Cover page of PIONEER S-EU2TB-LR/XTW1/E Service Manual

Service Manual for PIONEER S-EU2TB-LR/XTW1/E, downloadable as a PDF file.

We also have owner's manual to this model.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 2 pages
  • File size: 0.29 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2005
RRV3177
T ­ ZZK JULY 2005 Printed in Japan
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the cabinet by catches. Detach by pull-
ing it toward you.
The woofer is attached to the baffle by 4 external screws. To
detach it, unfasten those screws. When attaching it, face its ter-
minal upward.
The midrange is attached to the flange by 4 external screws. To
detach it, unfasten those screws. When attaching it, face its ter-
minal downward. The flange is attached to the baffle by 4 exter-
nal screws. To detach it, unfasten those screws.
The tweeter is attached to the baffle by 3 external screws. To
detach it, unfasten those screws.
SPEAKER SYSTEM
S-EU2TB-LR
XTW/E
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2005
RRV3177
T ­ ZZK JULY 2005 Printed in Japan
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The grille is attached to the cabinet by catches. Detach by pull-
ing it toward you.
The woofer is attached to the baffle by 4 external screws. To
detach it, unfasten those screws. When attaching it, face its ter-
minal upward.
The midrange is attached to the flange by 4 external screws. To
detach it, unfasten those screws. When attaching it, face its ter-
minal downward. The flange is attached to the baffle by 4 exter-
nal screws. To detach it, unfasten those screws.
The tweeter is attached to the baffle by 3 external screws. To
detach it, unfasten those screws.
SPEAKER SYSTEM
S-EU2TB-LR
XTW/E
background image
2
1
23
4
12
3
4
C
D
F
A
B
E
S-EU2TB-LR
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
NOTES:
PARTS LIST
Mark No.
Description
Part No.
SCHEMATIC DIAGRAM
Flange
31-200200-01
Grille (without Badge)
31-200200-03
Grille (with Badge)
30-200200-04
Terminal
37-108420-01
Tweeter
40-000003-01
Mid-Range Driver
40-258104-01
Woofer
40-528306-01
Capacitor
42-001210-01
Lead Wire (for Woofer)
45-222302-52
Lead Wire (for Mid Range)
45-223002-52
Lead Wire (for Tweeter)
45-227502-52
Wall Mount
56-813300-00
Screw (for Wall Mount)
50-031202-04
Screw (for Woofer)
50-041868-14
Screw (for Tweeter)
50-381816-14
Screw (for Mid Range)
50-381816-24
Input
Black
Red
Red
Black
Red
Black
Red
Black
1.2
µF/100V
Woofer
Mid Range
Tweeter
For Packing
Mark No.
Description
Part No.
1
Speaker Cable
44-220330-01
2
Carton Box
60-200207-01
3
Polyethylene foam
63-200200-01
4
Polyethylene Bag
64-474726-14
5
Polyethylene Bag
64-362426-24
6
Owner's Manual
77-200207-01
(English, Spanish, Chinese)
3
Speaker System
4
2
1
3
6
5
4
Speaker System
