Cover page of PIONEER S-EU5TB/XTW/JP Service Manual

Service Manual for PIONEER S-EU5TB/XTW/JP, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 2 pages
  • File size: 0.42 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
RRV3435
T ­ ZZM JUNE 2006 Printed in Japan
S-EU5TB
S-EU5TB
XTW/JP
SPEAKER SYSTEM
REASSEMBLY AND DISASSEMBLY PRECAUTIONS
The grille is attached to the cabinet by catches. Detach by pull-
ing it toward you.
The woofer is attached to the baffle by 4 external screws.
To detach it, unfasten those screws.
When attaching upper one, face its terminal downward. When
attaching lower one, face its terminal leftward.
The tweeter is attached to the baffle by 4 external screws.
To detach it, unfasten those screws.
When attaching it, face its terminal with marking rightward.
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2006
RRV3435
T ­ ZZM JUNE 2006 Printed in Japan
S-EU5TB
S-EU5TB
XTW/JP
SPEAKER SYSTEM
REASSEMBLY AND DISASSEMBLY PRECAUTIONS
The grille is attached to the cabinet by catches. Detach by pull-
ing it toward you.
The woofer is attached to the baffle by 4 external screws.
To detach it, unfasten those screws.
When attaching upper one, face its terminal downward. When
attaching lower one, face its terminal leftward.
The tweeter is attached to the baffle by 4 external screws.
To detach it, unfasten those screws.
When attaching it, face its terminal with marking rightward.
background image
2
1
23
4
12
3
4
C
D
F
A
B
E
S-EU5TB
EXPLODED VIEW
PACKING PARTS LIST
Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List.
The
mark found on some component parts indicates the importance of the safety factor of the part.
Therefore, when replacing, be sure to use parts of identical designation.
NOTES:
Mark No.
Description
Part No.
1
Speaker Cable
44-180330-01
2
Operating Instructions
77-200503-11
3
Polyethylene Foam (Top)
63-200500-01
4
Polyethylene Foam (Bottom)
63-200500-02
5
Polyethylene Foam (Center)
63-200500-03
6
Polyethylene Bag (for Manual) 64-362417-12
7
Polyethylene Bag (for SP System) 64-515317-12
8
Packing Case
60-200503-01
SPEAKER SYSTEM PARTS LIST
Mark No.
Description
Part No.
Network
01-200500-01
Grille Assy (with Badge)
30-200300-04
Grille(without Badge)
31-200300-03
Plastic Feet
31-010801-07
Terminal Connector (Black)
37-006200-08
Terminal Connector (Red)
37-006200-09
Terminal Plate
37-200500-40
Tweeter
40-041200-02
Woofer
40-528307-03
Screw (for Network)
50-031202-04
Screw (for Woofer)
50-041868-14
Screw (for Tweeter)
50-381816-14
Screw (for Terminal Plate)
50-381816-24
Metal Ring
54-007004-10
Sealing Packing
74-200500-99
(for Terminal Plate)
Sealing Packing (for Tweeter)
74-220005-01
Sealing Packing (for Woofer)
74-420005-01
Woofer
Woofer
Tweeter
Input
Blue
Red
Black
Red
Black
Black
4.7
µF/100 V
1.5
µF/100 V
C
C
L
L
1.5 mH
0.56 mH
Network (01-200500-01)
7
1
3
5
4
8
Accessory Set
Accessory Set
Warranty Set
Speaker System
6
2
SCHEMATIC DIAGRAM
