Cover page of PIONEER S-VS100V/XJI/NC Service Manual

Service Manual for PIONEER S-VS100V/XJI/NC, downloadable as a PDF file.

Manual details

  • Immediate download after payment.
  • Delivered as a PDF file.
  • The manual has 3 pages
  • File size: 0.1 MB
  • Available language versions: English
  • Different language versions may vary sligthly in file size and page count.

We guarantee that...

  • our manuals are complete,
  • the manual includes circuit diagrams,
  • our manuals are checked with antivirus,
  • We'll issue refund if the manual is damaged, incomplete or unreadable (our refund policy)

Sample pages

Thumbnail of page 1Thumbnail of page 2Thumbnail of page 3Thumbnail of page 4
Thumbnail of page 5Thumbnail of page 6Thumbnail of page 7
background image
ORDER NO.
PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 1999
RRV2211
T-ZZM SEPT. 1999 Printed in Japan
This product is component of system.
SPEAKER SYSTEM
S-VS100V
XJI/E
S-VS100V XJI/NC
System
Service Manual
Remarks
RRV2221
RRV2211
Component
X-VS100DVD
XR-VS100D
S-VS100V
STEREO CD CASSETTE DECK RECIEVER
SPEAKER SYSTEM
This service manual
FOR PRECAUTION OF
REASSEMBLY AND DISASSEMBLY
The cosmetic baffle assy is attached to the cabinet by 4 external
hexagon socket screws. To detach the cosmetic baffle assy,
loosen these screws by the hexagon screw driver. Then care-
fully disconnect the wires of the woofer and mid-range
mounted on the cosmetic baffle assy. To attach the cosmetic
baffle assy, replace it on the cabinet correctly and secure with 4
screws.
The woofer is attached to the cosmetic baffle assy together with
the cosmetic ring assy by 4 internal screws. To detach the
woofer (cosmetic ring assy), loosen these screws. To attach the
cosmetic ring assy, fit the notch of the cosmetic ring to the pro-
jection of the cosmetic baffle assy. To attach the woofer, face
its terminal downward, and fit the hole of the frame to the boss
of the cosmetic baffle assy. To attach the cosmetic ring assy
and woofer, replace it on the cosmetic baffle assy correctly and
secure with 4 screws.
The mid-range is attached to the cosmetic baffle assy by 2 in-
ternal screws. To detach the mid-range, loosen these screws.
Then carefully disconnect the wires of the tweeter mounted on
the cosmetic baffle assy by adhesion. To attach the mid-range,
replace it on the cosmetic baffle assy correctly and secure with
2 screws.
The network assy is connected to the input terminal. To detach
the network assy, disconnect the wire from the input terminal.
To attach the network assy, connect the wire of the network
assy to the input terminal correctly.
When exchange the tweeter, do it with the cosmetic baffle
assy.
