . . . 44

Resetting the system

. . . . . . . . . . . . . . . . . . . 44

Setting the Key Lock

. . . . . . . . . . . . . . . . . . . 44

Using the language code list

. . . . . . . . . . . . . 44

Language code list

. . . . . . . . . . . . . . . . . . . . . 45

Country/Area code list

. . . . . . . . . . . . . . . . . . 45

Specifications

. . . . . . . . . . . . . . . . . . . . . . . . 46

If you want to dispose this product, do not mix it with general household waste. There is a separate collection system for used

electronic products in accordance with legislation that requires proper treatment, recovery and recycling.

Private households in the 25 member states of the EU, in Switzerland and Norway may return their used electronic products free of charge to

designated collection facilities or to a retailer (if you purchase a similar new one).

For countries not mentioned above, please contact your local authorities for the correct method of disposal.

By doing so you will ensure that your disposed product undergoes the necessary treatment, recovery and recycling and thus prevent potential

negative effects on the environment and human health.

K058_En

DCS-363.book

Reviews

There are no reviews of this manual yet.

Related Products

Cover page of PIONEER AVD-W6210 Service Manual

PIONEER S-DV363 (DCS-363) Owner's Manual

Manual details

We guarantee that...

Sample pages

Reviews

Related Products

PIONEER AVD-W6210 Service Manual

PIONEER DEH-P4400 Owner's Manual

PIONEER DEH-P946 Owner's Manual

PIONEER DEH-46DH/UC Service Manual

PIONEER DEH-2850MP/XN/ES1 Owner's Manual

Popular Brands

General

Members Area
